1) Connect the MiniDP end to the Mini DisplayPort/Thunderbolt 2 port of the COMPUTER
2) Connect a DVI-D cable to the adapter and the DVI-D port of the DISPLAY
3)
Select the DVI input setting from the menu of the connected DISPLAY
4) Adjust the computer VIDEO resolution and refresh rate from the computer
Connection Notes
•
WINDOWS & MAC COMPATIBLE with Thunderbolt™ 2 or Mini DisplayPort ports
•
DUAL MONITOR SETUP to connect up to 2 monitors (1 adapter per monitor) with AMD Eyefinity
•
NOT BI-DIRECTIONAL adapter converts the signal only from Mini DisplayPort to DVI-D
•
VIDEO RESOLUTION up to 1920x1080 @ 60 Hz including 1080p with DVI-D Single Link
•
AUDIO IS NOT SUPPORTED BY DVI and must be transmitted separately
•
EASY-GRIP TREADS on the connector assist in cable unplugging to prevent damage
•
HDCP SUPPORT for viewing copy protected video with HDCP compliant equipment
•
DUST CAP protects the Mini DisplayPort connector on the adapter when traveling
Apple, Mac, MacBook, MacBook Air, MacBook Pro, Mac Pro, and iMac are trademarks of Apple Inc.
Thunderbolt is a trademark of Intel Corporation in the U.S. and/or other countries.
Contact support@cablematters.com for questions
Mini DisplayPort™ to DVI-D Cable
Model 101010
Advertisement
Table of Contents
Related Manuals for cable matters 101010
Summary of Contents for cable matters 101010
- Page 1 Model 101010 Mini DisplayPort™ to DVI-D Cable 1) Connect the MiniDP end to the Mini DisplayPort/Thunderbolt 2 port of the COMPUTER 2) Connect a DVI-D cable to the adapter and the DVI-D port of the DISPLAY Select the DVI input setting from the menu of the connected DISPLAY...
- Page 2 IDEO ETTINGS IN INDOWS Connect a DVI-D cable to the adapter and connect the adapter to the computer Select the DVI input from the connected display menu Search for Display in Windows Select the video Resolution (if needed) Select to Duplicate or Extend the display (Note: Click and drag the program to the display in Extended Mode) Select Advanced display settings and select the Display adapter properties Select the Monitor tab and adjust the Screen refresh rate (if needed)
- Page 3 IDEO ETTINGS IN Connect a DVI-D cable to the adapter and connect the adapter to the computer Select the DVI input on the connected display Open the Apple Menu on your computer Select System Preferences Click the Displays icon Click the Arrangement tab Choose to Duplicate or Extend the display ...
-
Page 4: Troubleshooting Tips
During this period, the products may be returned for repair, or replaced with equivalent products at our discretion. The warranty covers parts and labor costs only. Cable Matters does not warrant its products from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
