36 Channels LED Driver Evaluation Board Guide

Bill of Materials

Name Symbol
LED Driver U1
LDO U2
MCU U3
PMOS U4
Diode D1~D39
Diode D40~D51
Resistor R1
Resistors R2~R3
Resistors R4~R7
Capacitor C1
Capacitors C2,C3,C5
Capacitor C4
Button K1
Integrated Silicon Solution, Inc. – www.issi.com
Rev. A, 11/18/2016
Description
36 CH FxLED Driver
Low-dropout Regulator
Microcontroller
Dual PMOS
Diode, LED Blue, SMD
Diode, LED RGB, SMD
RES,3.3k,1/16W,±5%,SMD
RES,4.7k,1/16W,±5%,SMD
RES,100k,1/16W,±5%,SMD
CAP,10µF,16V,±20%,SMD
CAP, 1µF,16V,±20%,SMD
CAP,10nF,16V,±20%,SMD
Button SMD
Table 2: Bill of Materials, refer to Figure 2 above.
Qty Supplier
1 ISSI IS31FL3236/IS31FL3236A
1 PAM
1 NXP
1 ANPEC
39 Everlight 19-217/BHC-ZL1M2RY/3T
12 Everlight 99-235/RGBC/TR8
1 Yageo RC0603JR-073K3L
2 Yageo RC0603JR-074K7L
4 Yageo RC0603JR-07100KL
1 Yageo CC0603KKX7R9BB106
3 Yageo CC0603KKX7R9BB105
1 Yageo CC0603KKX7R9BB103
1
Part No.
PAM3101
LPC922
APM4953
3
