OWNERS
MANUAL
Model No.
45-02102-101
125 LB. PUSH
BROADCAST SPREADER
CAUTION:
Read Rules for
Safe Operation
and Instructions
Carefully
Assembly
Operation
Maintenance
Repair Parts
PRINTED IN U.S.A.
FORM NO. 48324 (3/03)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 45-02102-101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Agri-Fab 45-02102-101

  • Page 1 OWNERS MANUAL Model No. 45-02102-101 125 LB. PUSH BROADCAST SPREADER CAUTION: Read Rules for Safe Operation and Instructions Carefully Assembly Operation Maintenance Repair Parts PRINTED IN U.S.A. FORM NO. 48324 (3/03)
  • Page 2: Rules For Safe Operation

    RULES FOR SAFE OPERATION The following safety precautions are suggested. This Wear eye and hand protection when handling and broadcast spreader is designed, engineered and tested when applying lawn or garden chemicals. to offer reasonably safe and effective service, provided it is operated in strict accordance with these instructions.
  • Page 3 FULL SIZE NOT FULL SIZE HARDWARE PACKAGE KEY QTY. DESCRIPTION KEY QTY. DESCRIPTION Flow Control Link Hex Bolt, 1/4-20 x 1-3/4" Long Spacer Tube, Short Hex Bolt, 1/4-20 x 1-1/2" Long Spacer Tube, Long Hex Bolt, 1/4-20 x 3/4" Long Grip Carriage Bolt, 1/4-20 x 3/4"...
  • Page 4: Tools Required For Assembly

    Place the short spacer tube and a 3/4" washer ASSEMBLY INSTRUCTIONS onto the end of the axle that has the large drilled hole (left hand side). See Figure 2. TOOLS REQUIRED FOR ASSEMBLY Place the drive wheel onto the axle. The notched hub and the air valve should face to the outside.
  • Page 5 IMPORTANT: Do Not assemble long handle tube on 13. Assemble the leg stand tube to the long handle same side of crossover tube as shaft support tube using two 1/4" x 1-1/2" hex bolts. Secure plate. Assemble on opposite side. tightly with two 1/4"...
  • Page 6 16. Assemble the flow control arm to the flow control 19. Hook free end of flow control rod through hole in mounting bracket using a 1/4" x 3/4" hex bolt, two slide gate bracket located near bottom of hopper. nylon washers and a 1/4" hex lock nut as shown See figure 9.
  • Page 7 22. Place the adjustable stop into the "ON" end of 23. Position the flow control mounting bracket the slot in the top of the flow control mounting (Refer to figure 12). bracket. Secure with the 1/4" x 3/4" carriage bolt, a.
  • Page 8 24. Attach an angle stop bracket and a swivel bracket 26. Assemble the spreader shield to the front swivel to the rear hole in the R.H. shield bracket using brackets using two 1/4" x 3/4" carriage bolts, 5/16" a 1/4" x 3/4" hex bolt, two 5/16" washers, a ny- washers and the two 1/4"...
  • Page 9: Operation

    Always shut the closure plate before turning or OPERATION stopping the spreader. If fertilizer is accidentally deposited too heavily HOW TO USE YOUR SPREADER in a small area, soak the area thoroughly with a garden hose or sprinkler to prevent burning of SETTING THE FLOW CONTROL the lawn.
  • Page 10: Maintenance

    IMPORTANT: Application rates shown in the chart MAINTENANCE are affected by humidity and by the moisture con- tent of the material (granular and pellet). Some CHECK FOR LOOSE FASTENERS minor setting adjustments may be necessary to Before each use make a thorough visual check of compensate for this condition.
  • Page 11: Service And Adjustments

    STORAGE Rinse inside of hopper and exterior of spreader and dry off before storing. Store in a clean, dry area. SERVICE AND ADJUSTMENTS If the axle, slotted gear and sprocket assembly is disassembled, mark down the positions of the parts as they are removed. The drive wheel and sprocket positions in relation to the slotted gear determine which direction the spreader plate will spin.
  • Page 12 REPAIR PARTS FOR BROADCAST SPREADER MODEL 45-02102-101...
  • Page 13 REPAIR PARTS FOR BROADCAST SPREADER MODEL 45-02102-101 REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION 44482 Grip, Handle 44466 Hopper 46055 Pin, Spring 1/8" Dia. x 1" Lg. 43882 Rivet, Stainless 1543-069 Washer, Nylon 62482 Ass'y, Guide Closure R19111116 Washer, 5/16 SAE...
  • Page 14 NOTES...
  • Page 15 NOTES...
