Summary of Contents for Topcon OPUS A8 STANDARD Basic
- Page 1 Industriestraße 7 . 65366 Geisenheim . Germany www.topcon-electronics.de . dl-opus-info@topcon.com Technical Data Sheet OPUS A8 STANDARD Basic 29.05.19 Errors and technical changes excepted...
-
Page 2: General Information
Dust and oil can harm the electric contacts and compromise the functionality. correct documentation you can order it by con- tacting dl-opus-info@topcon.com. Only properly 3. Do not mount the device under the use of vio- trained personnel with the correct qualification are lence because it can cause damage. - Page 3 Industriestraße 7 . 65366 Geisenheim . Germany www.topcon-electronics.de . dl-opus-info@topcon.com Dimensions Housing Mounting Aluminium back-housing, plastic front-housing, • Landscape or portrait colored light grey (RAL 7035) with black rubber frame. • Standalone • In-dash...
- Page 4 Industriestraße 7 . 65366 Geisenheim . Germany www.topcon-electronics.de . dl-opus-info@topcon.com 3 Display Type: TFT Color Graphic LCD with LED Colors: 16,7 Mio backlight Brightness: typ. 400 cd/m² Size: 12.1“, 261 mm (W) x 163 mm (H) Contrast Ratio: typ. 1,000:1...
- Page 5 Industriestraße 7 . 65366 Geisenheim . Germany www.topcon-electronics.de . dl-opus-info@topcon.com 6 Interfaces CAN Bus Outputs • 2 x CAN-Interfaces 1 digital output • ISO 11898, CAN-specification 2.0 B active Short circuit protection: Up to 36 V • Up to 1 Mbit/s (default 250 Kbit/s, 500 Kbit/s, 300 mA open drain at 12V 750 Kbit/s and 1 Mbit/s) <...
- Page 6 Industriestraße 7 . 65366 Geisenheim . Germany www.topcon-electronics.de . dl-opus-info@topcon.com 8 Software Operating System Linux Kernel 3.0.0 or higher Application Programming • OPUS Projektor • Codesys-Tools (3.X) • ISO-VT • C/C++ 9 Testing and Verification CE-Compliance Mechanical EU Directive 2014/30/EC (EMC) according to • According to ISO 16750-3: Road Vehicles –...
- Page 7 Industriestraße 7 . 65366 Geisenheim . Germany www.topcon-electronics.de . dl-opus-info@topcon.com 10 Pinout Main connector pinout Pin. No. Assignment Description supply voltage +; terminal 30 Ignition Input ignition input; terminal 15 supply voltage - ;terminal 31 CarGND Car GND CAN1H CAN 1 high CAN1L CAN 1 low CAN2H CAN 2 high CAN2L...
- Page 8 Industriestraße 7 . 65366 Geisenheim . Germany www.topcon-electronics.de . dl-opus-info@topcon.com Video connector pinout Ethernet connector pinout Round Connector, 4 pins, M12, Round Connector, 5 pins, M12 acc. To IEC 61076-2-101 VidSig+ Mirror Camera+ Camera - VidSig GND Video connector, M12, female, 5 pins, b-coded,...
