SmarTemp Control
Temperature Calibration
Based on the installation location of the SmarTemp Control 2.0, multiple factors such as door openings
can affect the SmarTemp Controls ambient temperature reading. If temperature offset adjustment is
needed see "Offset" on page 5Error! Bookmark not defined. for further details.

Component Description

On / Off Button
Ambient Temp Sensor
*Micro USB Service Port
* The micro USB Service Port is used for Webasto heater diagnostic purposes only. This port
cannot be used to charge cell phones or other electronic devices.
LCD Screen Symbol Legend
Main Screen
Heat Mode
Vent Mode

Operation Examples

Below are a few operational examples of how easy it is to use the Webasto SmarTemp Control 2.0.
Heater ON Example
Press the Webasto button to turn heater on.
Set Temperature Output & Heater Runtime Example
Using the rotary dial and the selection button, follow these steps to set your cab temperature to 70°F
with a runtime of 4 hours.
LCD Screen
Heater Mode
Timer Start Day / Time
Timer Active
Ambient Temperature
Set Temperature
Runtime Remaining
Ambient Temperature
User Set Temperature
Runtime Remaining
Ambient Temperature
Fan Speed Indicator (Low –
Medium - High)
Installation - Operating Instructions
Rotary Knob
Screw Cap
Status Indicator Light(s)
Selection Button
Vent Mode
Timer Start Day / Time
Ambient Temperature
Timer Active
Mode Indicator
Heater ON
Mode Indicator
Fan ON
4
