OPERATION, MAINTENANCE AND SPARE PARTS
HYDRAULIC FEEDER
From machine:329 4157
READ THIS OPERATION AND MAINTENANCE MANUAL
CAREFULLY BEFORE USING THE MACHINE
03299780
HF 231
HF 231
Farmi Forest Corporation
Ahmolantie 6
FIN--- 74510 PELTOSALMI
FINLAND
Tel. +358 (0) 17 83 241
Fax. +358 (0) 17 8324 372
C ---EN ---271006 ---ER

Advertisement

Table of Contents
loading

Related Manuals for Farmi Forest Corporation HF 231

Summary of Contents for Farmi Forest Corporation HF 231

  • Page 1 03299780 C ---EN ---271006 ---ER HF 231 OPERATION, MAINTENANCE AND SPARE PARTS HYDRAULIC FEEDER HF 231 From machine:329 4157 READ THIS OPERATION AND MAINTENANCE MANUAL CAREFULLY BEFORE USING THE MACHINE Farmi Forest Corporation Ahmolantie 6 FIN--- 74510 PELTOSALMI FINLAND Tel.

  • Page 2: Ahmolantie

    HF 231 WARNING SYMBOLS IN THIS MANUAL Imminent danger which could cause serious personal injury or death. DANGER! Danger which could cause personal injury. WARNING! Conditions or misuse that could damage equipment or machinery. CAUTION! Reminders, such as for performing checks or carrying out NOTE! maintenance or repair procedures.
  • Page 3 HF 231 GUARANTEE GIVEN BY THE MANUFACTURER OF A DEVICE INTENDED AS A MACHINE PART Farmi Forest Corporation Ahmolantie 6, FIN- - 74510 PELTOSALMI, Finland Informs that the machine, launched on to the market, FARMI Hydraulic feeder (make) HF 231...

  • Page 4: Table Of Contents

    ............Thread Millimeter Inch 7/16 11/16 15/16 1 3/16 WHEN ORDERING SPARE PARTS, PLEASE INDICATE MACHINES TYPE FROM THE MACHINE PLATE, SPARE---PARTS ORDER NUMBER, DESCRIPTION AND QUANTITY REQUIRED. Example: HF 231, Upper feed roller, 1 pc...

  • Page 5: Safety

    HF 231 1.SAFETY 1.1.GENERAL These safety instructions are intended for personnel operating, servicing, and repairing FARMI equipment. These instructions will help you to: D operate the machine safely D operate the machine appropriately and effectively D notice, avoid, and prevent potentially hazardous situations The manufacturer has supplied safety instructions for the machine.

  • Page 6: Oils And Greases

    HF 231 1.4.OILS AND GREASES D Always use the oil grades recommended by the manufacturer. D Use the recommended oils in cold conditions. D Never mix different fluids or oils with each other. D Follow the manufacturer’s lubrication instructions. 1.5.MAINTENANCE D Modifications without the manufacturer’s permission are prohibited.

  • Page 7: Plates And Stickers

    HF 231 3.PLATES AND STICKERS These decals and stickers must be found from feeder. Missing ones must be renewed immediately. Number 1. Hearing protection (41018330). 2 Pcs. Wear hearing protection. 40142080 Number 2. Lifting point (41014270). 3 Pcs. 41014270 Number 3. Note! (41015690).
  • Page 8 HF 231 Number 4. Stay away from revolving part (41015600). 2 Pcs. 41015600 Number 5. Safety handle left (41016000). This sticker shows the movements of the safety handle. STOP = stop STOP STOP N = neutral R = reverse 41016000 Number 6.

  • Page 9: Feed Chute Presentation

    HF 231 4.FEED CHUTE PRESENTATION 4.1.FIELD APPLICATION 4.2.MAIN COMPONENTS The hydraulic feed chute HF 231 makes feeding difficult 1.Control handle material easier and more effective. The chip quality 2.Directional valve improves due to constant feeding speed and is less 3.Flow regulator dependent on knives sharpness.

  • Page 10: Mounting

    HF 231 6.MOUNTING 1. The hydraulic feeder and mechanical feeders include fitting blocks that are installed between the chipper and feeder. The fitting blocks are installed so that the two guide pins located at the bottom section of the feed opening go through the holes in the fitting block and secure the block.

  • Page 11: Operation

    HF 231 7.OPERATION The speed is suitable when the wood does not push against the grinding wheel or the feeder reel spikes 7.1.CONTROL HANDLE do not slow down the feeding of wood. See The HF 160 is operated with a control handle, paragraph7.4.

  • Page 12: Setting The Feeder Speed

    HF 231 Fig 8.Feeder reel speed settings. D The speed is suitable when the wood does not push against the grinding wheel or the feeder reel spikes 52080819 do not slow down the feeding of wood. D Make sure that you are using clean oil in the 52390200 hydraulic system.

  • Page 13: Hydraulics Circuit Diagram

    HF 231 10.HYDRAULICS CIRCUIT DIAGRAM Fig 12.43484050.

  • Page 14: Spare Parts

    HF 231 HF 231...
  • Page 15 HF 231 HF 231 Part Order No. Description Nimitys Remarks Qty. Til.nro. Bezeichnung Désignation Huom. Kpl. Teil Best Nt Pièce No. de ordre ..13291562 . . . Frame ....
  • Page 16 HF 231 HF 231...
  • Page 17 HF 231 HF 231 Part Order No. Description Nimitys Remarks Qty. Til.nro. Bezeichnung Désignation Huom. Kpl. Teil Best Nt Pièce No. de ordre ..52117108 ..Lock nut ....

  • Page 18: Lever Use Hf 231

    HF 231 2 lever use --- 2 vipukäyttö --- 2 Hebelgebrauch --- 2 Utilisation levier...
  • Page 19 HF 231 2 lever use --- 2 vipukäyttö --- 2 Hebelgebrauch --- 2 Utilisation levier Part Order No. Description Nimitys Remarks Qty. Til.nro. Bezeichnung Désignation Huom. Kpl. Teil Best Nt Pièce No. de ordre ..43299610 .

  • Page 20: Hydraulics

    HF 231 2 lever use --- 2 vipukäyttö --- 2 Hebelgebrauch --- 2 Utilisation levier...
  • Page 21 HF 231 2 lever use --- 2 vipukäyttö --- 2 Hebelgebrauch --- 2 Utilisation levier Part Order No. Description Nimitys Remarks Qty. Til.nro. Bezeichnung Désignation Huom. Kpl. Teil Best Nt Pièce No. de ordre ..43299490 .
  • Page 22 HF 231 Hydraulics---Hydrauliikka---Hydraulik ---Hydraulique 11.2 11.6 11.3 11.4 11.7 11.5 11.1 43484880...
  • Page 23 HF 231 Hydraulics---Hydrauliikka---Hydraulik ---Hydraulique Part Order No. Description Nimitys Remarks Qty. Til.nro. Bezeichnung Désignation Huom. Kpl. Teil Best Nt Pièce No. de ordre ..56001951 . . . Hydraulic motor ... .

  • Page 24: Directional Control Valve

    HF 231 Hydraulics---Hydrauliikka---Hydraulik ---Hydraulique 11.2 11.6 11.3 11.4 11.7 11.5 11.1 43484880...
  • Page 25 HF 231 Hydraulics---Hydrauliikka---Hydraulik ---Hydraulique Part Order No. Description Nimitys Remarks Qty. Til.nro. Bezeichnung Désignation Huom. Kpl. Teil Best Nt Pièce No. de ordre ..54922141 . . . Plug ..... .
  • Page 26 HF 231 Directional control valve ---Suuntaventtili ---Steuerventil ---Vanne de direction Part Order No. Description Nimitys Remarks Qty. Til.nro. Bezeichnung Désignation Huom. Kpl. Teil Best Nt Pièce No. de ordre 56075260 . . . Directional control valve ..
  • Page 29 14 days of receipt of the product.. Important Before putting your FARMI to use, be sure to read the instruction and service booklet provided with the machine FARMI Forest Corporation Ahmolantie 6 74510 PELTOSALMI FARMI Forest Ahmolantie 6...
  • Page 30 Date of delivery: ____ /____ 20____ Dealer: Dealer’s address: Dealer’s tel: Product and type: Serial number: Return to the manufacturer Date of delivery: ____ /____ 20____ Dealer: Dealer’s address: Dealer’s tel: Customer: Customer’s address: Customer’s tel: Product and type: Serial number: Notes:...
