Summary of Contents for Audio Analogue PRIMO CENTO VT
- Page 1 All manuals and user guides at all-guides.com AUDIO ANALOGUE primo CENTO VT INTEGRATED AMPLIFIER OWNER’S MANUAL MANUALE D’ISTRUZIONI Manual rev1.3a...
- Page 2 All manuals and user guides at all-guides.com...
- Page 3 AUDIO ANALOGUE. The information contained in this manual is related to the data kept by AUDIO ANALOGUE at the moment of the issue o f this publication; AUDIO ANALOGUE has the right to make changes to this document without prior notice.
- Page 4 Nessuna parte del presente manuale può essere riprodotta con alcun mezzo, trasmessa o copiata per usi pubblici e/o privati senza la previa autorizzazione di AUDIO ANALOGUE. Le informazioni contenute nel presente manuale sono relative ai dati in possesso di AUDIO ANALOGUE al momento della pubblicazione; AUDIO ANALOGUE si riserva il diritto di apportare cambiamenti al presente documento senza alcun preavviso.
- Page 5 All manuals and user guides at all-guides.com Dear Audiophile, To celebrate the first century from the invention of the tube, Audio Analogue presents Primo Cento VT: an equipment that establish the new reference in the category of stereo products characterized by an amazing quality and versatility.
-
Page 6: Front Panel
All manuals and user guides at all-guides.com FRONT PANEL DESCRIZIONE DEL PANNELLO FRONTALE POWER. Turns the unit on/off. SELECT. Input selector. It allows selecting the desired source. One of the green leds on its right indicates the selected source. PH/1,2,3,4,5. Green leds that indicate the selected input. A fix light indicates the selected source and the normal operative status of the unit, while a blinking light indicates that the unit is in the mute mode. -
Page 7: Back Panel
All manuals and user guides at all-guides.com BACK PANEL DESCRIZIONE DEL PANNELLO POSTERIORE RIGHT SPEAKER OUT. Right speaker out connector. LEFT SPEAKER OUT. Left speaker out connector. EARTH. Turntable ground connector (to be used only when the phono in is in use) PH/1. - Page 8 All manuals and user guides at all-guides.com Description of the remote controller AMPLIFIER Functions . IN+: it changes the selected source. . VOLUME+: it increases the volume of the unit. . IN-: it changes the selected source. . VOLUME-: it decreases the volume of the unit. .
- Page 9 WHERE TO PLACE PRIMO CENTO VT Primo Cento VT is a complex unit that may generate a large quantity of heat. Please locate the unit in a well-ventilated place. In particular, you should leave at least 5cm around and above the unit and avoid placing it close to heat sources (radiators, heaters, amplifiers, television sets).
- Page 10 POWERING UP PRIMO CENTO VT After plugging the Primo Cento VT power cord into the wall outlet, turn the unit on by pressing the POWER button. The led that corresponds to the first input starts flashing then turns on to indicate that the unit is ready (hang time is needed to heathen up the fuse).
- Page 11 PHONO MM/MC SWITCHOVER The PRIMO CENTO VT has an on-board phono stage that interfaces both MM and MC cartridges. It is factory preset to MM, so if switchover to MC is necessary, see the illustration for the correct jumper position.
-
Page 12: Specifications
All manuals and user guides at all-guides.com SPECIFICATIONS Parameter Settings Value Channels: Power stage gain 20Hz-20KHz 26.8dB Line gain 20Hz-20kHz 12dB Frequency response Vin =1 dBV(*) +0/-3dB Vout = -7dBV 7Hz-66KHz (on volume change) Vout = -3dBV 7Hz-79KHz Vout = 0dBV 7Hz-95.7KHz Vout = 12dBV 7Hz-95.7KHz... -
Page 13: Troubleshooting
Increase volume No sound Faulty or incorrectly plugged signal Check cords and their connection connectors between Primo Cento VT and the sources Off or incorrectly selected source Check if the source is on and active and if the correct in is selected... -
Page 14: Ricerca Guasti
‘AAA’) Eccessiva distanza dal pannello Avvicinarsi di più all’apparecchio o frontale dell’apparecchio o angolo non cambiare angolo corretto Se i rimedi suggeriti non dovessero funzionare oppure il problema non è riportato nella lista, contattate il vostro rivenditore Audio Analogue... - Page 15 Please contact your Audio Analogue dealer who will inform you about the take-back and recycling. Small products (and apparecchiature elettriche ed elettroniche insieme ai small amounts) might be taken back by your local collection facilities. normali rifiuti domestici. Per tali prodotti è previsto un sistema di raccolta a parte.
- Page 16 All manuals and user guides at all-guides.com AUDIO ANALOGUE Manufactured and Distributed by: AUDIO FUTURA spa Via Maestri Del Lavoro 583 51015 Monsummano Terme (PT) Italy Tel. 0572 954513 fax 0572 958099 www.audioanalogue.com - info@audioanalogue.com...
