Johnson Controls DRCR Owner's Manual page 9

Wireless Remote Controller DRCR
No. Name
Signal
1
Transmitter
ON/OFF
2
Button
MODE
3
Button
- Button
4
+ Button
5
FAN Button
● Signal transmitter
● Press this button, and the unit will be turned on; press it once more, and the
unit will be turned off. When turning off the unit, the Sleep function will
be canceled, but preset time is still enabled.
● Pressing this button, Auto, Cool, Dry, Fan, and Heat mode can be selected
sequentially. Auto mode is the default after powered on. Under the Auto
mode, the setting temperature will not be displayed. Under the Heat
mode, the initial value is 82°F (28°C). Under other modes, the initial value
is 77°F (25°C).
AUTO ; COOL;
● Preset temperature can be decreased by pressing this button. Pressing
and holding this button for more than 2 seconds will decrease the preset
temperature rapidly. When the button is released, the setting will be
transmitted. The temperature adjustment is unavailable under the Auto
mode, but the order can be sent by pressing this button. Centigrade
setting range: 16°- 30°. Fahrenheit scale setting range: 61°- 86°.
● Preset temperature can be increased by pressing this button. Pressing and
holding this button for more than 2 seconds will increase the preset
temperature rapidly. When the button is released, the setting will be
transmitted. The temperature adjustment is unavailable under the Auto
mode, but the order can be sent by pressing this button. Centigrade
setting range: 16°- 30°; Fahrenheit scale setting range: 61°-86°.
● By pressing this button, Auto, Low, Middle, High speed
selected. After powered on, Auto fan speed is the default.
AUTO
●
Low speed
Middle speed
High speed
Note: Under the DRY mode, the fan will be kept running at the low speed
and the fan speed isn't adjustable.
Function Description
DRY; FAN; HEAT (only for cooling and heating unit)
2
is sequentially
