Generic Unit Standard Control
UC7 Boom Height Control System
Installation Manual







Advertisement

loading
Need help?

Need help?

Do you have a question about the Norac UC7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Topcon Norac UC7

  • Page 1                        Generic Unit Standard Control  UC7 Boom Height Control System  Installation Manual             ...
  • Page 2         Copyright  2019 by NORAC Systems International Inc.  Reorder P/N: UC7‐BC‐GN02‐INST Rev A (Generic Unit Standard Control)    NOTICE:  NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without the requirement to update  products sold previously.  Every effort has been made to ensure the accuracy of the information contained in this manual.  The technical information in this manual  was reviewed at the time of approval for publication. ...
  • Page 3: Table Of Contents

    WWW.NORAC.CA    PRECISION DEFINED Contents  Introduction .......................... 1     Technical Specifications ...................... 2     Parts Overview ........................ 3     Pre‐Installation Checklist  ....................... 5     Ultrasonic Sensor Installation  .................... 6     Electronic Installation  ...................... 10     Software Setup  ........................ 13     Cable Schematics  ......................... 14          ...
  • Page 4: Introduction

    WWW.NORAC.CA    PRECISION DEFINED 1   Introduction  Congratulations on your purchase of the NORAC Boom Height Control System.  This system is manufactured  with  top  quality  components  and  is  engineered  using  the  latest  technology  to  provide  operating  reliability  unmatched for years to come.  When properly used the system can provide protection from sprayer boom damage, improve sprayer efficiency,  and ensure chemicals are applied correctly.  Please  take  the  time  to  read  this  manual  completely  before  attempting  to  install  the  system.    A  thorough  understanding of this manual will ensure that you receive the maximum benefit from the system. ...
  • Page 5: Technical Specifications

    WWW.NORAC.CA    PRECISION DEFINED 2   Technical Specifications  CAN ICES‐3(A)/NMB‐3(A)                         This Class A digital apparatus complies with Canadian ICES‐003.  Pursuant to EMC Directive – Article 9, this product is not intended for residential use.  Table 1: System Specifications  Supply Voltage (rated)   12VDC  Supply Current (rated)   10A  Hydraulic Pressure (maximum)   3300 psi  Baud Rate   250 kbps  Operating Temperature Range   0°C to 80°C            Visit www.solutions.norac.ca for more system   Page 2  installation and troubleshooting info. ...
  • Page 6: Parts Overview

    WWW.NORAC.CA    PRECISION DEFINED 3   Parts Overview  3.1. Electronic Installation Overview  The following diagrams illustrate the GN02 kit specific parts of the NORAC UC7™ system.  Interface cables, valve  cables, and power cables are shown in this manual and may not be included.  Cables are available separately  from NORAC.  Please refer to the UC7 Cable Ordering Guide (P/N: UC7‐BC‐CABLE‐GUIDE) for cable ordering  information (available at www.norac.ca).    Figure 1: Electronic Installation Overview  Items shown in green and denoted with an asterisk (*) are not included and must be ordered separately.  Items shown in BLUE are included in the display package and may not be exactly as shown.      Visit www.solutions.norac.ca for more system   Page 3  installation and troubleshooting info. ...
  • Page 7 WWW.NORAC.CA    PRECISION DEFINED 3.2. List of Parts  Item  Part Number  Name  Quantity  B05  44706‐01  KIT CABLE TIE BLACK 10 PCS 21 IN  150 PCS 7.5 IN  1  B17  44972  SENSOR MOUNTING BRACKET LOW PROFILE RAINFLAP 16GA  2  B20  44971  SENSOR MOUNTING BRACKET LOW PROFILE 16GA  2  C02  43220‐03  CABLE NETWORK 14 AWG 3M  1  C05  43210‐20  CABLE NETWORK 18 AWG 20M  2  E01  50000  HCM1 MODULE  1  E07  50300  ULTRASONIC MAX SENSOR  2  E11  43765  NETWORK COUPLER 8‐WAY  1 ...
  • Page 8: Pre-Installation Checklist

    WWW.NORAC.CA    PRECISION DEFINED 4   Pre‐Installation Checklist  The pre‐install checklist is necessary to check the existing sprayer functionality before the installation.  Unfold the sprayer over a flat, unobstructed area (i.e. no power lines…etc.).  Ensure all boom‐fold operations are functional (place a check mark in boxes below).  Bring engine to field‐operational RPM and record below.   Record  the  time  (seconds)  it  takes  for  a  full  stroke  for  all  boom  functions.    To  ensure  repeatable  measurements, take the average of 3 trials.    Not all sprayers will have the functions listed below in Figure 2.    Ensure the boom has sufficient travel so it does not contact the ground during these tests.    Figure 2: Pre‐Install Boom Speeds            Visit www.solutions.norac.ca for more system   Page 5 ...
  • Page 9: Ultrasonic Sensor Installation

    WWW.NORAC.CA    PRECISION DEFINED 5   Ultrasonic Sensor Installation  5.1. Ultrasonic Sensor Serial Number Arrangement  The MAX Sensors™ (E07) are mounted in the outer wing positions with the lowest serial number on the left side  and the highest serial number on the right side.    Each sensor has a serial number stamped on the sensor housing.  Apply a light coating of the supplied Permatex Anti‐seize grease to all threaded parts upon installation.    Figure 3: Sensor Serial Number Arrangement          Visit www.solutions.norac.ca for more system   Page 6  installation and troubleshooting info. ...
  • Page 10 WWW.NORAC.CA    PRECISION DEFINED 5.2. Ultrasonic Sensor Mounting Guidelines  The following guidelines will ensure optimal sensor performance and prevent sensor measurement.    In its lowest position, the sensor must be 9 inches (230 mm) or more from the ground.   Ensure that there are no obstructions within a 12 inch (300 mm) diameter circle projected directly below  the center of the sensor.   The sensor should be approximately vertical at normal operating heights.      Figure 5: Bracket Mounting Guidelines  Figure 4: Sensor Mounting Guidelines    5.3. Low Profile Bracket Mounting Guidelines  Minimize the distance between the bolts to prevent bending the bracket and prevent the bracket from  loosening over time.    Ensure the bracket is mounted tight against the bottom of the boom, minimizing the distance between the  boom structure and the angled flange.    A problem can arise if a sensor is not mounted correctly.  This may only become apparent once the control  system is switched from soil to crop mode.  Be careful that the sensor bracket does not collide with any other part of the boom when the boom is folded  to transport position.  If possible, mount the sensor brackets while the booms are folded to ensure they will  not cause interference.      Visit www.solutions.norac.ca for more system   Page 7  installation and troubleshooting info. ...
  • Page 11 WWW.NORAC.CA    PRECISION DEFINED 5.4. Rainflap Installation    Rainflaps are only installed if the sensor face will be pointing up when the booms are folded.  Insert one side of the rainflap rod into the pre‐bent hinge tab on the sensor bracket. (Figure 6)    Figure 6: Rainflap Rod in Pre‐Bent Hinge Tab  Align the other side of the rainflap rod with the unbent hinge tab. (Figure 7)    Figure 7: Align Rainflap Rod  Bend the hinge tab inward over the rainflap rod until the hinge tab fits securely in the detent groove on  the backside of the sensor bracket. (Figure 8)    Figure 8: Bend Rainflap Hinge Tab  Ensure the rainflap actuates smoothly when the bracket is turned upside down and returns to the open  position when the sensor bracket is returned to its operating position (sensor pointing downwards toward  the ground).      Visit www.solutions.norac.ca for more system   Page 8  installation and troubleshooting info. ...
  • Page 12 WWW.NORAC.CA    PRECISION DEFINED 5.5. Wing Sensor Installation  The sensor bracket should be oriented forward (ahead of the boom).  Typically, the best mounting location for the wing sensor brackets will be near the end of the boom tips,  approximately two feet (0.6 m) from the end.    Mount the sensor into the sensor bracket.  Run the sensor cable through hole and behind the bracket.   Ensure the cable is clear of moving parts and will not be damaged during folding.  Front                          Figure 9: Bracket Mounting Example          Visit www.solutions.norac.ca for more system   Page 9  installation and troubleshooting info. ...
  • Page 13: Electronic Installation

    WWW.NORAC.CA    PRECISION DEFINED 6   Electronic Installation  6.1. HCM1 Installation  Install the HCM1 (E01) on the boom near the valve block with the large label and LEDs facing up.  Secure  with cable ties.    Output Number  Normal Function    1,2  Left Up and Down  3,4  Right Up and Down    5,6  Main Up and Down    7,8  Roll CW and CCW  Figure 10:  HCM1 Connections    Figure 11:  HCM1 Label  Insert 4‐pin plugs (P01) into any unused connectors on the HCM1.    The  interface  cables  (C14  and  C15)  are  ordered  separately  from  this  kit.    Please  refer  to  the  UC7™  Cable  Ordering Guide (P/N: UC7‐BC‐CABLE‐GUIDE) for cable ordering information (available at www.norac.ca). ...
  • Page 14 WWW.NORAC.CA    PRECISION DEFINED 6.2. Cabling Connections  Fasten the 8‐way coupler to the boom with cable ties.  Connect cable C02 between the 8‐way coupler (E11)  and the 6‐pin NORAC bus connector on the HCM1.  NORAC Bus    Figure 12: NORAC Bus Location  Connect cable C05 to the 8‐way coupler and route along the boom to the outer wing sensors.  At the sensor brackets, attach a 2‐way coupler with terminator (E20) to the sprayer boom.  The 2‐way  coupler with terminator is the white 2‐way coupler.  Plug the sensor and the CANbus cable into the 2‐way  coupler.  Insert the 6 pin plugs (P03) into the remaining receptacles of the 8‐way coupler.        Visit www.solutions.norac.ca for more system   Page 11  installation and troubleshooting info. ...
  • Page 15 WWW.NORAC.CA    PRECISION DEFINED   Figure 13: Cabling and Parts Layout          Visit www.solutions.norac.ca for more system   Page 12  installation and troubleshooting info. ...
  • Page 16: Software Setup

    WWW.NORAC.CA    PRECISION DEFINED 7   Software Setup  Start up the sprayer and test the sprayer’s functionality.  The display terminal does not need to be powered  on for the original boom function switches to operate.  Unfold the booms and raise/lower each boom and  the main section.    Confirm that the cabling and hoses do not pinch, stretch or bind over the entire range of motion.  If any functions do not work, review the hydraulic and electrical portions of this manual to check for proper  installation.  Turn on the power for the display terminal using the switch on the side.  The procedure for the installation of the UC7™ Boom Height Control system is now complete.  Begin the  Automatic  System  Setup  procedure  as  described  in  the  UC7  Technical  Operation  Manual  for  Standard  Control.            Visit www.solutions.norac.ca for more system   Page 13  installation and troubleshooting info. ...
  • Page 17: Cable Schematics

    WWW.NORAC.CA    PRECISION DEFINED 8   Cable Schematics  8.1. Item C02: 43220‐03 ‐ Cable Network 14 AWG – 3m              Visit www.solutions.norac.ca for more system   Page 14  installation and troubleshooting info. ...
  • Page 18 WWW.NORAC.CA    PRECISION DEFINED 8.2. Item C05: 43210‐20 ‐ Cable Network 18 AWG – 20m                Visit www.solutions.norac.ca for more system   Page 15  installation and troubleshooting info. ...
  • Page 19     TOPCON Agriculture Canada  3702 Kinnear Place  Saskatoon, SK   S7P 0A6  TOPCON Agriculture Americas  W5527 Hwy 106  Fort Atkinson, WI   53538  TOPCON Precision Agriculture Europe  Avenida de la industria,  35, Tres Cantos, España  Spain  Support    Phone:  888 979 9509     E‐mail: tasupportn@topcon.com    Web: www.norac.ca      ...
