Summary of Contents for SunBriteTV Pro 2 1K Series
- Page 1 Operator’s Manual Pro 2 Series 1K/4K Model SB-P2-32-1K SB-P2-43-1K SB-P2-49-4K SB-P2-55-4K SB-P2-65-4K Revision 20200604_0800 PN: MSP-002-00...
- Page 2 CA Prop65 Warning Recycling Programs For California, Connecticut, Hawaii, Illinois, Indiana, Maine, Maryland, Michigan, Minnesota, Missouri, North Carolina, New Jersey, New York, Oklahoma, Oregon, Pennsylvania, Rhode Island, South Carolina, Texas, Utah, Virginia, Vermont, Washington, Washington D.C., Wisconsin, and West Virginia Consumers Only: For the recycling of SunBrite brand TV’s and other brand TV’s, please contact customer service at 866-357-8688 for details.
-
Page 3: Important Safety Instructions
Dear SunBriteTV Customer: Congratulations on the ownership of your SunBriteTV all-weather outdoor LCD TV, and welcome to the family of satisfied SunBrite customers. You are in great company, with thousands of homeowners and esteemed commercial facilities such as Yankee Stadium, Fenway Park, Disney World, and Sea World who have trusted us to deliver superior performance, lasting durability and the enjoyment of superb television viewing in the great outdoors. - Page 4 Power Source: SunBriteTV must operate on a power source indicated on the specification label. If you are not sure of the type of power supply used in your home, consult your dealer or local power company. When using the TV outdoors, you must use a GFI- protected AC outlet with “in-use”...
- Page 5 However, it is not designed to withstand pressure washers, high-pressure water jets, or hurricane-type weather. Do not service SunBriteTV yourself: Removal of the television screen cover may expose you to high voltage or other dangerous risks. Refer all servicing to a qualified service professional. Warranty will not be honored if you service the unit yourself.
-
Page 6: Table Of Contents
Time Menu Lock Menu Option Menu Media Menu Information Menu Troubleshooting Care of SunBriteTV - Filter cleaning Specifications Features Information and Instructions Extreme Climate Warning Programming Other Manufacturers’ Universal Remote Control Devices SunBriteTV Pixel Quality Policy Appendix A - RS232 Cable Pinout... -
Page 7: Supplied Accessories
Supplied Accessories Unpacking After unpacking the SunBriteTV television, please make sure that the following items are included in the carton and that they are in good condition. If items are damaged or missing, contact your dealer immediately. SunBriteTV LCD Television Operator’s Manual... -
Page 8: Tv Installation
LCD panel, and will not cause damage to the screen. Either turn the screen away from the sun, or apply shade to the TV, and the dark areas will quickly disappear. SunBriteTV Pro 2 Series Operator’s Manual Page 7... - Page 9 TV Installation – Rear Panel Internal Connect Source - Cable routing WARNING: Do not connect the power source before making connections. Internal Connect Source through the cable access door. The Internal Connect Source allows you to easily connect to the Audio, Video, VGA, HDMI, Audio Out, and RF connectors. The internal connect Source are inside the cable cover located on the back of the unit (Figure1).
- Page 10 Connections See next page 5 pin din jack - SunBriteTV optional speaker bar connection output. Direct IR input 3.5mm Jack IR WINDOW - Rear IR receiver, allows IR emitter to be installed inside the cable compartment. RS232 - 3.5mm Stereo Jack - For remote control using RS232 commands.
- Page 11 18. Emitter port - Connect an emitter to control the SunbriteTV through the HDBaseT compatible transmiter which supports IR repeating. 19. Option Switches- reserved for future use. Swith settings do not effect the HDBaseT operation at this time.
- Page 12 TV Installation – Rear Panel Connections Cable Descriptions: Connection Descriptions: Green Blue Yellow Green White Legacy component input, 3.5mm to RCA cable required for, not included SunBrite Part Number CBL-35MM-COMP SunBriteTV Pro 2 Series Operator’s Manual Page 11...
- Page 13 TV Installation – Rear Panel Connections Switching Sources for Ports: Your SunBrite TV offers several options when connecting your devices to the TV. The chart below will help you understand which source you switch to for each of the ports. CONNECTING TO AN ANTENNA Connecting to Digital Cable without Cable Box or Antenna Connecting to Cable or Antenna...
-
Page 14: Rear Panel Connection Diagrams
This TV does not decode Bit stream digital audio, so make sure the DVD is setup for PCM digital audio through HDMI. If HDMI 1 is occupied, use HDMI 2 as your connection port. SunBriteTV Pro 2 Series Operator’s Manual Page 13... - Page 15 TV Installation – Rear Panel Connection Diagrams CONNECTING TO A DVD PLAYER (Continued) Connecting with Composite (Fair) Make sure the power of the TV and your DVD player is turned off. Obtain a Yellow Video Cable. Connect the Yellow Video connector to both your DVD player and Composite’s Yellow Video connector port off the back of your TV.
- Page 16 TV. This model supports SONY’s universal remote code. If SunBriteTV is not listed, please look up SONY’s codes in your universal remote’s hand book. This TV will turn off automatically if there’s no signal present for more than 15 minutes.
- Page 17 TV. This model supports SONY’s universal remote code. If SunBriteTV is not listed, please look up SONY’s codes in your universal remote’s hand book. This TV will turn off automatically if there’s no signal present for more than 15 minutes.
- Page 18 The TV will turn off automatically if there’s no signal present for more than 15 minutes. If HDMI 1 is already occupied, use HDMI 2 as your connection port, and switch source to HDMI 2. Continued on next page SunBriteTV Pro 2 Series Operator’s Manual Page 17...
- Page 19 TV Installation – Rear Panel Connection Diagrams CONNECTING TO A PC (Continued) Make sure the power of the TV and your PC is turned off. Connecting with VGA Analog (Good) Obtain a 15-pin D-Sub VGA cable, connect to the VGA output of your PC and the other end to the VGA port off the back of your Obtain a 3.5 mm Mini-jack, connect to the audio out of your PC and the other end to the VGA Stereo Input port.
- Page 20 If the OSD is active, Vol+/Vol- is used to select the highlighted options. Front Panel IR Sensor LED power indicator Ambient light sensor SunBriteTV Pro 2 Series Operator’s Manual Page 19...
-
Page 21: Remote Control Guide
The functionality of the remote control is under warranty for one year. If the remote control malfunctions within the one-year warranty period, replace the batteries with new long-life alkaline batteries. If the problem is not solved with new batteries, contact the SunBriteTV Customer Care Center. SunBriteTV will repair or replace the remote control at SunBriteTV’s option. - Page 22 OSD. This button opens the OSD and also exits the OSD by going to the previous level of the OSD. This button exits the OSD entirely. SunBriteTV Pro 2 Series Operator’s Manual Page 21...
-
Page 23: Channel Menu
On-Screen Display Menu Your TV has been factory-set to plug-in and enjoy your programming. In the event you turn on the TV and get the message, “Please run Channel Auto Scan, ” press your remote’s Menu button, press the Channel function and press Auto Scan. Note: To run the Channel function, you must be in the TV Source. -
Page 24: Sound Menu
Time Format OSD Active Time Lock Menu This menu manages Lock functions including: Lock System Change password (default password is 0000) Input Block Canada Rating RRT Setting RRT Reset Block Rated TV SunBriteTV Pro 2 Series Operator’s Manual Page 23... -
Page 25: Option Menu
On-Screen Display Menu (continued) Option Menu (page 1 of 2) This menu manages Setup functions including: Menu Language Transparency (menu) Energy Mode CEC Control HDMI EDID Color Range Network Configuration Network Upgrade Local Dimming IMCP Enable Option Menu (page2 of 2) This menu manages Setup functions including: Quick Start Mode... - Page 26 Press menu to interupt the learning process, learned channels will be stored. Highlight those channels which you do not wish to keep, have poor signal or are scrambled and hide them from the channel selections. SunBriteTV Pro 2 Series Operator’s Manual Page 25...
- Page 27 Adjusting On-Screen Displays – Channel Menu (continued) Channel Edit Press the qp buttons to highlight the desired channel and Press <enter> The channel will be displayed Using the Addq button on the remote you can change the text name of the learned channel. Using the Deletep button on the remote you can skip the channel when using Ch +/-.
- Page 28 <enter>, then use qp to select Off, Auto, Low, Middle or High. Overscan Press the qp buttons to highlight Overscan, press <enter>, then use qp to select Off, On. * Menu function may not be available on all inputs. SunBriteTV Pro 2 Series Operator’s Manual Page 27...
- Page 29 Adjusting On-Screen Displays – Sound Menu 1. Press qp buttons on the remote or CH+/CH- on the TV) to move the cursor to the item to be selected. 2. Press t u buttons on the remote or VOL+/VOL- on the TV to make the desired adjustments. 3.
- Page 30 Press the qp buttons to highlight the OSD Active time adjustment, then use t u to select the amount of time the OSD menus will display before timing out, 5s, 10s, 15s, 20s or always On. SunBriteTV Pro 2 Series Operator’s Manual Page 29...
- Page 31 Adjusting On-Screen Displays – Lock Menu 1. Press qp buttons on the remote or CH+/CH- on the TV) to move the cursor to the item to be selected. 2. Press t u buttons on the remote or VOL+/VOL- on the TV to make the desired adjustments. 3.
- Page 32 EDID 1.4 should be used for older devices or with 4k extenders or cables which are limited to 4k @ 30hz. EDID 2.0 should be used for newer source devices for full 4k @ 60hz resolution SunBriteTV Pro 2 Series Operator’s Manual Page 31...
- Page 33 Adjusting On-Screen Displays – Option Menu (continued) Color Range Press the qp buttons to highlight Color Range, then use <enter> to select Auto, 16-235, or 0-255. Auto, the TV will select color range based on the input and source content. 0-255, typically used for PC content 16-235, typically used for TV content Network Configuration...
- Page 34 Press the qp buttons to highlight the Restore Factory Default, then use <enter> to select on. Use t u to select Yes or No, then press <enter>. This will restore all the user settings to their defaults. SunBriteTV Pro 2 Series Operator’s Manual Page 33...
- Page 35 Adjusting On-Screen Displays – Option Menu Page 2 (continued) Ambient Light Sensor Note the Ambient sensor function is only available when the User Picture mode is selected. Press the qp buttons to highlight the Ambient Light Sensor adjustment, then use t u to turn the ambient light sensor on and off.
- Page 36 During playback a menu will appear at the bottom of the screen Use t u to highlight the fuction, then press These functions allow repeat play, pause, rotate and zoom. SunBriteTV Pro 2 Series Operator’s Manual Page 35...
- Page 37 Menu - Media MP3 Audio Accessing the USB input Press the Menu button on the remote or on the side control panel of the TV, then press qp buttons to highlight Media and press <enter>. Select Music or Photo and press <enter> If a USB flash drive can be accessed by the TV it will display as shown, press <enter>...
- Page 38 Above items cannot be changed on this menu and are for service and reference only. Software Update(USB) Use this feature as instructed by technical support to update the TV firmware using a USB flash drive. SunBriteTV Pro 2 Series Operator’s Manual Page 37...
-
Page 39: Troubleshooting
This is common to all LCD screens used in display and television products, and is not specific to SunBriteTV. For more information, Picture is too dark Adjust your contrast, brightness and backlight settings from the OSD menu see SunBriteTV’s Pixel Quality Policy in this manual. - Page 40 (do not spray the solution directly on the panel) and gently clean the panel. 2. When the TV is not in use, keep it covered with the SunBriteTV Outdoor Dust Cover: The fitted dust cover is designed to protect the LCD panel from the harmful UV rays from direct sunlight, and keeps wind- blown objects from scratching the surface of the panel.
-
Page 41: Specifications
Specifications Model SB-P2-32-1K Pro 2 Series Full HD LCD Screen 32-inch diagonal Color Active Matrix TFT LED LCD Dimensions Resolution 1920 x 1080 FHD (4k input scaled to 1080p) Aspect Ratio 16:9 Blacklight Brightness 1500 nits (cd/m2) Side View - Surface Luminance, Front View white Contrast Ratio... - Page 42 Shipping 51 lbs (23.1 kgs) Residential Warranty Two year, in-factory, parts and labor Commercial Warranty Two year, in-factory, parts and labor Mount Pattern 200mm x 200mm Specifications are subject to change. 04/19/2020 SunBriteTV Pro 2 Series Operator’s Manual Page 41...
- Page 43 Specifications LCD Screen 49-inch diagonal Color Active Matrix TFT LED LCD Model SB-P2-49-4K Pro 2 Series 4K Ultra HD Dimensions Resolution 3840 x 2160 UHD 4k Aspect Ratio 16:9 Blacklight Brightness 1000 nits (cd/m2) Front View Side View - Surface Luminance, white Contrast Ratio 4000:1...
- Page 44 Shipping weight 108 lbs / 49kgs Residential Warranty Two year, in-factory, parts and labor Commercial Warranty Two year, in-factory, parts and labor Mount Pattern 400 mm x 400 mm Specifications are subject to change 04/19/2020. SunBriteTV Pro 2 Series Operator’s Manual Page 43...
- Page 45 Specifications Model SB-P2-65-4K Pro2 Series 4K Ultra HD LCD Screen 65-inch diagonal Color Active Matrix TFT LED LCD Dimensions Resolution 3840 x 2160 UHD 4k Aspect Ratio 16:9 Blacklight Brightness 1000 nits (cd/m2) Front View Side View - Surface Luminance, white Contrast Ratio 4000:1...
-
Page 46: Features Information And Instructions
Programming Other Manufacturers’ Universal Remote Control Devices When programming a DirectTV, local cable universal remote control or Control system, you may find that SunBriteTV may not be on the list of TV manufacturers. If that is the case, your SunBriteTV supports SONY’s universal remote code. -
Page 47: Appendix A - Rs232 Cable Pinout
Follow instructions on page 8 to close the cable door. * Neither the emitter or control block are supplied by Place IR Emitter Cable SunBriteTV. See instructions that come with your IR over the bottom of the Emitter and control block to determine how to make the cable door. -
Page 48: Appendix B - Rs232 Control Codes
Picture Mode 3 - SunBrite Day [ESC]R 1B 52 Picture Mode 4 - Sunbrite Night [ESC]S 1B 53 * input 7 and 8 are out of letter sequence to remain SunBriteTV Pro 2 Series Operator’s Manual Page 47 compatible with legacy SunBrite RS232 commands... - Page 49 Page 48...
