0-6
3010-01
▶ Installation of special zig
1) Identify the SAT clutch with adjusting equipment around the clutch cover.
2) Adapt the zig set(4 pieces) between the clutch cover and diaphram spring around (Refer to
the picture).
Diaphram
Cover
Rexton applied SAC (Self Adjusting Clutch) system.
This clutch system also requires to replace both clutch cover and disc when the disc need to
be replaced. However, for
disc re-usage, special zig set is not necessary.
This is different point with SAT system.
CLUTCH
RODIUS 2007.07
SST part number:D9930 0010C
Adjusting
equipment
Zig for clutch removal
and installation
