OWNERS
MANUAL
Model No.
45-02101-101
PRO 125#
BROADCAST SPREADER
CAUTION:
Read Rules for
Safe Operation
and Instructions
Carefully
Assembly
Operation
Maintenance
Repair Parts
PRINTED IN U.S.A.
FORM NO. 47438 (Rev. 2/00)
www.mymowerparts.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Agri-Fab 45-02101-101
Summary of Contents for Agri-Fab 45-02101-101
- Page 1 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 OWNERS MANUAL Model No. 45-02101-101 PRO 125# BROADCAST SPREADER CAUTION: Read Rules for Safe Operation and Instructions Carefully Assembly Operation Maintenance Repair Parts PRINTED IN U.S.A. FORM NO. 47438 (Rev. 2/00)
- Page 2 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 TABLE OF CONTENTS SAFETY RULES...............2 MAINTENANCE & STORAGE..........9 CARTON CONTENTS............2 LUBRICATION..............9 ASSEMBLY ..............4 PARTS EXPLOSION............10 OPERATION ..............8 REPAIR PARTS..............11 RULES FOR SAFE OPERATION Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times, when using equipment.
- Page 3 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 FULL SIZE HARDWARE REFERENCE CHART NOT SHOWN FULL SIZE REF. QTY. DESCRIPTION REF. QTY. DESCRIPTION Spacer Tube, Short (1") Bolt, Carriage 1/4" x 3/4" Spacer Tube, Long (1-5/16") Bolt, Hex 1/4" x 5/8" Bracket, Swivel Bolt, Hex 1/4"...
- Page 4 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 5. Place the short spacer tube and a 3/4" washer onto the ASSEMBLY INSTRUCTIONS end of the axle that has the large drilled hole (left hand side). See figure 2. TOOLS REQUIRED FOR ASSEMBLY 6.
- Page 5 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 10. Assemble the (long) handle tube to the side of the 14. Assemble the leg stand tube to the handle tube (long) crossover tube opposite the shaft support plate, as using two 1/4" x 1-1/2" hex bolts and two 1/4" hex lock shown in figure 4.
- Page 6 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 18. Assemble the flow control arm to the flow control mount- 21. Hook the free end of the flow control rod through the hole ing bracket using one 1/4" x 5/8" hex bolt and one 1/4" in the slide gate bracket located near the bottom of the hex lock nut.
- Page 7 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 24. Assemble the flow control gauge onto the flow control 28. Assemble the spreader shield to the front swivel brack- mounting bracket using a 1/4" x 3/4" carriage bolt, a ets using two 1/4" x 3/4" carriage bolts, 5/16" washers nylon washer and the hand knob.
- Page 8 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 USING THE SPREADER OPERATION 1. Determine approximate square footage of area to be covered and estimate amount of fertilizer or seed re- STARTING THE SPREADER quired. 1. Pull the flow control arm back against the flow control 2.
- Page 9 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 IMPORTANT: Application rates (shown on chart) are LUBRICATION affected by humidity and mixture content of material (granu- 1. Apply a little automotive grease to the sprocket and gear. lar and pellet). Minor adjustment of the flow rate setting may 2.
- Page 10 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 REPAIR PARTS FOR BROADCAST SPREADER MODEL 45-02101-101 www.mymowerparts.com...
- Page 11 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 REPAIR PARTS FOR BROADCAST SPREADER MODEL 45-02101-101 REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION 44466 Hopper 1509-069 Bolt, Hex 1/4-20 x 1-3/4" Lg. * 43882 Rivet, Stainless 43866 Bolt, Hex 1/4-20 x 5/8" Lg. Gr. 5*...
- Page 12 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 REPAIR PARTS 303 West Raymond Sullivan, IL. 61951 (217) 728-8388 / www.agri-fab.com www.mymowerparts.com...
