Fig 2a - Dimensions and EU Product Fiche- Standard models
579
I
E
F G
KEY
A OVERALL HEIGHT
B SECONDARY RETURN TAPPING
C HEAT PUMP FLOW CONNECTION (22mm O/D COPPER)
D TUNDISH OUTLET CONNECTION (22mm COMPRESSION)
E HEAT PUMP RETURN CONNECTION (22mm O/D COPPER)
F HEATING CIRCUIT FLOW CONNECTION (22mm O/D COPPER)
G HEATING CIRCUIT RETURN CONNECTION (22mm O/D COPPER)
H COLD WATER INLET CONNECTION (22mm COMPRESSION)
I HOT WATER OUTLET CONNECTION (22mm COMPRESSION / 3/4" BSP M)
CAPACITY
A
B
C
D
E
F
G
MODEL 150 Standard
Energy efficiency
class
Standing loss in W
Storage volume V in
Litres
Technical parameters in accordance with European Commission regulations 814/2013 and 812/2013
H
C
D
150 170
1130 1256
- -
996 996
493 619
585 585
195 195
50 50
170 Standard
B B
50 55
150 170
A
B
210 250
1508 1760
1050 1175
996
871 1123
585
195
50
210 Standard 250 Standard
C
65
210
683.0
300
2074
1385
996 996
1437
585 585
195 195
50 50
300 Standard
C C
70 79
250 300
