User Manual
Intrinsically Safe Ultrasonic Anemometer
Doc No: 1360-PS-0001
Issue 10 (Applies to Anemometers with Serial Numbers 3000 onwards)
Parts 1360-PK-022
and 1360-PK-060
Gill Instruments Limited
Saltmarsh Park, 67 Gosport Street, Lymington,
Hampshire, SO41 9EG, UK
Tel: +44 1590 613500, Fax: +44 1590 613555
Email:
anem@gillinstruments.com
Website:
www.gillinstruments.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1360-PK-022 and is the answer not in the manual?

Questions and answers

Related Manuals for Gill Instruments 1360-PK-022

Summary of Contents for Gill Instruments 1360-PK-022

  • Page 1 User Manual Intrinsically Safe Ultrasonic Anemometer Doc No: 1360-PS-0001 Issue 10 (Applies to Anemometers with Serial Numbers 3000 onwards) Parts 1360-PK-022 and 1360-PK-060 Gill Instruments Limited Saltmarsh Park, 67 Gosport Street, Lymington, Hampshire, SO41 9EG, UK Tel: +44 1590 613500, Fax: +44 1590 613555 Email: anem@gillinstruments.com...
  • Page 2 Gill Instruments Ltd WARNING: ENSURE CORRECT SUPPLY VOLTAGE IS USED/SELECTED ON POWER SUPPLY BEFORE INSTALLATION Intrinsically Safe WindObserver Anemometer Page 2 Issue 10 Doc. No. 1360-PS-0001 May 2015...

  • Page 3: Table Of Contents

    Gill Instruments Ltd FOREWORD ..............................5 INTRODUCTION ............................5 IS SYSTEM PACKING LIST ........................5 Gill Part 1360-PK-022 .......................... 5 Gill Part 1360-PK-060 .......................... 6 Spares ..............................6 SPECIFICATION ............................7 Intrinsically Safe WindObserver 1360-PK-052................... 7 Mounted in Hazardous Area..........................7 Power Supply Unit 1360-PK-053.
  • Page 4 Gill Instruments Ltd APPENDIX 1 ............................... 62 SUMMARY OF ABBREVIATIONS USED IN THIS MANUAL ............. 62 APPENDIX 2 ............................... 64 PRODUCT APPROVALS ..........................64 SIRA ATEX CERTIFICATION ......................... 64 SIRA IECEx CERTIFICATION ........................ 64 APPENDIX 3 ELECTRICAL CONFORMITY .................... 90...

  • Page 5: Foreword

    Gill products are in continuous development and therefore specifications may be subject to change and design improvements without prior notice. The information contained in this manual remains the property of Gill Instruments and must not be copied or reproduced for commercial gain.

  • Page 6: Gill Part 1360-Pk-060

    Gill Instruments Ltd Gill Part 1360-PK-060 Comprising of:-   1360-PK-052 Intrinsically Safe WindObserver 2 axis anemometer.  1255-10-057 Anemometer Mounting kit.  1360-PK-054 Anemometer 20 Way Connector kit.  1000-10-034 This manual on a CD.  1277-30-045 Head Cover (2 halves).

  • Page 7: Specification

    Gill Instruments Ltd SPECIFICATION Intrinsically Safe WindObserver 1360-PK-052. Mounted in Hazardous Area. I.S. Rating – ATEX European and IECEx International (For use in Zone 0, 1 and 2 Areas). See ATEX and IECEx Certificates in Appendix 2. Measurement Output 1, 2 and 4Hz...

  • Page 8: Power Supply Unit 1360-Pk-053

    Gill Instruments Ltd Power Supply Unit 1360-PK-053. Mounted in Non Hazardous Area. The I.S. PCI may be used with either Model 1360 IS Anemometer (SIRA 00ATEX2218, IECEx SIR 13.0157) or IS II Anemometer (SIRA 15ATEX2014 and IECEx SIR 13.0013). I.S. Rating – ATEX European, IECEx International.

  • Page 9: Power Supply Unit 1360-Pk-055 (1954-00-002)

    Gill Instruments Ltd Power Supply Unit 1360-PK-055 (1954-00-002) Mounted in Non Hazardous Area. I.S. LVPCI may be used with either Model 1360 IS Anemometer (SIRA 00ATEX2218, IECEx SIR 13.0157) or IS II Anemometer (SIRA 15ATEX2014 and IECEx SIR 13.0013). I.S. Rating – ATEX European, IECEX International.

  • Page 10: Installation

    The Intrinsically Safe WindObserver has a base mounted 20 way socket and is supplied with a mating 20 way connector requiring connection to a suitable IS cable. Intrinsically Safe Cable and Junction Boxes are not available from Gill Instruments and must be determined to be suitable for use by the customer.

  • Page 11: Installation Using A Mains Power Supply

    Gill Instruments Ltd 5.1.1 Installation using a Mains Power Supply. The unit must be installed in accordance with the Control Drawing 1360-G-028. Note that the PCI box is mounted in the Non Hazardous area. Drawing 1360-G-028 I.S. Issue 3, IS WindObserver System Diagram Sheet 1 of 2.

  • Page 12: Drawing 1360-G-028 Issue 3, I.s. Windobserver System Diagram Sheet 2 Of 2

    Gill Instruments Ltd Drawing 1360-G-028 Issue 3, I.S. WindObserver System Diagram Sheet 2 of 2. Intrinsically Safe WindObserver Anemometer Page 12 Issue 10 Doc. No. 1360-PS-0001 May 2015...

  • Page 13: Installation Using A Low Voltage Power Supply

    Gill Instruments Ltd 5.1.2 Installation using a Low Voltage Power Supply. The unit must be installed in accordance with the Drawing 1954-30-026. Note that the PCI box is mounted in the Safe area. Drawing 1954-30-026 issue 3, IS WindObserver System Diagram...
  • Page 14 Gill Instruments Ltd Drawing 1954-30-026 issue 3, IS WindObserver System Diagram Sheet 2 of 2. Intrinsically Safe WindObserver Anemometer Page 14 Issue 10 Doc. No. 1360-PS-0001 May 2015...

  • Page 15: Installation Guidelines

    Gill Instruments Ltd Installation Guidelines 5.2.1 Power Supply Mains Instructions specific to hazardous area installations (in accordance with IEC60079- 0:2011 clause 30) The following instructions relevant to safe use in a hazardous area apply to equipment covered by certificate numbers IECEx SIR 13.0156 and Sira 00ATEX2217.

  • Page 16: Power Supply Low Voltage

    Gill Instruments Ltd 5.2.2 Power Supply Low Voltage Instructions specific to hazardous area installations in accordance with IEC60079-0:2011 clause 30. The following instructions relevant to safe use in a hazardous area apply to equipment covered by certificate numbers IECEx SIR 13.0159 and Sira 13ATEX2384.

  • Page 17: Anemometer

    Gill Instruments Ltd 5.2.3 Anemometer Instructions specific to hazardous area installations (in accordance with IEC60079- 0:2011 clause 30) The following instructions relevant to safe use in a hazardous area apply to equipment covered by certificate numbers IECEx SIR 15.0013 and SIRA 15ATEX2014.
  • Page 18 Gill Instruments Ltd Anemometer Siting General Guidelines The Intrinsically Safe WindObserver has been designed to meet and exceed the stringent standards listed in its specification. Operating in diverse environments all over the world, Intrinsically Safe WindObserver requires no calibration or adjustment whatsoever.

  • Page 19: Cabling

    Note: Gill Instruments do not supply Intrinsically Safe cables; it is the responsibility of the customer to determine the type of cable that is suitable for each individual IS installation.
  • Page 20 Gill Instruments Ltd 20 Way Connector terminal positions viewed from the solder connection side. Slot Position Grub Screw Wiring Connections between the 20 way Anemometer connector and the Power Supply Interface Box. 20 Way Mains Power Low Voltage Anemometer Function...

  • Page 21: Mounting

    Gill Instruments Ltd 5.2.5 Mounting Do NOT remove the black “rubber” transducer caps. Take care not to knock the four transducer arms. All the time the WindObserver is not in its final location, it should be protected from damage by keeping it in its original packaging, treating it as a delicate instrument.

  • Page 22: Alignment

    Gill Instruments Ltd 5.2.6 Alignment The anemometer should be set to point North, see drawing 1360-G-026 as shown below, (or to some other known reference direction). This is facilitated by slots in the base for the mounting screws, which allow rotation of the anemometer for fine alignment.

  • Page 23: Sealing

    Gill Instruments Ltd 5.2.7 Sealing The connector area at the base of the anemometer should not be directly exposed to moisture or solvents, as whilst the connectors are sealed when mated, the anemometer is vented to air at the base to avoid pressure build up. Therefore use the gasket provided in the mounting kit.

  • Page 24: Is Power Supply Unit Mains Voltage Default Setting

    Gill Instruments Ltd IS Power Supply Unit Mains Voltage Default Setting The IS Mains Operated Power Supply Unit is shipped set for 230v AC operation and will not self-adjust for 115 AC operation. If 115v AC operation is required then set the internal slide switch to the 115V setting.

  • Page 25: Connection To A Pc Or Other Device

    Gill Instruments Ltd CONNECTION TO A PC OR OTHER DEVICE Connection to a PC or other device requires the use of: 1) The specified Intrinsically Safe Power Supply Unit Interface – MUST BE USED UNDER ALL CIRCUMSTANCES, CERTIFICATION DEPENDS UPON THIS.
  • Page 26 Gill Instruments Ltd Connecting to a Gill WindDisplay using an RS422 Connection Maximum suggested RS422 approved twisted pair screened cable length is 1000 Metres. Refer to the WindDisplay User Manual for the method of operation. Intrinsically Safe Power Supply Box...

  • Page 27: Using The Anemometer With A Computer And Software

    Gill Instruments Ltd USING THE ANEMOMETER WITH A COMPUTER AND SOFTWARE This section describes the modes and format of the data output by the anemometer. On first applying power to the WindObserver, it will be in ‘Measurement Mode’, and it will output wind measurement information within 3 seconds in one of the formats as described below.

  • Page 28: Digital Serial Output Formats

    Gill Instruments Ltd Digital Serial Output Formats The following data modes are available from the serial output of the anemometer:- Mode 1 ASCII, UV, Continuous A,+000.00,+000.01,M,00,21 Fault free conditions. A,,,M,04,24 Fault report condition with CSV setting (O1). A,+999.99,+999.99,M,04,24 Fault report condition with Fixed Field setting (O2).
  • Page 29 Gill Instruments Ltd Mode 3 ASCII, UV, Polled A,+000.00,+000.01,M,00,21 Fault free conditions. A,,,M,04,24 Fault report condition with CSV setting (O1). A,+999.99,+999.99,M,04,24 Fault report condition with Fixed Field setting (O2). Where: <STX><ID>,±UUU.UU,±VVV.VV,U,SS,<ETX>CC<CR><LF> <STX> Start of string character (ASCII value 2) <ID>...
  • Page 30 Gill Instruments Ltd Mode 5 ASCII, NMEA, continuous $IIMWV,262,R,000.84,M,A*1A Fault free conditions. $IIMWV,,R,,M,V*29 Fault report condition with CSV setting (O1). $IIMWV,999,R,999.99,M,V*07 Fault report condition with Fixed Field setting (O2). Where: $IIMWV,DDD ,R,MMM.MM,U,A,*cc<CR><LF> ‘$’ Start of string character ‘II’ Integrated instrument (or WI = Wind Instrument) ‘MWV’...
  • Page 31 Gill Instruments Ltd Mode 7 Binary UV Short Continuous In a terminal program the Binary output will look like:- Converted it will read like:- 0x81 0x81 +000.04 -000.02 00 1 <STX>,UUU.UU, VVV.VV,SS,U<ETX><CR><LF> Where:- <STX> Start of string character (ASCII value 2) UUU.UU...
  • Page 32 Gill Instruments Ltd Mode 13 ASCII Tunnel Polled A,000.00,1,00,M,0F Fault free conditions. A,,1,04,M,15 Fault report condition with CSV setting (O1). A,999.99,1,04,M,02 Fault report condition with Fixed Field setting (O2). <STX>,ID,MMM.MM, P,SS,U<ETX><CR><LF> Where:- <STX> Start of string character (ASCII value 2) <ID>...
  • Page 33 Gill Instruments Ltd Mode 15 ASCII Continuous Road Weather Average (RWA) With default factory RWA unit settings then upon switch on by default it will take 60 seconds before outputting the first reading and thereafter a reading will occur once per minute.
  • Page 34 Gill Instruments Ltd Modes 14 and 15 Road Weather Averaging Notes. The averaging is implemented with reference to the following standard: Guide to Meteorological Instruments and Methods of Observation – World Meteorological Organization WMO-No8 seventh edition 2008 ISBN 978-92-63- 10008-S.
  • Page 35 Gill Instruments Ltd Therefore if the RWALONG number is 10 (default) and Averaged Data Output Period is 60 seconds, then the rolling averaged Direction and Magnitude data is calculated over rolling 600 readings. Whenever the unit is powered up then until the unit has reached its minimum long term averaging interval the status code will read 51 (Measurement Average Building).
  • Page 36 Gill Instruments Ltd Mode 14 – Averaging Polled Mode See Mode 15 for data output format and command explanations. For ease of use before changing to this Mode set all other WindObserver parameters first including:- Px:- Measurement Rate, (P1 to P4) this command sets the underlying measurement rate from 1Hz to 4Hz.

  • Page 37: Digital Format Notes

    Gill Instruments Ltd Digital Format Notes ASCII Polled Modes (Mode 3 UV, 4 Polar, 13 Tunnel and 14 RWA). When in the Polled mode, an output is only generated when the host system sends a Poll signal to the WindObserver consisting of the WindObserver Unit Identifier – that is, the relevant letter A –...
  • Page 38 Gill Instruments Ltd G Command Averaging. Using the G Command in association with modes other than M14, M15 and polled modes. The Averaging Period can be set from zero to 3600 secs. (1 hour). The default setting is zero. When averaging is enabled, data is output at a rate determined by the averaging period.

  • Page 39: Status Codes

    Gill Instruments Ltd Status Codes A two character ‘Status code’ will be transmitted in the serial string. This value will denote the system and measurement status. The codes are: Code 00 - O.K. This indicates that the system is operating correctly. The transducers signals are within the required limits and no memory faults have occurred.

  • Page 40: Anemometer Software Commands

    Gill Instruments Ltd ANEMOMETER SOFTWARE COMMANDS The Intrinsically Safe WindObserver can be configured using Terminal emulator software such as HyperTerminal. Alternatively it is possible to use Gill Wind Software as a Terminal program only (Wizard and Sync Comms not applicable). Wind will run on PC’s up to and including Windows 8 and can be downloaded from:- http://www.gillinstruments.com/main/software.html.
  • Page 41 Gill Instruments Ltd 6. Adjust the Port settings to match WindObserver settings. WindObserver default settings are : Bits per second 9600 Data bits None Parity Stop bits None Flow Control Click on OK and data similar to the following example will scroll on screen at the output rate: The WindObserver should be outputting data as per the following screen.
  • Page 42 Gill Instruments Ltd Entering Configuration mode From Continuous mode From Polled mode Type * - where N is the Unit Identifier. Type *N Note - the Unit Identifier must be entered as upper-case The Intrinsically Safe WindObserver responds with a CONFIGURATION MODE message, stops reporting wind measurements, and waits for a command (as detailed below).
  • Page 43 Gill Instruments Ltd Returning to Measurement mode Type Q and press ENTER key If in Continuous mode, the anemometer responds with wind measurements immediately, continuing at the selected Sampling rate. If in Polled mode:- Enables poll Polls anemometer (where N is the Unit identifier entered as upper-case)

  • Page 44: Configuration Settings

    Gill Instruments Ltd Changing settings To change a setting, first go into Configuration mode and then refer to the sections below. Enter the Configuration code of the new setting required, followed by press ENTER key If successful, the new setting will be echoed back as a message by the Intrinsically Safe WindObserver.
  • Page 45 Gill Instruments Ltd Dx- Diagnostic and Configuration Command Each of these commands causes a response from the Intrinsically Safe WindObserver. Command Item Typical response code Type and serial No. I03000 Software version 1.032 Current configuration: Unit configuration B3 F1 G0000 K1 L1 M2 NA O1 P1 U1 V1 X1...
  • Page 46 Gill Instruments Ltd Mx to Mxx - Message Format Output format Configuration code ASCII UV Continuous ASCII Polar Continuous ASCII UV Polled (tri-state) ASCII Polar Polled (tri-state) NMEA Continuous Binary Tunnel Continuous Binary UV Continuous Binary Polar Continuous ASCII Tunnel Continuous...
  • Page 47 Gill Instruments Ltd Q- Returning to Measurement Mode (see page 42) Road Weather Averaging Settings RWASHORT XX (Short term number) Where XX = 10 to 60, associated with Mode 14 and Mode 15 averaging. RWALONG XX (Long term number) Where XX = 1 to 10, associated with Mode 14 and Mode 15 averaging.

  • Page 48: Maintenance & Fault-Finding

    Gill Instruments Ltd 10. Maintenance & fault-finding 10.1 Cleaning and Handling When installing the unit handle with lint free gloves and degrease the unit to reduce the build-up of deposits. If there is any build-up of deposit on the unit, it should be gently cleaned with a cloth, moistened with soft detergent.

  • Page 49: Safe Mode

    Gill Instruments Ltd 10.4 Safe Mode If a unit is received that will not communicate or the configuration settings are not known then Safe Mode can be used to establish communication with the IS WindObserver and change configuration settings. Initial Set Up.

  • Page 50: Status (Error) Codes

    Gill Instruments Ltd Change settings if required referring to the previous configuration details. Type Q and press Enter to go back into measurement mode. If powering down the instrument and repowering and no change has been made to the baud rate (B command ) then open a new terminal program at the units original baud rate setting (the default setting would be 9600 Bauds to view data).

  • Page 51: Bench Tests

    Gently hold the anemometer cylinder and then see if it is possible to feel the Anemometer rock on the transducers. If this occurs then it is likely the transducer arms are misaligned requiring return to Gill Instruments for re- alignment.
  • Page 52 Gill Instruments Ltd When the IS Power Supply is powered up the +5v SAFE and +5v HAZ LED’s will be illuminated. HAZ LED SAFE LED Data Tests With the Sensor connected and outputting data to the PCI box. Examine the Main PCB and the Red RX LED at the bottom left of the PCB will be seen to flash on and off at the sensor output rate (1Hz to 4Hz).
  • Page 53 Gill Instruments Ltd With the Sensor connected and outputting data to the PCI box. Check that the unit is correctly configured by going into Configuration mode and using (See Page 37). If a HyperTerminal connection is established to change the sensor configuration then when a PC keystroke is undertaken then the PCI box Red Tx LED at the top right on the PCB will be seen to momentarily flash on and off.
  • Page 54 If there has been no significant changes to the IS WindObserver head configuration then *PASS* will confirm correct operation. Alterations to the head geometry can result in a *FAIL* or ‘Insufficient Samples’ message. If this occurs please contact Gill Instruments. Intrinsically Safe WindObserver Anemometer Page 54 Issue 10 Doc.

  • Page 55: Connections And Tests With The Low Voltage Supply Unit

    Gill Instruments Ltd 10.6.3 Connections and tests with the Low Voltage Supply Unit Couple the Intrinsically Safe WindObserver to the power supply unit using a known working test cable (The 3 metre test cable connections to terminal block J5 are shown following).
  • Page 56 Gill Instruments Ltd Anemometer Supply Voltage and Current With the LVPCI box powered, the Supply Voltage between J5 Terminal 8 +ve and Terminal 7 (-ve) must be between 6v dc to 12v dc. Typically 9v dc. (If the supply voltage exceeds 12 v dc damage to the Anemometer might result).
  • Page 57 Gill Instruments Ltd With the Sensor connected and outputting data to the PCI box. 1. Check that the unit is correctly configured by going into Configuration mode and using , see Page 37. If a HyperTerminal connection is established to change the sensor configuration then when a PC keystroke is undertaken then the PCI box Red Tx LED on the PCB will be seen to momentarily flash on and off.

  • Page 58: Returning Units

    *PASS* will confirm correct operation. Alterations to the head geometry can result in a *FAIL* or ‘Insufficient Samples’ message. If this occurs please contact Gill Instruments. 10.7 Returning Units If the unit has to be returned, it should be carefully packed in the original packaging and returned to your authorised Gill distributor, with a full description of the fault condition.

  • Page 59: Drawings

    Gill Instruments Ltd 11. DRAWINGS 11.1 Mains Power Supply Drawing 1360-M-039 Issue 3, I.S.Terminal Arrangement. Intrinsically Safe WindObserver Anemometer Page 59 Issue 10 Doc. No. 1360-PS-0001 May 2015...

  • Page 60: Mains Power Supply Drawing 1360-G-043 Issue 2 I.s. Pci Unit

    Gill Instruments Ltd 11.2 Mains Power Supply Drawing 1360-G-043 Issue 2 I.S. PCI Unit VIEW OF PCI WITH LID OPEN GLAND PLATE The Gland plate may be removed to allow fitting of customer supplied cable glands. Gland plate screws should be torqued to 4NM.

  • Page 61: Low Voltage Power Supply Drawing 1954-30-023 Issue 2 Terminal Arrangement

    Gill Instruments Ltd 11.3 Low Voltage Power Supply Drawing 1954-30-023 issue 2 Terminal Arrangement. Intrinsically Safe WindObserver Anemometer Page 61 Issue 10 Doc. No. 1360-PS-0001 May 2015...

  • Page 62: Summary Of Abbreviations Used In This Manual

    Gill Instruments Ltd APPENDIX 1 SUMMARY OF ABBREVIATIONS USED IN THIS MANUAL Alternating Current ANEM Anemometer ASCII American Standard Code for Information Interchange Carriage Return Comma Separated Variable Cross Sectional Area Clear To Send Direct Current Data Carrier Detect Direction parameter...
  • Page 63 Gill Instruments Ltd SECond Static Random Access Memory Start of string character SoftWare Transmit Cartesian Co-ordinate System Volts positive Voltage negative Voltage VoltAmperes Intrinsically Safe WindObserver Anemometer Page 63 Issue 10 Doc. No. 1360-PS-0001 May 2015...

  • Page 64: Product Approvals

    Gill Instruments Ltd APPENDIX 2 PRODUCT APPROVALS SIRA ATEX CERTIFICATION 1. Certificate Number: Sira 00ATEX2217 Issue 8 for the IS WindObserver Power Supply Unit 1360. 2. Certificate Number: Sira 15ATEX2014 Issue 0 for the model 1360 IS II Anemometer. 3. Certificate Number: Sira 13ATEX2384 Issue 1 for the IS Low Voltage Power Supply and Communications Unit 1954-00-002.

  • Page 65: Doc. No. 1360-Ps-0001 May

    Gill Instruments Ltd Certificate Number: Sira 00ATEX2217 for the IS WindObserver Power Supply Unit 1360. Intrinsically Safe WindObserver Anemometer Page 65 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 66 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 66 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 67 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 67 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 68 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 68 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 69 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 69 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 70 Gill Instruments Ltd Certificate Number: Sira 15ATEX2014 for the model 1360 IS Anemometer. Intrinsically Safe WindObserver Anemometer Page 70 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 71 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 71 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 72 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 72 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 73 Gill Instruments Ltd Certificate Number: Sira 23ATEX2384 for the IS Low Voltage Power Supply and Communications Unit 1954-00-002. Intrinsically Safe WindObserver Anemometer Page 73 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 74 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 74 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 75 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 75 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 76 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 76 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 77 Gill Instruments Ltd Certificate Number: Sira IECEx SIR 13.0156 for the IS WindObserver Power Supply Unit 1360. Intrinsically Safe WindObserver Anemometer Page 77 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 78 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 78 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 79 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 79 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 80 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 80 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 81 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 81 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 82 Gill Instruments Ltd Certificate Number: Sira IECEx SIR 15.0013 for the model 1360 IS Anemometer. Intrinsically Safe WindObserver Anemometer Page 82 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 83 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 83 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 84 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 84 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 85 Gill Instruments Ltd Certificate Number: Sira IECEx SIR 13.0159 for the IS Low Voltage Power Supply and Communications Interface 1954-00-002. Intrinsically Safe WindObserver Anemometer Page 85 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 86 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 86 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 87 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 87 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 88 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 88 Issue 10 Doc. No. 1360-PS-0001 May 2015...
  • Page 89 Gill Instruments Ltd Intrinsically Safe WindObserver Anemometer Page 89 Issue 10 Doc. No. 1360-PS-0001 May 2015...

  • Page 90: Appendix 3 Electrical Conformity

    Gill Instruments Ltd APPENDIX 3 ELECTRICAL CONFORMITY EC Declaration of Conformity Gill Instruments Limited Saltmarsh Park 67 Gosport Street Lymington SO41 9EG England in accordance with the following Directives: 94/9/EC ATEX Equipment Directive 2004/108/EC EMC Directive 2006/95/EC Low Voltage Directive (Mains Power Supply only)
  • Page 91 [Ex ia Da] IIIC (Ta = -30⁰C to +40⁰C) Signed by A.C.R. Stickland – Director Date of issue: 26/05/2015 Place of issue: Gill Instruments Limited, Lymington. Change Note: 8446 Doc:1360-0021 Date: 26th May. 2015 Intrinsically Safe WindObserver Anemometer Page 91 Issue 10 Doc.
