Elba OB60 Series Installation Instructions And User Manual
Single & double multifunction models
Hide thumbs
Also See for OB60 Series:
- User manual (48 pages) ,
- Installation instructions and user manual (36 pages) ,
- Installation instructions manual (8 pages)
Subscribe to Our Youtube Channel
Related Manuals for Elba OB60 Series
Summary of Contents for Elba OB60 Series
- Page 1 Installation instructions User guide Built-in oven OB60 single & double multifunction models NZ AU...
-
Page 3: Table Of Contents
Contents Safety and warnings Installation instructions First use ELECTRONIC CLOCK MODELS Setting the clock and using your oven MODELS WITH THREE-BUTTON CLOCK Oven controls Cooking with ‘auto-off’ MODELS WITH SIX-BUTTON CLOCK Oven controls Using the timer Automatic cooking 120-MIN ANALOGUE TIMER MODELS Using your oven Oven functions Baking charts... -
Page 4: Safety And Warnings
Safety and warnings Installation WARNING! Electrical Shock Hazard Always disconnect the appliance from the mains power supply before carrying out any maintenance or repairs. Connection to a good earth wiring system is essential and mandatory. Alterations to the domestic wiring system must only be made by a qualified electrician. - Page 5 Safety and warnings Operation and maintenance Your built-in oven has been carefully designed to operate safely during normal cooking procedures. Please keep the following guidelines in mind when you are using your oven: WARNING! Electrical Shock Hazard Switch the oven off at the wall before any cleaning or maintenance. Failure to do so may result in death or electrical shock.
-
Page 6: Installation Instructions
Installation instructions OB60S models 16-20 mm 2.5 mm Installation diagrams for illustration purposes only Fig. 1 OB60S product and cabinetry dimensions Product and cabinetry dimensions (mm) overall height* of product overall width of product overall depth of product (excluding handle and knobs) height of chassis width of chassis depth of chassis... - Page 7 Installation instructions OB60B models 16-20 mm 2.5 mm Fig. 2 OB60B product and cabinetry dimensions Product and cabinetry dimensions (mm) overall height* of product overall width of product overall depth of product (excluding handle and knobs) height of chassis width of chassis depth of chassis depth of oven frame and control panel (=distance between front of chassis and front of oven door, excl.
- Page 8 Installation instructions Before you install the oven, make sure that the benchtop and oven cavity are square and level, and are the required dimensions the installation will comply with all clearance requirements and applicable standards and regulations a suitable isolating switch providing full disconnection from the mains power supply is incorporated in the permanent wiring, mounted and positioned to comply with the local wiring rules and regulations.
- Page 9 Installation instructions Connecting the oven to the mains power supply Important! This oven must be connected to the mains power supply only by a suitably qualified person. This oven must be earthed. Before connecting the oven to the mains power supply, check that the domestic wiring system is suitable for the power drawn by the oven (as specified on the rating plate) the voltage corresponds to the value given on the rating plate.
- Page 10 Installation instructions Securing the oven to the cabinetry Position the oven in the prepared cavity. Important! Do not lift the oven by the door handle. Open the oven door fully. Use the supplied screws to secure the oven to the cabinetry. Important! Do not over-tighten the screws.
- Page 11 Installation instructions Final checklist TO BE COMPLETED BY THE INSTALLER Make sure the oven is level and securely fitted to the cabinetry. Check the lower trim is still undamaged. Open the oven door slowly to its fully open position and check if there is adequate clearance between the bottom of the door and the lower trim.
-
Page 13: First Use
First use Before using your new oven, please: Read this user guide, taking special note of the ‘Safety and warnings’ section. Remove all accessories and packaging. Make sure you peel the protective film off all surfaces. ELECTRONIC CLOCK MODELS Set the clock. The oven will not work until the clock has been set. See ‘ELECTRONIC CLOCK MODELS - Setting the clock and using your oven’... -
Page 14: Setting The Clock And Using Your Oven
Setting the clock and using your oven To set the three-button clock When first connected, or after a power failure, will flash in the display. Press Press until you have the correct time of day. To set the six-button clock When first connected, or after a power failure, and AUTO will flash in the display. - Page 15 Setting the clock and using your oven When you have finished cooking Turn both the function and temperature knobs to the off ( O ) position. If AUTO is flashing or steadily lit, press to return the oven to manual mode (six-button clock models only).
-
Page 16: Oven Controls
Oven controls Temperature Clock display Function indicator light indicator light Temperature Control buttons Function knob knob Fig. 8 Control panel- Single models with three-button clock Buttons sets the clock, shows the time of day when oven cooking with ‘auto-off’ set decreases time and beep volume increases time Illuminated symbols... -
Page 17: Cooking With 'Auto-Off
Cooking with ‘auto-off ’ Use ‘auto-off’ to automatically turn the oven off when the set cooking time has elapsed. To set the oven for cooking with ‘auto-off’ Set the oven: Check the clock shows the correct time (eg 12:07). Select the function and set the temperature. Fig. -
Page 18: Oven Controls
Oven controls Fig. 11 Control panel-Double models with six-button clock Control panel Control buttons (for main lower oven only) Main (lower) oven temperature knob Upper oven function knob Main (lower) oven temperature indicator light Upper oven temperature knob Upper oven temperature indicator light Main (lower) oven function knob Clock display Buttons... -
Page 19: Using The Timer
Using the timer You can use the timer at any time, even when the oven is not in use. Important! The timer does NOT turn the oven off. To set the timer Press will show and the symbol Fig. 13 Six-button clock display will start flashing. -
Page 20: Automatic Cooking
Automatic cooking Important! Only the lower (main) oven can be set for automatic cooking. Safe food handling: leave food in the oven for as short a time as possible before and after cooking or defrosting. This is to avoid contamination by organisms which may cause food poisoning. -
Page 22: Using Your Oven
Using your oven 120-min Temperature Function analogue indicator light indicator light timer Temperature Function knob knob Fig. 15 Control panel (120-min analogue timer models) Important! The oven will not work until the timer has been set either to manual mode ( symbol) or to count down. - Page 23 Using your oven Using the 120-min analogue timer Use the timer to automatically turn the oven off when the set cooking time has elapsed. Select the function by turning the function knob. Select the temperature by turning the temperature knob clockwise.
-
Page 24: Oven Functions
Oven functions Depending on your model, your may only have some of these functions. OVEN LAMP Only the oven light comes on. It remains on in all the cooking functions. BAKE This is the traditional method of baking. It is best to bake on only one shelf at a time in this function. -
Page 25: Baking Charts
Baking charts Please note: The settings in the following charts are guidelines only. Follow the instructions in your recipe or on packaging and be prepared to adjust the oven settings and baking times to achieve the best possible results for you. Shelf positions are counted from the base up (1 is the lowest, 4 the highest). - Page 26 Baking charts Baking chart FAN BAKE Food Shelf position Temperature ( Time (mins) single shelf 150-170 13-17 Small cakes multi shelf not recommended single shelf 200-220 8-12 Scones multi shelf not recommended two small (20 cm), 160-175 20-30 staggered on shelf Sponge one large (26 cm) 30-40...
-
Page 27: Care And Cleaning
Care and cleaning Important! Always switch the power to the oven off at the wall before any cleaning or maintenance. When you switch the power back on after cleaning, you will have to set the clock on electronic clock models. Do not use abrasive cleaners, cloths or pads to clean any part of your oven. - Page 28 Care and cleaning What? How? Important! These panels are normally ‘self- Side catalytic If you roast or grill a lot of meat cleaning’ because their special panels and hardly ever bake, heating enamel breaks down greasy (not supplied an empty oven for 60-90 mins splatters when the oven is used for with the oven, C on BAKE...
- Page 29 Care and cleaning Removing and refitting the side racks (and catalytic panels if installed) Note: only some models have a lamp in the left oven wall. Catalytic panels are not supplied with the oven, but purchased and installed optionally. Contact your local Fisher &...
- Page 30 Care and cleaning Removing and refitting the inner glass pane of the oven door Important! The outer pane is not removable. Take care, the glass pane is heavy. Place the removed glass pane on a safe, soft surface. To remove the inner glass pane Open the levers.
- Page 31 Care and cleaning To refit the inner glass pane Make sure the open levers firmly Check the rubber pads are in place. hook to the door. Rubber pads Check the pane is the right way up. Insert the pane into the slide guides and slide it to the bottom retainers.
- Page 32 Care and cleaning Removing and refitting the oven door Important! Take care, the oven door is heavy! To remove the door Open the door fully. Open the levers. Lever Hook into Hold the door. Close the door until the levers hook to it.
- Page 33 Care and cleaning Replacing the oven lamp Note: oven bulb replacement is not covered by your warranty. Let the oven cavity and the grill element cool down. Switch the power to the oven off at the wall. LEFT LAMP (some models only) Remove the left side rack (and catalytic panel if installed).
-
Page 34: Warranty And Service
Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: your product is correctly installed. you are familiar with its normal operation. If after checking these points you still need assistance or parts, please refer to the Service &... - Page 36 Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available. www.elba.co.nz www.elba.com.au NZ AU Built-in oven user guide Published: 04/2009 Part No.
