OSD Functions
The TBS Unify EVO OSD automatically shows information that it finds in the CRSF telemetry stream. It is
kept basic and clean on purpose, it sets itself up as much as it can and just works.
Here are the telemetry features currently supported:
GPS, heading & home arrow (TBS GPS via BST, or other GPS connected to a Betaflight or iNav FC)
●
● Current sensor information (if provided to the Betaflight or iNav FC)
Voltage sensor built-in to VTx
●
● RSSI, SNR and LQ information (when connected to a TBS Crossfire RX or FC)
● Video Transmitter Channel & Power
HAM Callsign
●
Button menu control
There are categories in the menu, and settings. Pressing the button for 3 seconds will toggle between
categories, pressing it for a short (1 second) press toggles between settings. To enter the menu, hold the
button for 3 seconds. LED colors will signal the state of the menu, for an overview see the following table.
1. Channel select mode
Enter the menu by pressing the button for 3s. Red LED will flash 1 time. Select channels by simple short
presses.
2. Band select mode
Press button for an additional 3s. Red LED will flash 2 times. Select band by simple short presses.
3. Unlock & power select mode
(FOR HAM USERS ONLY!) Press button for 20 to 25 seconds. The Red LED will flash 3 times to confirm. You
have unlocked the video transmitter for use with all frequencies (see frequency table below).
NOTE​ : Unlock only works if you are inside the band selection menu
The power select mode is now accessible. Once unlocked, you can select the power level according to the
table below. To lock the transmitter, go back into band select menu and press the button for 20 to 25
seconds again.
Save and exit
At any time during the menu settings, press the button for 3 seconds or longer. Blue LED will turn on,
settings are saved and it will exit the menu.
