Team Blacksheep TBS UNIFY EVO Manual page 7

Airwave 5740
Race Band 5658
PowerLevel 25
The selections in ​ o range ​
special request (custom firmware for large events with prior legal body approval). The video transmitter
ensures that you cannot select illegal channels or power levels by accident:
● When controlled by the push button, you will need to confirm having a HAM license by following
the steps described above to unlock your video transmitter
● Through the CORE PRO, you are required to enter your HAM license number under the "Callsign"
menu before you can access the high power transmission settings and the locked out channels
LED Flash Codes for Channel, Band and Power
The TBS UNIFY PRO 5G8 signals selected channel, band and power levels using a startup sequence of LED
codes. The same sequence is also repeated in the menu to make it unified. First, the ​
indicate the item being shown. One flash for channel, two flashes for band, three flashes for power level.
Subsequently, the ​ B LUE ​
Red LED: Indicate item - Channel, band or power setting
Blue LED: Indicate value
For example, Channel 6, Band B, Power of 500mW, will have the following startup LED code:
● 1x ​ R ed​ and 6x ​
2x ​ R ed​ and 2x ​
●
3x ​ R ed​ and 3x ​
●
Once the Video transmitter has successfully booted up, it will show a constant ​
constant ​ R ED ​ + ​ B LUE ​ f or unlocked state.
5760 5780
5695 5732
100 400
r equires HAM license to operate legally. Black selections are only available on
L ED will indicate the value.
B lue ​ = Channel, 6
B lue ​ = Band, 2 (=B)
B lue ​ = Power, 3 (= 500mW)
5800 5820 5840
5769 5806 5843
800
7
5860 5880 MHz
5880 5917 MHz
mW
R ED ​ L ED flashes to
B LUE ​ f or locked state, and a
