Wireless Remote Controller DRCR
TEMP
10
Button
TIMER
11
OFF Button
TURBO
12
Button
SLEEP
13
Button
LIGHT
14
Button

3 Additional Functions

● X-FAN function (This function is applicable to select models.)
This function is used to keep the fan running on the indoor unit to remove moisture from
the evaporator coil.
With X-FAN function ON: After turning off the unit by pressing the ON/OFF button, the
①
indoor fan will continue running for several minutes at low speed. In this period, press the X-FAN
button to stop the indoor fan.
With X-FAN function OFF:After turning off the unit by pressing the ON/OFF button,
②
the unit will shut off immediately..
● TURBO function (This function is applicable to select models)
If the TURBO function is activated, the unit will run at high fan speed to perform cooling or
● Pr essing this button will toggle the temperature displayed on the remote
between the indoor setting temperature and the indoor temperature.
● Indoor setting temperature is default after the indoor unit is initially
powered up.
● By pressing the TEMP button, when the temperature symbol
is displayed, the indoor setting temperature is displayed.
When is displayed, the indoor temperature is displayed.
When is displayed, there is an error with the temperature sensor.
If a TEMP signal from another remote is received, the preset temperature
will be displayed. After 5 seconds, the display will return to the indoor
temperature. (This function is not applicable to all models.)
● By pressing this button, the TIMER OFF settting can be set with the
same setting method as that of the TIMER ON, in which case the OFF
symbol blinks.
● In the Cool or Heat mode, pressing this button can activate or deactivate
the TURBO function.When the TURBO fucntion is activated, its symbol
will be displayed; when the running mode or the fan speed is
changed, this function will be canceled automatically.(This function is
not applicable to all models).
● By pressing this button, Sleep On and Sleep Off can be selected. Upon
initial power up, the SLEEP function is defaulted to OFF. Once the unit is
turned off, the Sleep function is canceled. When Sleep is set to On, the
symbol will display.
● Press this button to toggle the display backlight ON/OFF.
LIGHT is set to on, the icon
in the display will be on. When the LIGHT is set to off, the
will not be displayed and the indicating light in the display will be off.
will be displayed and the indicating light
4
icon
