2. S 900 C / S 900 M / S 900 P Handheld Transmitter
2.1 Controls and Indicators
There are different condenser and dynamic microphone capsules for the handheld transmitter
(refer to Optional Accessories).
The S 900 C handheld transmitter has charging contacts and can be operated with the integrated
rechargeable battery pack only. Avoid a direct contact of the charging contacts to the skin, as there is
a voltage of 3 V at maximum.
S 900 C
1
Microphone capsule (can be unscrewed)
1
LC-Display
2
Infrared diode (at the bottom of the transmitter)
3
On/Off switch (at the bottom of the transmitter)
4
Charging contacts (at the bottom of the transmitter S 9xx C only )
5
S 900 M / S 900 P
1
Microphone capsule (can be unscrewed)
1
2 LC-Display
Infrared diode (on the rear)
3
On/Off switch
4
2
2 3
3
5
4
4
63
