Liebert®
EXM™ Parallel Cabinet
User Manual—10-200kVA, 60Hz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXM Parallel Cabinet and is the answer not in the manual?

Questions and answers

Related Manuals for Vertiv EXM Parallel Cabinet

Summary of Contents for Vertiv EXM Parallel Cabinet

  • Page 1 Liebert® EXM™ Parallel Cabinet User Manual—10-200kVA, 60Hz...
  • Page 2 The products covered by this instruction manual are manufactured and/or sold by Vertiv This document is the property of Vertiv and contains confidential and proprietary information owned by Vertiv. Any copying, use or disclosure of it without the written permission of Vertiv is strictly prohibited.

  • Page 3: Table Of Contents

    Figure 7 Main components—800mm 1+1 and 2+0 Liebert EXM Parallel Cabinet... . . 17 Figure 8 Outline drawing—300mm Liebert EXM Parallel Cabinet ......18 Figure 9 Outline drawing—600mm Liebert EXM Parallel Cabinet.
  • Page 4 Liebert EXM Parallel Cabinet specifications ........

  • Page 5: Important Safety Instructions

    Risk of moving heavy units and tipping hazard. Can cause equipment damage, injury and death. Exercise extreme care when handling cabinets to avoid equipment damage or injury to personnel. The Liebert EXM Parallel Cabinet’s weight ranges from 263-714lb. 119.3 to 323.8kg. Locate center of gravity symbols and determine unit weight before handling each cabinet.
  • Page 6 One person should never work alone, even if all power is removed from the equipment. A second person should be standing by to assist and summon help in case of an accident. ® ™ Vertiv | Liebert Parallel Cabinet User Manual |...
  • Page 7 Une personne ne devrait jamais travailler seule, même si toute l’alimentation de l’équipement est coupée. Une deuxième personne devrait toujours être présente pour porter assistance ou chercher de l’aide en cas d’accident. ® ™ Vertiv | Liebert Parallel Cabinet User Manual |...

  • Page 8: Mechanical Installation

    NOTICE Risk of improper installation. Can cause equipment damage and void warranty. The Liebert EXM Parallel Cabinet should be installed by a qualified engineer in accordance with the information contained in this chapter All equipment not referred to in this manual is shipped with details of its own mechanical and electrical installation.

  • Page 9: Environmental Considerations

    ONSIDERATIONS 1.3.1 Room The Liebert EXM Parallel Cabinet is intended for indoor installation and should be located in a cool, dry, clean-air environment with adequate ventilation to keep the ambient temperature within the specified operating range (see 3.0 - Specifications).

  • Page 10: Clearances

    Maintenez en tout temps l’inclinaison verticale minimale. 1.4.2 Clearances Liebert EXM Parallel Cabinet’s have no ventilation grilles at either side or at the rear. Clearance around the front of the equipment should be sufficient to enable free passage of personnel with the doors fully opened.

  • Page 11: Power Cables

    OWER ABLES The Liebert EXM Parallel Cabinet requires both power and control cabling once it has been mechanically installed. All control cables must be separate from the power cables. Run control cables in metal conduits or metal ducts that are electrically bonded to the cabinets they are connected to.
  • Page 12 Figure 1 Cabinet arrangement—Liebert EXM UPS, battery cabinets, Liebert Parallel Cabinet Liebert Liebert Liebert Parallel Cabinet (Matching) Liebert Liebert Battery Battery Parallel Battery Cabinet Cabinet Cabinet Cabinet (Matching) (Matching) (Matching) (Matching) ® ™ Vertiv | Liebert Parallel Cabinet User Manual |...

  • Page 13: Power Cable Connection Procedure

    The operations described in this section must be performed by authorized electricians or properly trained and qualified technical personnel wearing adequate safety clothing, eye protection and gloves. If you have any difficulties, do not hesitate to contact Vertiv. See the back page of this manual for contact information. AVERTISSEMENT Risque de décharge électrique pouvant entraîner des dommages matériels, des blessures...

  • Page 14: Table 1 Power Wiring For Liebert Exm Ups To Liebert Exm Parallel Cabinet

    Tighten the connections to the proper torque (see Table 8). Ensure correct phasing. 6. Connect the control wiring from the Liebert EXM Parallel Cabinet terminal block TB1 to the Liebert EXM UPS Bypass Module (X9 J23 and J26). Tighten the connections to the proper torque (see Table 8).
  • Page 15 Mechanical Installation Table 1 Power wiring for Liebert EXM UPS to Liebert EXM Parallel Cabinet (continued) System Configuration From Utility UPS 1 AC Input Utility UPS 2 AC Input Utility UPS 1 AC Output Liebert EXM 60-100kVA 1+1 UPS 2 AC Output...

  • Page 16: Table 2 Control Wiring For Liebert Exm Ups To Liebert Exm Parallel Cabinet

    Mechanical Installation Table 2 Control wiring for Liebert EXM UPS to Liebert EXM Parallel Cabinet System Configuration From Liebert EXM UPS Bypass Module UPS 1 X9J26-9 TB1-8 X9J26-11 TB1-7 X9J26-13 TB1-1 X9J26-15 TB1-2 1+1 and 2+0 UPS2 X9J26-9 TB1-10 X9J26-11...

  • Page 17: Table 3 Control Wiring For Liebert Exm Ups To Liebert Exm Parallel Cabinet With Skru Inter

    Liebert EXM Parallel Cabinet output rather than being connected directly to the Liebert EXM Parallel Cabinet itself. Where this is the case, the Liebert EXM Parallel Cabinet output cables can be rated to suit the individual distribution network demands rather than being fully load-rated.

  • Page 18: Installation Drawings

    Installation Drawings 2.0 INSTALLATION DRAWINGS Figure 2 Parallel (1+1, 2+0) cabinet, 10-200kVA Liebert EXM Parallel Cabinet *System AC Output AC Input 4 Wire + Grd OPT. K 4 Wire + Grd Static Bypass MOB1 * UPS 1 Output AC Input...

  • Page 19: Figure 3 One-Line Diagram, Parallel (2+1) Cabinet, 10-160Kva

    Installation Drawings Figure 3 One-line diagram, Parallel (2+1) Cabinet, 10-160kVA Liebert EXM Parallel Cabinet *System AC Output AC Input 4 Wire + Grd OPT. K 4 Wire + Grd Static Bypass MOB1 * UPS 1 Output AC Input Busbar Liebert EXM #1...

  • Page 20: Figure 4 Main Components-300Mm 1+1 Liebert Exm Parallel Cabinet

    2. Control wiring and power wiring must be run in separate conduits. 3. All wiring is to be in accordance with national and local electrical codes. 4. If maintenance bypass cabinet is attached to UPS, Vertiv 1.38" will supply the interconnection cables.

  • Page 21: Figure 5 Main Components-600Mm 2+1 Liebert Exm Parallel Cabinet

    DETAIL A 2. All wiring is to be in accordance with national and local electrical codes. EXM16017 8 Typically Phase Busbar 3. If maintenance bypass cabinet is attached to UPS, Vertiv will supply Rev. 1 Connections the interconnection cables. ®...

  • Page 22: Figure 6 Main Components-800Mm 2+1 Liebert Exm Parallel Cabinet

    2. Control wiring and power wiring must be run in separate conduits. EXM16110 3. All wiring is to be in accordance with national and local electrical codes. 4. If maintenance bypass cabinet is attached to UPS, Vertiv will supply Rev. 0 the interconnection cables.

  • Page 23: Figure 7 Main Components-800Mm 1+1 And 2+0 Liebert Exm Parallel Cabinet

    2. Control wiring and power wiring must be run in separate conduits. 0.71" 3. All wiring is to be in accordance with national and local electrical codes. (18mm) 4. If maintenance bypass cabinet is attached to UPS, Vertiv will supply 1.75" the interconnection cables. (44mm) EXM16109 5.

  • Page 24: Figure 8 Outline Drawing-300Mm Liebert Exm Parallel Cabinet

    Installation Drawings Figure 8 Outline drawing—300mm Liebert EXM Parallel Cabinet 8.6" (218mm) FRONT Cable Entry Area 10" x 11.8" (254mm x 300mm) Cable Entry Area 8.3" x 7.9" (211mm x 201mm) 34.3" (872mm) Detail A TOP VIEW Cable Entry Area 10"...

  • Page 25: Figure 9 Outline Drawing-600Mm Liebert Exm Parallel Cabinet

    Installation Drawings Figure 9 Outline drawing—600mm Liebert EXM Parallel Cabinet FRONT 4.5" 15.0" (381mm) 2.9" (74mm) (114mm) Cable Entry Area Control Cable Entry 20.7" x 17.7" 4.7" x 1.6" (526mm x 450mm) (119mm x 41mm) 28.3" Cable Entry Area (719mm) 20.7"...

  • Page 26: Figure 10 Outline Drawing-800Mm Liebert Exm Parallel Cabinet

    Installation Drawings Figure 10 Outline drawing—800mm Liebert EXM Parallel Cabinet 22.8" (579mm) 2.9" (74mm) Control Cable Entry 4.7" x 1.6" (119mm x 41mm) Power Cable Plate 28.3" (719mm) X 17.5" (445mm) 28.3" Power Cable Entry (719mm) 26.8" (681mm) X 16.8" (427mm)

  • Page 27: Figure 11 Control Wiring Diagram, Liebert Exm Parallel Cabinet, 1+1 And 2+0 Paralleling

    Installation Drawings Figure 11 Control wiring diagram, Liebert EXM Parallel Cabinet, 1+1 and 2+0 paralleling ® ™ Vertiv | Liebert Parallel Cabinet User Manual |...

  • Page 28: Figure 12 Control Wiring Diagram, Liebert Exm Parallel Cabinet, 2+1 Paralleling

    Installation Drawings Figure 12 Control wiring diagram, Liebert EXM Parallel Cabinet, 2+1 paralleling ® ™ Vertiv | Liebert Parallel Cabinet User Manual |...

  • Page 29: Figure 13 Control Wiring Diagram, Liebert Exm Parallel Cabinet, 2+0 And 1+1 Paralleling With

    Installation Drawings Figure 13 Control wiring diagram, Liebert EXM Parallel Cabinet, 2+0 and 1+1 paralleling with SKRU 1 2 3 4 5 6 ® ™ Vertiv | Liebert Parallel Cabinet User Manual |...

  • Page 30: Figure 14 Control Wiring Diagram, Liebert Exm Parallel Cabinet, 2+1 Paralleling With Skru

    Installation Drawings Figure 14 Control wiring diagram, Liebert EXM Parallel Cabinet, 2+1 paralleling with SKRU 1 2 3 4 5 6 ® ™ Vertiv | Liebert Parallel Cabinet User Manual |...

  • Page 31: Figure 15 Control Wiring Diagram, Liebert Exm Parallel Cabinet, 2+1 With Repo

    Installation Drawings Figure 15 Control Wiring Diagram, Liebert EXM Parallel Cabinet, 2+1 with REPO ® ™ Vertiv | Liebert Parallel Cabinet User Manual |...

  • Page 32: Figure 16 Control Wiring Diagram, Liebert Exm Parallel Cabinet, 2+0 And 1+1 With Repo

    Installation Drawings Figure 16 Control wiring diagram, Liebert EXM Parallel Cabinet, 2+0 and 1+1 with REPO ® ™ Vertiv | Liebert Parallel Cabinet User Manual |...

  • Page 33: Specifications

    Specifications 3.0 SPECIFICATIONS Table 4 Liebert EXM Parallel Cabinet specifications 10-40kVA 60-100kVA 120-200kVA Model Size 300mm 600mm 800mm Cabinet Width Input Parameters Input Voltage to Bypass, VAC 208/120V or 220/127V, 3-Phase, 4-Wire Input Current Refer to UPS User Manual Input Frequency...

  • Page 34: Electrical Characteristics

    (2) 500 kcmil — (3) 350 kcmil (3) 500 kcmil (3) 350 kcmil (3) 500 kcmil Table 6 Liebert EXM Parallel Cabinet output currents, 2+0 and 2+1 configurations 2+0 and 2+1 Configuration UPS Size System Nominal OCP Device Bolt 75°C...

  • Page 35: Torque Requirements

    ORQUE EQUIREMENTS All electrical connections must be tight. Tables 8 and 9 provide the torque values for the connections to the Liebert EXM Parallel Cabinet. Use these values unless the equipment is labeled otherwise. Table 8 Busbar torque for power wiring...
  • Page 36 Specifications ® ™ Vertiv | Liebert Parallel Cabinet User Manual |...
