Spares List - Ecodan 150 Standard Installation And Servicing Instructions

Table 8 - Spares list
DESCRIPTION
1 Immersion heater (including terminal shroud and gasket)
2 Immersion heater gasket
3 Immersion heater backnut
4 Immersion heater key spanner
5 Tundish
6 Expansion Valve Cartridge 8 bar
7 Expansion Valve 8 bar Complete
8 Temperature / pressure relief valve
9 DHW Expansion vessel 12 litre ( 150 litre models)
10 DHW Expansion vessel 18 litre ( 170 and 210 litre models)
11 DHW Expansion vessel 24 litre (250 and 300 litre models)
12 Pressure Reducing Valve (3.5 bar)
13 Nut and olive pack (4 of each)
14 TSRU immersion heater over-temperature cutout
16 Primary circulating pump - UPM3
17 Primary circulating pump 150 - 210L models - UPM GEO
18 Primary circulating pump 250 & 300L models - UMPXL GEO
19 DHW circulating pump
20 Filling loop
21 Automatic air vent
22 Primary system pressure gauge
23 Drain valve
24 Terminal shroud
25 Flow sensor Body
26 Flow sensor cable
27 O rings for Flow Sensor body (2 per)
28 Fastner clip for Flow sensor body (2 per)
29 Plate to plate heat exchanger
30 Plate to plate heat exchanger insulation set
31 Terminal box cover (Standard and Solar models)
32 Terminal box cover (Slimline models)
33 Fernox TF1 magnetic filter
34 Primary pump isolating valve
35 DHW pump isolating valve
36 Scale trap assembly
37 3 way motorised diverter valve - Actuator head
38 3 way motorised diverter valve - Valve body
39 Flow temperture sensor assembly
40 Return temperature sensor assembly
41 DHW tank thermal sensor assembly
42 Solar sensor pocket assembly including gasket (Solar models only)
43 Solar thermal over-temperature cutout (Solar models only)
PART NO.
95602002
95611026
95605204
95605205
95607881
95605206
95605207
95605209
95970022
95970023
95970024
95605211
95970026
95602003
7696407
7696408
7696409
54HSHDHW
95970029
95970032
95970033
95605210
95970034
307286
307287
307288
307289
54HSHPHEX
95970037
95970038
95970039
95970061
95605212
95605213
95970062
54HSH3WV-ACT
54HSH3WV-VLV
PAC-TH011-E
PAC-TH011-E
PAC-TH011TK-E
95970025
95970060
37
