1) Connect one end of the DisplayPort cable to the computer or video graphics card
2) Connect the other end of the cable to the monitor with DisplayPort
3) Select the DisplayPort input setting from the menu of the connected monitor
4) Select a compatible video resolution and refresh rate from the computer
5) Adjust the computer audio output settings
Connection Notes
!! DEPRESS THE LATCH on the DisplayPort connector to avoid damage when unplugging !!
·
DISPLAYPORT 1.4 feature support for high-bandwidth HBR3, 32.4Gbps bandwidth, DSC 1.2 display
·
stream compression, FEC forward error correction, and 32 audio channels,
DISPLAYPORT 1.2 backwards compatible
·
VIDEO RESOLUTION up to 8K (7680x4320) including 5K (5120x2880 @ 60Hz), 4K (3840x2160 @
·
60Hz), 2K (2560x1440 @ 144Hz) and HD (1920x1200 @ 60Hz)
4K/5K/8K COMPATIBLITY requires a 4K/5K/8K equipped computer and display
·
AUDIO SUPPORT for all known audio formats
·
Compatible with a USB-C to DisplayPort adapter
·
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the United States and other countries.
Contact support@cablematters.com for questions
DisplayPort™ 1.4 Cable
Model 102025
Advertisement
Table of Contents
Related Manuals for cable matters 102025
Summary of Contents for cable matters 102025
- Page 1 Model 102025 DisplayPort™ 1.4 Cable 1) Connect one end of the DisplayPort cable to the computer or video graphics card 2) Connect the other end of the cable to the monitor with DisplayPort 3) Select the DisplayPort input setting from the menu of the connected monitor...
- Page 2 Video Settings in Windows Connect the cable to both ends Select the DisplayPort input from the connected display menu Search for Display in Windows Select the video Resolution (if needed) Select to Duplicate or Extend the display Note: Click and drag the program to the display in Extended Mode Select Advanced display settings and select the Display adapter properties Select the Monitor tab and adjust the Screen refresh rate (if needed) Click Apply to save the settings...
- Page 3 Audio Settings in Windows 1) Search for Sound in Windows 2) Select the Playback Tab 3) Select the monitor with DisplayPort audio or external speakers 4) Click on the Configuration button to adjust the audio channels 5) Click on the Properties for advanced settings 6) Click Set Default 7) Click Apply 8) Click OK to save the settings...
-
Page 4: Troubleshooting Tips
During this period, the products may be returned for repair, or replaced with equivalent products at our discretion. The warranty covers parts and labor costs only. Cable Matters does not warrant its products from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
