Agri-Fab 45-02103 Owner's Manual

Agri-fab 125 lb. push broadcast spreader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
™
OWNERS
MANUAL
Model No.
45-02103
125 LB. PUSH
BROADCAST SPREADER
CAUTION:
Read Rules for
Assembly
Safe Operation
Operation
and Instructions
Maintenance
Carefully
Repair Parts
the fastest way to purchase parts www.speedepart.com
PRINTED IN U.S.A.
FORM NO. 49030 (REV. 4/7/08)

Advertisement

Table of Contents
loading

Related Manuals for Agri-Fab 45-02103

Summary of Contents for Agri-Fab 45-02103

  • Page 1 ™ OWNERS MANUAL Model No. 45-02103 125 LB. PUSH BROADCAST SPREADER CAUTION: Read Rules for Assembly Safe Operation Operation and Instructions Maintenance Carefully Repair Parts the fastest way to purchase parts www.speedepart.com PRINTED IN U.S.A. FORM NO. 49030 (REV. 4/7/08)

  • Page 2: Rules For Safe Operation

    The following safety precautions are suggested. This broadcast spreader is designed, engineered and tested to offer reasonably safe and effective service, provided it is operated in strict accordance with these instructions. Failure to do so may result in personal injury. Always observe the rules of safe operation.
  • Page 3 QTY. DESCRIPTION Hex Bolt, 1/4-20 x 1-3/4" Long Hex Bolt, 1/4-20 x 1-1/2" Long Hex Bolt, 1/4-20 x 1" Long Carriage Bolt, 1/4-20 x 3/4" Long Nyock Nut, 1/4-20 Thd. Flat Washer, 5/16" SAE Nylon Washer Flat Washer, 5/8" Cotter Pin, 5/32" x 2" SHOWN FULL SIZE NOT SHOWN FULL SIZE QTY.

  • Page 4: Tools Required For Assembly

    ASSEMBLY INSTRUCTIONS TOOLS REQUIRED FOR ASSEMBLY (1) Pliers (1) Hammer (2) 7/16" Open or Boxed End Wrenches Remove the spreader, the loose parts and the hardware package from the carton. Lay out parts and hardware and identify using the illustrations on pages 2 and 3. With the spreader resting upside down on the top of the hopper, assemble a spacer and then a 5/8"...
  • Page 5 IMPORTANT: Do Not asssemble handle tube to same side of crossover tube as shaft support plate. Place the long handle tube onto the crossover tube on the side opposite from the shaft support plate. Fasten with the bolt, washer and nut removed in the previous step.
  • Page 6 16. Assemble the flow control arm to the flow control mounting bracket using a 1/4" x 1" hex bolt, two nylon washers and a 1/4" nylock nut as shown in figure 8. Tighten carefully. The flow control arm should be snug, but should pivot with no more than a slight resistance.

  • Page 7: Carriage Bolt

    22. Place the adjustable stop into the "ON" end of the slot in the top of the flow control mounting bracket. Secure with the 1/4" x 3/4" carriage bolt, a nylon washer, a 5/16" flat washer and the nylon wing nut. See figure NYLON WING NUT 5/16"...

  • Page 8: Operation

    OPERATION HOW TO USE YOUR SPREADER SETTING THE FLOW CONTROL (Refer to figure 13 on page 7.) Loosen the nylon wing nut, set the adjustable stop to the desired flow rate setting and retighten the wing nut. The higher the setting number, the wider the opening in the bottom of the hopper.

  • Page 9: Maintenance

    MAINTENANCE CHECK FOR LOOSE FASTENERS Before each use make a thorough visual check of the spreader for any bolts and nuts which may have loosened. Retighten any loose bolts and nuts. CHECK FOR WORN OF DAMAGED PARTS Check for worn or damaged parts before each use. Repair or replace parts if necessary.
  • Page 10 REPAIR PARTS FOR BROADCAST SPREADER MODEL 45-02103...
  • Page 11 REPAIR PARTS LIST FOR BROADCAST SPREADER MODEL 45-02103 REF. PART QTY. DESCRIPTION 44466 Hopper C-9M5732 Pop Rivet (not shown) 62482 Ass'y, Guide Closure 48842 Tube, Frame 23753 Slide Gate Angle Bracket 23758 Slide Gate Bracket 43648 Bolt, Hex 1/4-20 x 1-1/2" Lg.*...

  • Page 12: Repair Parts

    Agri-Fab, Inc. Unauthorized uses and/or reproductions of this manual will subject such unauthorized user to civil and criminal penalties as provided by the United States Copyright Laws.
