Ecodan 150 Standard Installation And Servicing Instructions page 9

Fig 2c - Dimensions and EU Product Fiche- Slimline models
E
D
F
KEY
A OVERALL HEIGHT
B HEAT PUMP FLOW CONNECTION (22mm O/D COPPER)
C TUNDISH OUTLET CONNECTION (22mm COMPRESSION)
D HEAT PUMP RETURN CONNECTION (22mm O/D COPPER)
E HEATING CIRCUIT FLOW CONNECTION (22mm O/D COPPER)
F HEATING CIRCUIT RETURN CONNECTION (22mm O/D COPPER)
G COLD WATER INLET CONNECTION (22mm COMPRESSION)
H HOT WATER OUTLET CONNECTION (22mm COMPRESSION / 3/4" BSP M)
CAPACITY
A
B
C
D
E
F
MODEL
Energy efficiency
class
Standing loss in W
Storage volume V in
Litres
Technical parameters in accordance with European Commission
regulations 814/2013 and 812/2013
492
H
G
150 170
1515 1689
1047 1047
909 1083
637 636
246 246
101 101
150 Slimline 170 Slimline
C C
60 68
150 170
A
B
C
648
9
