- Page 1 Wireless Remote Controller MODEL DRCR Owner's Manual User Notice Please read this Owner's manual carefully before operation and retain it for future reference.
- Page 2 Important Notice ● Johnson Controls, Inc. pursues a policy of continuing improvement in design and performance in its products. As such, Johnson Controls, Inc. reserves the right to make changes at any time without prior notice. ● Johnson Controls, Inc. cannot anticipate every possible circumstance that might involve a potential hazard.
-
Page 3: Table Of Contents
Table of Contents 1 Introduction and Safety Summary.............i 2 User Notice ....................1 3 Control Panel of the Wireless Remote .............1 4 Additional Function s.................4 5 Replacement of Batteries .................5 Customer Service, Technical Support............6... - Page 4 Use only Johnson Controls recommended or provided as standardized or replacement parts. Johnson Controls shall not assume any liability for injuries or damage caused by not following steps outlined or described in this manual. Unauthorized modifications to Johnson Controls products are prohibited as they…...
- Page 5 Take the following precautions to reduce the risk of property damage Do not touch the main circuit board or electronic components in the controller or remote devices. Also, make sure that dust and/or steam does not accumulate on the circuit board. ...
- Page 6 After installation work for the system has been completed, explain the “Safety Precautions,” use, and maintenance of the unit to the customer according to the information in all manuals that accompanied the system. All manuals and warranty information must be given to the user or left near the Indoor Unit.
- Page 7 Clamp electrical wires securely with a cable clamp after all wiring is connected to the terminal block. In addition, run wires securely through the wiring access channel. When installing the power lines, do not apply tension to the cables. Secure the suspended cables at regular intervals, but not too tightly.
-
Page 8: User Notice
Wireless Remote Controller DRCR 1 User Notice CAUTION ! Make sure there is no obstruction between the wireless remote controller and the signal ① receiver. The signal receiving distance of the wireless remote controller can be up to 32.8 feet. - Page 9 Wireless Remote Controller DRCR Name Function Description Signal ● Signal transmitter Transmitter ● Press this button, and the unit will be turned on; press it once more, and the ON/OFF unit will be turned off. When turning off the unit, the Sleep function will Button be canceled, but preset time is still enabled.
- Page 10 Wireless Remote Controller DRCR ● Press this button to set up the swing angle, which sequentially changes as shown. ● When the guide louver starts to swing up and down, if SWING funtions is canceled, the air guide louver will stop and remains at the current position.
-
Page 11: Additional Functions
Wireless Remote Controller DRCR ● Pr essing this button will toggle the temperature displayed on the remote between the indoor setting temperature and the indoor temperature. ● Indoor setting temperature is default after the indoor unit is initially powered up. -
Page 12: Replacement Of Batteries
Wireless Remote Controller DRCR heating so that the ambient temperature will approach the preset temperature more quickly. ● Lock Press + and - buttons simultaneously to lock or unlock the keyboard. If the wireless remote controller is locked, the icon will be displayed, in which case, any button press will result in no response but with the icon blinking three times. - Page 14 Product improvement, specifications and appearance in this manual are subject to change without prior notice. LIT - 12012196 © Johnson Controls, Inc. USA...
