SunBriteTV Veranda SB-4374UHD-BL Quick Start Manual

Planning the Location

Sources/What to Watch

ETHERNET
OPTICAL
(10/100)
L R
ETHERNET DIGITAL ANALOG
RJ45 terminal for AUDIO OUT AUDIO OUT
service only terminal terminal

Weather Proofing

Veranda Outdoor Television
Quick Start Guide SB-4374UHD-BL, SB-5574UHD-BL, SB-6574UHD-BL
Rear IR
USB 1
USB 2
HDMI 1 terminal
HDMI 2 terminal
HDMI 3 terminal
ARC: Audio Return Channel
HDMI 4 terminal
MHL: Mobile High-Definition Link
COMPONENT/VIDEO DTV/TV
Y/Y Pb/Cb Pr/Cr L AUDIO R CABLE/AMTENNA
COMPONENT/ CABLE/ANTENNA IN
VIDEO IN terminal* 4
Thumb Screws
Media Bay
Wires
Place the Veranda only in a fully shaded area.
• Signals can be sent from any source using
an HDMI, Component, or digital antenna
connection.
• Refer to the operator's manual for detailed
instructions.
• After all connections are made, all wires
must exit the media bay from the bottom.
• Up to 5 wires can exit the media bay while
still maintaining the weatherproof feature.
Note: Leave a drip loop as the wires enter the
compartment.
• Tighten the thumb screws completely to
weatherproof the TV.
Drip Loop
