- Page 1 OWNERS MANUAL Model No. 45-02141 BROADCAST SPREADER 100 (PUSH) CAUTION: Read Rules for Safe Operation and Instructions Carefully Assembly Operation Maintenance Repair Parts PRINTED IN U.S.A. FORM NO. 47290 (REV. 12/01)
-
Page 2: Rules For Safe Operation
RULES FOR SAFE OPERATION The following safety precautions are suggested. This Wear eye and hand protection when handling and broadcast spreader is designed, engineered and tested when applying lawn or garden chemicals. to offer reasonably safe and effective service, provided it is operated in strict accordance with these instructions. - Page 3 FIGURE 2 - HARDWARE PACKAGE KEY QTY. DESCRIPTION KEY QTY. DESCRIPTION Hex Bolt, 1/4-20 x 1-1/2" Long Cotter Pin, 3/32" x 3/4" Long Hex Bolt, 1/4-20 x 5/8" Long Flow Control Link Carriage Bolt, 1/4-20 x 3/4" Long Extension Spring Nylon Washer Spacer Tube Flat Washer, 5/16"...
- Page 4 Place a wheel onto the end of the axle that has a cross ASSEMBLY INSTRUCTIONS hole. The long end of the hub goes to the inside. See figure 5. TOOLS REQUIRED FOR ASSEMBLY Pliers Assemble a 5/32" x 2" cotter pin through the notched Hammer wheel hub and the axle.
- Page 5 Place the handle tube (long) on the crossover tube, (side between crossover tube and hopper), align the holes in the handle tube, crossover tube, and shaft HANDLE TUBE (LONG) support. Assemble with 1/4" hex bolt, flat washer and hex lock nut removed in the previous step. See figures 1/4"...
- Page 6 17. Assemble the flow control arm to the flow control 20. Hook free end of flow control rod through hole in slide mounting bracket using one 1/4" x 5/8" hex bolt and gate bracket located near bottom of hopper. See figure one 1/4"...
- Page 7 23. Assemble the flow control gage onto the flow control mounting bracket using a 1/4" x 3/4" carriage bolt, a nylon washer and hand knob. See figure 14. 24. Move flow control arm to off position and push flow control mounting bracket toward hopper until closure plate (located in bottom of hopper) is completely closed.
-
Page 8: Operation
OPERATION FLOW RATE CHART The application spread pattern should overlap to insure MATERIAL TYPE Flow Rate Setting uniform coverage at the edges. The approximate distance At 3 M.P.H. between each pass is shown in the application diagram. Light Heavy See figure 15. Fertilizer Granular APPLICATION DIAGRAM... -
Page 9: Maintenance And Storage
Heavy moisture conditions may require a cover over MAINTENANCE & STORAGE the hopper to keep contents dry. The vinyl cover acts as a wind and moisture shield, but should not be used as a rain cover. See figure 18. Do not store spreader with any material in hopper. Clean your spreader after use. - Page 10 REPAIR PARTS FOR BROADCAST SPREADER MODEL 45-02141...
- Page 11 REPAIR PARTS LIST FOR BROADCAST SPREADER MODEL 45-02141 REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION 44624 Hopper 43878 Wire, Agitator 43882 Rivet, Stainless 43088 Washer, Flat 1/4" Std. 62482 Ass'y, Guide Closure 44468 Sprocket - 6 Tooth 44588 Tube, Frame...
-
Page 12: Limited Warranty
If you do not know the dealer or distributor in your area, please write to the Customer Service Department of AGRI-FAB, Inc. at P.O. BOX 903, SULLIVAN, ILLINOIS 61951. The return of a product or part to AGRI-FAB ®...
