- Page 1 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 OWNERS MANUAL Model No. 45-02112 125 LB. TOW BROADCAST SPREADER CAUTION: Read Rules for Safe Operation and Instructions Carefully Assembly Operation Maintenance Repair Parts FORM NO. 48317 (4/02) www.mymowerparts.com...
-
Page 2: Rules For Safe Operation
For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 RULES FOR SAFE OPERATION Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when operating equipment. •... - Page 3 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 SHOWN FULL SIZE NOT SHOWN FULL SIZE KEY QTY. DESCRIPTION KEY QTY. DESCRIPTION Hex Bolt, 1/4-20 x 1-3/4" Flat Washers 1-5/8" Hex Bolts, 3/8-16 x 1-1/4" Cotter Pin, 3/32" x 3/4" Hex Bolt, 1/4-20 x 3/4"...
-
Page 4: Tools Required For Assembly
For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 5. Align the holes in the ends of the two hitch braces with ASSEMBLY INSTRUCTIONS the nearest hole in the hitch tube. Fasten with a 1/4" x 1-3/4" hex bolt and a 1/4" hex lock nut. See figure 2. DO TOOLS REQUIRED FOR ASSEMBLY NOT TIGHTEN AT THIS TIME. - Page 5 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 9. Assemble a spacer and a 1-5/8" flat washer onto the 14. Assemble the flow control link (end with small hole) to end of the axle that has the large hole. See figure 4. the flow control arm using a 1/4"...
- Page 6 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 14. Assemble the flow control arm to the flow control 17. Hook the free end of the flow control rod through the mounting bracket using a 1/4" x 3/4" hex bolt, two nylon hole in the slide gate bracket located near the bottom washers and a 1/4"...
-
Page 7: Carriage Bolt
For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 NYLON WING NUT 5/16" FLAT WASHER NYLON WASHER 1/4" x 3/4" ADJUSTABLE CARRIAGE BOLT STOP FIGURE 11 20. Position the flow control mounting bracket (figure 12). a. Push on flow control arm until it locks in "OFF" position. -
Page 8: Operation
For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 OPERATION HOW TO USE YOUR SPREADER SETTING THE FLOW CONTROL (Refer to figure 12 on page 7.) REFER 1. Loosen the nylon wing nut, set the adjustable stop to the desired flow rate setting and retighten the wing nut. CHARTS The higher the setting number, the wider the opening in the bottom of the hopper. -
Page 9: Maintenance
For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 MAINTENANCE SERVICE AND ADJUSTMENTS 1. If the axle, slotted gear and sprocket assembly is CHECK FOR LOOSE FASTENERS disassembled, mark down the positions of the parts as 1. Before each use make a thorough visual check of the they are removed. - Page 10 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 REPAIR PARTS FOR BROADCAST SPREADER MODEL 45-02112 21 22 www.mymowerparts.com...
- Page 11 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 REPAIR PARTS FOR BROADCAST SPREADER MODEL 45-02112 REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION 44466 Hopper 43070 Washer, Flat 3/8" * 43882 Rivet, Stainless 41576 Bolt, Hex 3/8-16 x 1-3/4" Lg.*...
-
Page 12: Repair Parts
If you do not know the dealer or distributor in your area, please write to the Customer Service Department of AGRI-FAB, Inc. at P.O. BOX 903, SULLIVAN, ILLINOIS 61951. The return of a product or part to AGRI-FAB ®...
