IS31FL3731 Audio Modulated Matrix LED Driver Evaluation Board Guide

Bill of Materials

Name
LED Driver
MCU
Audio Amplifier
Diode D1~D144
Crystals
Resistors
Resistors
Resistors
Resistor
Resistor
Capacitor
C2,C5,C6,
Capacitors
Capacitor
Capacitors
Button
Integrated Silicon Solution, Inc. – www.issi.com
R1.0, 07/12/2012
Symbol
U1 Matrix LED Driver
U2 Microcontroller
U3 Class- AB Audio Amplifier
Diode, LED Blue, SMD
Y1 Crystals, 12MHz,HC-49S
R1,R8 RES,20k,1/16W,±5%,SMD
R2,R3,R5, RES,4.7k,1/16W,±5%,SMD
R4,R6 RES,100k,1/16W,±5%,SMD
R7 RES,10k,1/16W,±5%,SMD
R9 RES,39k,1/16W,±5%,SMD
C1 CAP,10µF,16V,±20%,SMD
CAP,1µF,16V,±20%,SMD
C10,C11
C3, CAP,0.1µF,16V,±20%,SMD
C4,C9 CAP,0.22µF,16V,±20%,SMD
K1 Button SMD
Table 2: Bill of Materials, refer to Figure 2 above.
Description Qty Supplier Part No.
1 ISSI IS31FL3731
1 NXP STC12C5A60S2
1 ISSI IS31AP4991
9-217/BHC-ZL1
144 Everlight
M2RY/3T
1
2
3
2
1
1
1
5
1
2
1
4
