SunBriteTV Signature SB-S-XX-4K Series Quick Start Manual

Planning the Location
Sources/What to Watch
5V DC 3.5A Max
Aux Power
Service Port
Analog Audio
Out
12V DC
RS-232
Input
Speaker
Out
Rear IR
Receiver
HDMI 1: ARC/MHL
HDMI 2: MHL
Weather Proofing
Signature Outdoor Television
Quick Start Guide SB-S-XX-4K
1.3mm ID x
3.8mm OD
AV1/Video
VGA
1 2
ON
S-Video ATSC/
VGA Stereo NTSC Tuner
Digital
Input
Audio Out
Component 1-2: Video In
Thumb Screws
Media Bay
Wires
Place the Signature in a partially shaded area
• Signals can be sent from any source using
an HDMI, Component, Ethernet, or digital
antenna connection.
• Refer to the operator's manual for detailed
instructions
IR RCVR PWR
Off/On
IR Flasher
HDBaseT
• The Signature is equipped with an
HDBaseT receiver in the media bay
• After all connections are made, all wires
must exit the media bay from the bottom.
• Up to 5 wires can exit the media bay while
still maintaining the weatherproof feature.
Note: Leave a drip loop as the wires enter the
compartment.
• Tighten the thumb screws completely to
weatherproof the TV.
Drip Loop
