Dimensions And Eu Product Fiche - Solar Models; Solar Coil Specification - Ecodan 150 Standard Installation And Servicing Instructions

Mitsubishi electric pre-plumbed unvented mains pressure water heater with ftc5 control system for use with the air source heat pump range 150, 170, 210, 250 and 300 litre capacity
Table of Contents

Advertisement

Fig 2b - Dimensions and EU Product Fiche - Solar models
D
E
F G
KEY
A
OVERALL HEIGHT
B
HEAT PUMP FLOW CONNECTION (22mm O/D COPPER)
C
TUNDISH OUTLET CONNECTION (22mm COMPRESSION)
D
HEAT PUMP RETURN CONNECTION (22mm O/D COPPER)
E
HEATING CIRCUIT FLOW CONNECTION (22mm O/D COPPER)
F
HEATING CIRCUIT RETURN CONNECTION (22mm O/D COPPER)
G
SOLAR COIL CONNECTIONS (22mm COMPRESSION / 3/4" BSP M)
H
COLD WATER INLET CONNECTION (22mm COMPRESSION)
I
HOT WATER OUTLET CONNECTION (22mm COMPRESSION / 3/4" BSP M)
CAPACITY
A
B
C
D
E
F
G
MODEL
Energy efficiency
class
Standing loss in W
Storage volume V in
Litres
Technical parameters in accordance with European Commission regulations 814/2013
and 812/2013
8
579
I
H
210
250
1513
1765
1346
1346
877
1129
935
935
545
545
400
400
372
372
210 Solar
250 Solar
C
C
65
68
210
250
A
B
C
300

Solar coil specification:

2081
Surface Area: 1.1m
1346
Coil volume: 5.8 litres
Pressure drop: 3.6 kPa (0.036 bar)
1444
Output rating: 30kW at 80
935
litres/minute flow rate
545
Connections: 22mm compression / 3/4" BSP male
Dedicated solar volume: 75 litres
400
372
300 Solar
C
77
300
683
2
C flow temperature, 15
o
