OUTLET/TERMINAL FITTINGS (TAPS, ETC.)

The Pre-plumbed cylinder can be used in conjunction with most types of terminal fittings, plumbing fittings and pipework.
However, the rated pressures of any fittings selected should be checked for compatibility before installation.
NOTE: Accessories, plumbing fittings and pipework should have a rated operating pressure of at least 8 bar.
Outlets situated higher than the cylinder will give outlet pressures lower than that at the unit, a 10m height difference
will result in a 1 bar pressure reduction at the outlet fitting.

LIMITATIONS

Pre-plumbed
The cylinder should not be used in association with any of the following:
• Solid fuel boilers or any other boiler in which the energy input is not under effective thermostatic control, unless additional
and appropriate safety measures are installed.
• Ascending spray type bidets or any other class 1 back syphonage risk require that a type A air gap be employed.
• Steam heating plants unless additional and appropriate safety devices are installed.
• Situations where maintenance is likely to be neglected or safety devices tampered with.
• Water supplies that have either inadequate pressure or where the supply may be intermittent.
• Situations where it is not possible to safely pipe away any discharge from the safety valves.
• In areas where the water consistently contains a high proportion of solids, e.g. suspended matter that could block the
strainer unless adequate filtration can be ensured.

OPERATIONAL SUMMARY

Maximum mains supply pressure
Operating pressure
Expansion vessel pressure
Maximum design (Rated) pressure
Expansion relief valve setting
T&P relief valve setting
T&P relief valve manufacturers ref
Maximum primary circuit pressure
Maximum heating fluid temperature
Storage capacity
Weight when full

OUTLINE SPECIFICATIONS

The cylinders are designed, constructed and tested for compliance with BS EN 12897:2006
Outer casing: White pre-painted corrosion resistant steel
Water container: Duplex stainless steel. 100% pressure tested to 1.5 MPa (15 bar).
Thermal insulation: CFC/HCFC free fire retardant expanded polyurethane foam with zero ozone depletion potential. It has a
Global Warming Potential (GWP) of 3.1. Nominal thickness Standard and Solar units 60mm, Slimline units 50mm.
Table 1 - Unit Weights & Standing Heat Loss
Nominal
Model Type Capacity
(litres)
Standard
Standard
Standard
Standard
Standard
Solar
Solar
Solar
Slimline
Slimline
1.6 MPa (16 bar)
0.35 MPa (3.5 bar)
0.35 MPa (3.5 bar)
0.8 MPa (8 bar)
0.8 MPa (8 bar)
90°C/1.0 MPa (10 bar)
RWC PTEM 510003
0.3 MPa (3 bar)
85 C
o
See Table 1 below
See Table 1 below
Weight of
full unit (kg)
150 206
170 232
210 279
250 327
300 387
210 284
250 332
300 392
150 204
170 230
Weight of
unit (kg)
per day (kWh/24h)
56 1.19
62 1.32
69 1.57
77 1.67
87 1.89
74 1.56
82 1.63
92 1.84
54 1.45
60 1.63
Standing Heat Loss
per year (kWh/365d)
434.4
481.8
573.1
609.6
689.9
569.4
595.0
671.6
529.3
595.0
