  • Page 1 ™ owners manual model no. 45-02153-131 100 lB. Tow BroaDCasT sPreaDer CAUTION: Assembly Read Rules for Operation Safe Operation Maintenance and Instructions Repair Parts Carefully the fastest way to purchase parts www.speedepart.com PRINTED IN U.S.A. FORM NO. 40537 (REV. 10/25/07)

  • Page 2: Rules For Safe Operation

    Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when operating equipment. • Read the towing vehicle owners manual and towing vehicle safety rules. Know how to operate your tractor before using the broadcast spreader attachment.
  • Page 3 1/4" x 1-1/2" hex bolt and a 1/4" nylock nut. See figure 3. Do not tighten at this time. Tighten all loose hex nuts and bolts attached to hitch tube and hitch braces. Do not collapse tubes when tightening. HITCH TUBE 1/4"...

  • Page 4: Operation

    Push on flow control arm until it locks in "OFF" position. Slide flow control mounting bracket along tube until closure plate in bottom of hopper just closes. Snug the 1/4" lock nuts just enough to hold flow control mounting bracket in place. Set adjustable stop at "5".

  • Page 5: Maintenance

    REFER CHARTS OVERLAP FIGure 8 ImPorTanT: Application rates shown in the chart are affected by humidity and by the moisture content of the material (granular and pellet). Some minor setting adjustments may be necessary to compensate for this condition. aPPlICaTIon CHarT (sHIelD uP) TYPe maTerIal Flow seTTInG...
  • Page 6 ParTs For BroaDCasT sPreaDer moDel 45-02153-131 21 22...
  • Page 7 ParTs For BroaDCasT sPreaDer moDel 45-02153-131 ParT no. DesCrIPTIon 44624 Hopper 46055 Pin, Spring 1/8" Dia. x 1" Lg. 62482 Ass'y, Guide Closure 40469 Tube, Frame 23753 Slide Gate Angle Bracket 23758 Slide Gate Bracket 43661 Bolt, Hex 1/4-20 x 1" Lg.*...

  • Page 8: Repair Parts

    ParTs Agri-Fab, Inc. 809 South Hamilton Sullivan, IL. 61951 217-728-8388 © 2007 Agri-Fab, Inc www.agri-fab.com...
