Bill Of Materials - ISSI IS31AP2031-QFLS2-EB Manual

IS31AP2031 CLASS-K AUDIO POWER AMPLIFIER
EVALUATION BOARD GUIDE

BILL OF MATERIALS

Name Symbol
Audio Amplifier
LDO
MCU
Diode D1~D4
Resistor
Resistor R3,R5,R10~R13 RES,100k,1/16W,±5%,SMD
Resistor R6~R9
Resistor
Capacitor
Capacitor
Capacitor C8,C10
Capacitor
Capacitor
Capacitor
Capacitor
Button K1~K4
Bill of Materials, refer to Figure 2 above.
Integrated Silicon Solution, Inc. – www.issi.com
Rev. C, 01/22/2017
Description
U1 Class-K Audio Amplifier
U2 Low-dropout Regulator
U3 Microcontroller
Diode, LED Blue, SMD
R1,R2 RES,10k,1/16W,±1%,SMD
RES,1k,1/16W,±5%,SMD
R4 Not Connected
C1,C6 CAP,10µF,10V,±10%,SMD
C2 CAP, 1µF,16V,±10%,SMD
CAP, 1µF,16V,±10%,SMD
C3,C4 CAP, 15nF,16V,±10%,SMD
C5 CAP, 4.7µF,10V,±10%,SMD
C7 CAP, 0.1µF,16V,±10%,SMD
C9 CAP,10nF,16V,±10%,SMD
Button SMD
Qty Supplier
1 ISSI
1 PAM
1 NXP
4 Everlight 19-217/BHC-ZL1M2RY/3T
2 Yageo RC0603FR-0710KRL
6 Yageo RC0603JR-07100KRL
4 Yageo RC0603JR-0701KRL
1
2 Yageo CC0805KKX7R6BB106
1 Yageo CC0603KKX7R7BB105
2 Yageo CC0805KKX7R7BB105
2 Yageo CC0603KKX7R7BB153
1 Yageo CC0805KKX7R6BB475
1 Yageo CC0603KKX7R7BB104
1 Yageo CC0603KKX7R7BB103
4
Part No.
IS31AP2031
PAM3101
LPC922
3
