Function Overview

Visual Representation of Z Axis or Ladder Tilt

This visual shows the degree of change required to initiate the alarm when the tilt
of the ladder changes.
NOTE: This representation is not to scale and is for a visual reference only
Wall
1
5º-14º
Side
Ladder
View
After Sales Support
1300 663 907
1.5º
2
1.5º
3
2.7º
customercare@winplus.com.au
1
2
2.7º 3
Model Number DY160121
5º-14º
Flashing Green
Change of 1.5º
from set position
Two Flasing Red Lines
Rapid Beep
Change of 2.7º
from set position
Two Solid Red Lines
Constant Alarm
