HF 160
OPERATION, MAINTENANCE AND
SPARE PARTS MANUAL
HYDRAULIC FEEDER
AND FEED CHUTE
HF 160
It is very important to read this instruction
handbook thoroughly before using the machine!
03514050
Normet Corporation
Ahmolantie 6
FIN---74510 PELTOSALMI
FINLAND
Tel. + 358 (0) 17 83 241
Fax. + 358 (0) 17 823 606
D- -USA- -120802- -JaK
03512800
Advertisement
Table of Contents
Related Manuals for Farmi Forest Corporation VALBY HF 160
Summary of Contents for Farmi Forest Corporation VALBY HF 160
- Page 1 www.normet.fi 03514050 D- -USA- -120802- -JaK HF 160 OPERATION, MAINTENANCE AND SPARE PARTS MANUAL 03512800 HYDRAULIC FEEDER AND FEED CHUTE HF 160 It is very important to read this instruction handbook thoroughly before using the machine! Normet Corporation Ahmolantie 6 FIN---74510 PELTOSALMI FINLAND Tel.
-
Page 3: General Safety
www.normet.fi HF 160 SAFETY INSTRUCTIONS 03512800 1. GENERAL SAFETY Do not operate this machine until you have read and IMPORTANT! understood the manual page by page. The owner of this machine is responsible for instructing all operators and support personnel in the operation and safety precautions of this chipper. -
Page 4: Safety Instructions For The Hydraulic Feeder And Feed Chute
www.normet.fi HF 160 SAFETY INSTRUCTIONS 03512800 D D D D Check the material before you feed it. The material must be free from nails, stones and all other materials that are not wood, paper or plastic. Feeding wire and barbed wire into the chipper is very dangerous as it might pull in the operator. -
Page 5: Table Of Contents
www.normet.fi HF 160 TABLE OF CONTENTS 03511000 1. GENERAL SAFETY ........... . 2. -
Page 6: Plates And Stickers For Hydraulic Feeder And Feed Chute
www.normet.fi HF 160 PLATES AND STICKERS 03512800 2.1. PLATES AND STICKERS FOR HYDRAULIC FEEDER AND FEED CHUTE Do not remove any plate or sticker by the manufactu- IMPORTANT! rer on the chipper or the accessories. Replace mis- sing ones immediately. You can order them as a spare parts. - Page 7 www.normet.fi HF 160 PLATES AND STICKERS 03512800 2 pc 40142080 1 pc 41014120 2 pc. 41014220 1 pc 41014830 2 pc 40605214 2 pc 41014270 1 pc 40605214 --- 7 ---...
- Page 8 www.normet.fi HF 160 PLATES AND STICKERS 03512800 ... Plates and stickers for Hydraulic feeder HF160 and feed chute Part Order no. Description Remarks Qty..40142080 ..Safety goggles, earmuffs and a hard hat must be used when operating the chipper .
-
Page 9: Introduction
www.normet.fi HF 160 PRESENTATION 03512800 3.INTRODUCTION 4.MAIN COMPONENTS 1. Safety / control bar 3.1. FIELD OF APPLICATION 2. Control valve Feeding difficult material becomes easier and more effective when using the hydraulic feeder 3. Flow regulator and feed chute HF160. Also the chip quality 4. -
Page 10: Dimensions
www.normet.fi HF 160 PRESENTATION 03512800 5.DIMENSIONS Fig. 2. HF160 Dimensions. --- 10 ---... -
Page 11: Preparations For Start Up
www.normet.fi HF 160 ASSEMBLY AND MOUNTING 03512800 INSTRUCTIONS 6.PREPARATIONS FOR START Weight 73 lb. ( 160kg) 6.1. LIFTING THE MACHINE OR THE MACHI- NE PART Prior to every procedure IMPORTANT! always recall the general safety instructions given in chapter 1. Make sure that nobody will enter the lifting zone. - Page 12 www.normet.fi HF 160 ASSEMBLY AND MOUNTING 03512800 INSTRUCTIONS 3. Fasten the control rod to the safety / control bar, refer to Spare parts, page 3 4. Connect the hydraulic hoses by connecting the pressure hose (marked ”IN”) to the hy- draulics of the tractor.
-
Page 13: Safety Operation
www.normet.fi HF 160 OPERATION AND 03512800 MAINTENANCE 3. REVERSE 7.SAFETY OPERATION The feed roller rotates outwards and the wood is released from the feeder. Prior to every procedure IMPORTANT! always recall the general safety instructions given in chapter 1. Feeding wire and barbed wire into the chipper... -
Page 14: Adjusting The Feeding Speed
www.normet.fi HF 160 OPERATION AND 03512800 MAINTENANCE DANGER! Do not ever reach inside the the disk. Turning counter---clockwise in- feed chute! creases the feed roller speed, fig.8. D In case of tangle, reverse the feeding until the material comes loose and then disen- gage the PTO. -
Page 15: Safety Maintenance And Service
www.normet.fi HF 160 OPERATION AND 03512800 MAINTENANCE 8.SAFETY MAINTENANCE AND SERVICE Prior to any procedure also recall the general safety instructions in chapter 1. Use only original spare parts. IMPORTANT! Observe common safety practice. Before performing lubrication work on any WARNING! equipment, consult... -
Page 16: Maintenance
www.normet.fi HF 160 OPERATION AND 03512800 MAINTENANCE Fig. 9. Greasing the roll holder’s shaft 9.MAINTENANCE bearings. D Check and tighten possibly loose screws Prior to every procedure and nuts often. IMPORTANT! always recall the general D Check the condition of hydraulic hoses and safety instructions given the tightness of connections once a year. -
Page 17: Maintenance And Lubrication Scehule
www.normet.fi HF 160 OPERATION AND 03512800 MAINTENANCE 9.1. MAINTENANCE AND LUBRICATION SCEHULE GENERAL EVERY 8 EVERY 20 EVERY 40 EVERY PROCEDURE HOURS HOURS HOURS 2000 PAGE HOURS OR 1 YEAR Sliding Grease once a week. bearings of feed roller fastener shaft Hydraulic Check hose... -
Page 18: Technical Data
www.normet.fi HF 160 OPERATION AND 03512800 MAINTENANCE 11.TECHNICAL DATA 1 pcs. Æ10” (260 mm) Feed roller Max. tree diameter 6,1/4” (160 mm) Hydraulic motor 1 pcs. 24 in (400 cm Oil demand, P .T.O speed 540 rpm. min. 3 US gal/min. (15 l/min), max 10 gal/min. Max. - Page 19 --- 19 ---...
-
Page 20: Spare Parts
www.normet.fi HF 160 SPARE PARTS 03511000 03512800 HF 160 Hydraulic feeder and feeding chute --- 20 ---... - Page 21 www.normet.fi HF 160 SPARE PARTS 03511000 03512800 HF 160 Hydraulic feeder and feeding chute Part Order no. Description Remarks Qty..03512830 ..Feeder frame ............
-
Page 22: Hf 160 Hydraulics
www.normet.fi HF 160 SPARE PARTS 03511000 03512840, 03512850 HF 160 Hydraulics --- 22 ---... - Page 23 www.normet.fi HF 160 SPARE PARTS 03511000 03512840, 03512850 HF 160 Hydraulics Part Order no. Description Remarks Qty..56526031 ..Hose assembly ....K1/2”S L= 0,4m .
- Page 24 www.normet.fi HF 160 INDEX 03512800 ASSEMBLY, 11 MAIN COMPONENTS, 9 MAINTENANCE , 16 MOUNTING , 11 CONNECTING, 11 CONTROLS, 13 OPERATION, 13 DIMENSIONS, 10 PLATES ,6 PREPARATIONS , 11 FEEDING , 13 FEEDING SPEED, 14 FIELD OF APPLICATION, 9 REVERSE , 13 GENERAL SAFETY, 3 SAFETY , 13 SCEHULE, 17...
