Specifications
Input voltage:
Power Output
Extra features:
Remote software
protocol
Output Power
Pit mode
Pit mode -> flight mode
Channels:
Audio
Power consumption
Range:
Antenna connector:
Port connector
Dimensions:
Weight:
Kit contents:
* requires HAM license, special unlocking procedure!
7V to 26V (2S - 6S LIPO) VBat, peak max 31V.
Connect directly to battery or regulator with enough output power (>=7V, 1A)!
Regulated 5V for Camera @ 200mA
PWM, Barcodes, 2x CRSF or
CRSF:
14dBm (25mW)
20dBm (100mW*)
26dBm (400mW*)
29dBm (800mW*)
Activate: ​ p ress button during powered up.
Deactivate: ​ p ress button during powered up.
(​ r ed​
Command through Smartaudio V2.1 & CRSF
Band A (8ch), B (8ch), E (5ch)
Low Race Band 8ch **
Yes, through microphone on-board
25mW: 300mA
200mW: 370mA
500mW: 500mA
800mW: 650mA
Up to 4 km with omnidirectional RHCP antennas
Main connector: JST-GH, 7 pin
2​ nd​
22 (H) x 30 (W) x 4 (D) mm
1x TBS UNIFY EVO, 1x 7pin cable (power, cam, crsf), 1x 4pin cable
2
TBS UNIFY EVO
CleanSwipe
PitMode
2x CRSF
Smartaudio V2.1
SmartAudio V2.1
LED: ​ r ed blinking
LED: ​ b lue
& ​ b lue​ when unlocked)
Fatshark 8ch
Race Band 8ch
U.FL high strength
SMA
Connector: JST-GH, 4 pin
7g excluding antenna
Smartaudio V2.1:
14dBm (25mW)
23dBm (200mW*)
27dBm (500mW*)
29dBm (800mW*)
25mW: 300mA
100mW: 350mA
400mW: 450mA
800mW: 650mA
