IS31AP4915 Class-G Audio Power Amplifier Evaluation Board Guide
Description
The IS31AP4915 is an audio power amplifier
designed to drive ceramic speakers in portable
applications. The IS31AP4915 outputs 20V
less than 1% THD+N while operating. The
IS31AP4915
features
improved noise rejection and a low power
shutdown mode. The IS31AP4915 is unity-gain
stable and uses external gain-setting resistors. The
IS31AP4915
evaluation
characterization
of
IS31AP4915
provides connectors for audio inputs, audio outputs,
and power supply. Please note that ceramic
speakers are not included with kit.
Features
Integrated Charge-Pump Power Supply–No
Inductor Required
Short-Circuit and Thermal Protection
Pop Reduction Circuitry
20V
Voltage Swing into Ceramic Speaker
P-P
High Electric-Sound Efficiency
Package: QFN-16 (4mm x 4mm)
Quick Start
Figure 1: Photo of IS31AP4915 Evaluation Board
Ordering Information
Part No.
IS31AP4915-SLS2-EB
For pricing, delivery, and ordering information, please contact the ISSI team at
analog_mkt@issi.com
Integrated Silicon Solution, Inc. –
RevA, 1/10/2013
with
P-P
differential
inputs
for
board
allows
easy
features.
It
Temperature Range
-40°C to +85°C (Industrial)
Table 1: Ordering Information
or (408) 969-6600.
http://www.issi.com
Recommended Equipment
5V, 2A power supply
Audio input source (i.e. iPod/mp3 player)
Ceramic speaker
Caution: Do not exceed the conditions listed above,
otherwise the board will be damaged.
Absolute Maximum Ratings
≤6.5V power supply
Caution: Do not exceed the voltage listed above. Doing so
may cause damage to the board.
Procedure
The IS31AP4915 evaluation board has been fully
assembled to allow easy demonstration of the
amplifier's characteristics. Follow the steps listed
below to verify board operation.
Caution: Do not turn on the power supply until all circuitry
connection points are joined. Operate only under safe
conditions.
1. Connect the ceramic speaker to the OUT+ and
OUT-
2. Connect the audio source to the J2 by using a
3.5mm headphone connector
3. Connect the ground terminal of the power
supply to the GND pin and the positive terminal
to the VCC pin, OR connect the power supply
to J1.
4. Turn on the audio source
5. Turn on the power supply
IC Package
QFN-16 (4mm x 4mm)
