YOKOGAWA YTMX580 Startup Manual

YOKOGAWA YTMX580 Startup Manual

Multi-input temperature transmitter
Hide thumbs Also See for YTMX580:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Technical
Information
TI 04R01B01-01EN
Contents
Introduction ...................................................................................................... 2
Precautions for Use ......................................................................................... 2
1.
Overview .................................................................................................. 3
1.1
1.2
1.3
2.
Preparation .............................................................................................. 6
2.1
2.2
2.3
2.4
2.5
3.
Configuration .......................................................................................... 9
3.1
3.2
3.3
3.4
4.
Checking the Display of Process Data ...............................................33
Appendix 1 Modbus Registers ....................................................................34
Appendix 2 Explanation of Terms ...............................................................35
Appendix 3 DX Custom Display Example ..................................................36
Revision Information .....................................................................................37
YTMX580 Multi-Input Temperature
Transmitter Startup Guide
(From Device Configuration and Wireless Network
Connection to Process Data Monitoring)
Device Configuration ........................................................................................3
Hardware and Software Requirements ...........................................................4
Configuration Work Flow .................................................................................5
Designing the Network .....................................................................................6
Installing the Software and Device File ...........................................................6
Configuring the PC Network ............................................................................6
Configuring the Monitoring Device Network .................................................7
2.4.1
Configuring the DX...........................................................................................7
2.4.2
Configuring the MW .........................................................................................8
Connecting the Devices ...................................................................................8
Provisioning (Step 1) ........................................................................................9
Setting the YTMX (Step 2) ...............................................................................12
Registering the Device (Step 3) .....................................................................15
3.3.1
Configuring Network (Communication) ..................................................... 15
3.3.2
Registering the Device (YTMX) .................................................................... 17
Configuring the Monitoring Device (Step 4) .................................................23
3.4.1
Configuring the DX........................................................................................ 23
3.4.2
Configuring the MW100 ................................................................................ 28
Yokogawa Electric Corporation
2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan
Tel.: 81-422-52-5634 Fax.: 81-422-52-9802
[Style : S1]
TI 04R01B01-01EN
©Copyright Oct. 2011 (KP)
1st Edition, Dec. 12, 2011 (KP)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YTMX580 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for YOKOGAWA YTMX580

Summary of Contents for YOKOGAWA YTMX580

  • Page 1: Table Of Contents

    Technical YTMX580 Multi-Input Temperature Transmitter Startup Guide Information (From Device Configuration and Wireless Network Connection to Process Data Monitoring) TI 04R01B01-01EN [Style : S1] Contents Introduction ...................... 2 Precautions for Use ..................2 Overview ....................3 Device Configuration ..................3 Hardware and Software Requirements ............4 Configuration Work Flow .................5...

  • Page 2: Introduction

    • Yokogawa does not provide any guarantees regarding the details on the configuration explained in this docu- ment. • Yokogawa does not assume any responsibility for any damage directly or indirectly suffered by the user or any third party related to the use of the details on the configuration explained in this document.

  • Page 3: Overview

    Overview One YTMX580 Multi-Input Temperature Transmitter (hereinafter referred to as YTMX) and one YFGW710 Field Wireless Integrated Gateway (hereinafter referred to as YFGW) are connected via the field wireless network, and the process data measured by the YTMX is transmitted to the YFGW at Period of 2 seconds.

  • Page 4: Hardware And Software Requirements

    Hardware and Software Requirements Table 1 shows the hardware and software requirements, including products recommended by Yokogawa. This document describes an example of using the hardware and software listed below. Table 1 Hardware and Software Requirements, including Products Recommended by Yokogawa...

  • Page 5: Configuration Work Flow

    Configuration Work Flow Figure 2 shows the configuration work flow. This document explains the operating procedures according to the steps shown in the work flow. For the work items and configuration tools used for the respective work items, refer to Table 2 “Work Items and Configuration Tools.” Provisioning (Section 3.1) Step 1 ・...

  • Page 6: Preparation

    (YTMX), and the network information for the Ethernet connection of the YFGW. This document uses the settings shown in Table 3 to configure the network. Table 3 Network Settings Item Settings Network ID Device Tag (name to identify the device) YTMX580 Network Settings Device IP Address Subnet Mask Default Gateway YFGW 192.168.0.101...

  • Page 7: Configuring The Monitoring Device Network

    Configuring the Monitoring Device Network The following shows the network settings to connect the DX or the MW to the YFGW via Ethernet. For the operating procedures, refer to the instruction manuals of the respective devices. Settings IP Address: 192.168.0.200 Subnet Mask: 255.255.255.0 Default Gateway: 192.168.0.1 2.4.1...

  • Page 8: Configuring The Mw

    When the all the settings have been configured, click [End] to exit the basic setting mode. The dialog box appears. Select [Yes]. Press DISP/ENTER 2.4.2 Configuring the MW Configure the network settings in MW100 IP Configuration Software. 1. Start MW100 IP Configuration Software from the Start menu of PC1. 2.

  • Page 9: Configuration

    Configuration Provisioning (Step 1) <Important> Provisioning information is required to connect the YTMX to the gateway. Be sure to export the provisioning infor- mation, because the information will need to be imported into Field Wireless Configurator later on. 1. Connect the infrared adapter to PC2 and ensure that the distance to the infrared communication port on the front of the YTMX is within 30 cm.
  • Page 10 Click [OK]. 5. Set [100] in Network ID and [YTMX580] in Device Tag, and click [Start Provisioning]. If a device tag is already set, set [YTMX580] as necessary. When the dialog box to confirm whether to update the settings appears, click [OK].
  • Page 11 7. Click [Exit] from the File menu to exit Provisioning Device Tool. TI 04R01B01-01EN Dec. 12, 2011-00...

  • Page 12: Setting The Ytmx (Step 2)

    Setting the YTMX (Step 2) This section describes the device settings of the YTMX. The screen shows FieldMate R2.03.01 as an example. For details on FieldMate, refer to the instruction manual of FieldMate. 1. Connect the infrared adapter to PC2 and ensure that the distance to the infrared communication port on the front of the YTMX is within 30 cm.
  • Page 13 4. Click [Configure/Setup] of [AI1 Temp] from [Device Configuration] and select the [Configuration] tab. For FieldMate R2.04.01, [Device Configuration] is under [Menu (online)]. 5. Select the [O/S] checkbox in [Mode. Target] of [Block Mode] and click [Apply parameters] ([Download to device] for R2.04.01).
  • Page 14 6. Configure the settings shown in Table 5 for the respective parameters of AI1 Temp. When configuration of the respective parameters is complete, click [Apply parameters] ([Download to device] for R2.04.01). Table 5 Parameter Settings Item Parameter AI1 Temp to AI8 Temp Scale High Limit Scale.EU at 100% 100.0...

  • Page 15: Configuring The Network (Communication) And Registering The Device (Step 3)

    10. Click [Exit] from the File menu to exit FieldMate. Configuring the Network (Communication) and Registering the Device (Step 3) 3.3.1 Configuring Network (Communication) 1. Start Field Wireless Configurator from the Start menu of PC1. 2. When the Login dialog box appears, enter “admin” in Login Name and Password and click [OK]. 3.
  • Page 16 4. Configure the settings shown in Table 6, such as Network ID and Network Information. Note 2 : Do not change the setting Note 1 Note 1: The ISA100.11a field wireless network uses the wireless frequency bandwidths for the respective channels defined in the IEEE 802.15.4.

  • Page 17: Registering The Device (Ytmx)

    3.3.2 Registering the Device (YTMX) Import the provisioning information and register the device (YTMX) with the YFGW. Copy the provisioning infor- mation file (YTMX-Prov.ypif) that was exported (saved to PC2) in Step 1 Provisioning to PC1. Importing the Provisioning Information 1.
  • Page 18 1. Double-click the displayed Device Tag. 2. When the Edit Device window appears, click [Load CF/DD]. Select the CF file (00010101.cff) for the YTMX and click [Open]. (Default: c:¥Program Files¥Yokogawa¥DTM¥DTMev¥EV¥ISA100¥00594543¥1802) Setting Device Role Set [IO] in [Device Role] (uncheck the box for Router) and click [Apply].
  • Page 19 Setting Publication Period Click the [Sampling Data] tab, click [DIAG_STATUS] of [UAP 2] [UAPMO_01] of Available Parameter, and click the [>] button. Set 2 (sec) in [Publication Period (sec)] and click [Apply]. When the confirmation message appears, click [OK]. Setting Modbus Resisters Map the process data (parameters) to the registers of the YFGW according to the settings below.
  • Page 20 2. Drag PV of AI_01 to position 3 of Input Register. 3. Repeat the same operation for AI_02 to AI_08 to map the parameters to the registers. 4. When the mapping of the parameters is complete, click [Apply Changes]. Saving Project File 1.
  • Page 21 Downloading 1. Click [Download] from the Tools menu. 2. When the Download Project Data window appears, click [Start download]. When the confirmation message appears, click [Yes]. 3. Select YTMX.yep and click [Save]. When the message to confirm whether to replace the file appears, click [Yes]. TI 04R01B01-01EN Dec.
  • Page 22 4. When the download is complete, confirm that there are no errors and click [Close]. If errors such as a timeout occur, wait for about 3 minutes and then click [Start download] again. 5. Click [Close] in the Download Project Data dialog box. Click [Exit] from the File menu to exit Field Wireless Configurator.

  • Page 23: Configuring The Monitoring Device (Step 4)

    Configuring the Monitoring Device (Step 4) This section explains the settings for displaying the process data in the DX or the MW. For the operating proce- dures, refer to the instruction manuals of the respective devices. 3.4.1 Configuring the DX Configuring the Modbus Client Configure the Modbus client in the Basic Setting Mode.
  • Page 24 Basic Configuration Setup Screen [Communication (Ethernet)] > [Modbus Client] > [Basic Setting] > DISP/ENTER Settings Read cycle: 2s Retry interval: 2min TI 04R01B01-01EN Dec. 12, 2011-00...
  • Page 25 Configuring the Connection Destination Server Setup Screen [Communication (Ethernet)] > [Modbus Client] > [Modbus server settings] > DISP/ENTER Settings Connection Destination Server 1 Port: 502 Modbus Server Name: 192.168.0.101 (IP address of the YFGW) Unit: Auto Setting Transmission Commands Setup Screen [Communication (Ethernet)] >...
  • Page 26 Settings Client Server Command No. Command Type Connection First/Last Register Type Destination 30005 30008 30011 30014 R-Math FLOAT_B 30017 30020 30023 30026 When configuration of the parameters is complete, click [End] to exit the Basic Configuration Mode. When the dialog box to confirm whether to save the settings appears, select [Yes] > DISP/ENTER. Setting the Calculation Expression In the calculation channel, set the communication channel to which the process data is to be loaded.
  • Page 27 Setting the Group Set the group for the channels to be displayed. Setup Screen MENU key (to switch to setting mode) > [Menu] tab > [Group set, Trip line] > DISP/ENTER Settings Group No. 1 On/Off: On Group Name: Set any name. Channel Setting: 101 –...

  • Page 28: Configuring The Mw100

    3.4.2 Configuring the MW100 This section describes the settings for displaying the process data in the MW. For the operating procedures of the MW, refer to the instruction manual of the MW. Configuring the Modbus Client Modbus Client Setting 1 Setup Screen Top window >...
  • Page 29 Modbus Client Setting 2 Setup Screen Top window > [Communication Setting] > [Modbus Client Setting 2] Settings No. 1 Server: 192.168.0.101 (Set the IP address of the YFGW.) TI 04R01B01-01EN Dec. 12, 2011-00...
  • Page 30 Modbus Client Setting 3 Setup Screen Top window > [Communication Setting] > [Modbus Client Setting 3] Settings Channel Type Server Unit Register Data Type Read 30005 C001 C001 Read 30008 C002 C002 Read 30011 C003 C003 Read 30014 C004 C004 Float-Big Read 30017...
  • Page 31 Setting MATH channel Expressions In the MATH channels, set the communication channels to which the process data of the respective channels is to be loaded. Setup Screen Top Window > [Chanel Setting] > [MATH Channel Setting] Settings Span Action Expression Unit Decimal Point Lower...
  • Page 32 Setting the Group Set the calculation channels in the display group (No.). Setup Screen Top Window > [Display Setting] > [Display Group Setting] Settings Group Name Channel Set Group 1 A001-A008 *1: Set any group name. TI 04R01B01-01EN Dec. 12, 2011-00...

  • Page 33: Checking The Display Of Process Data

    Checking the Display of Process Data When configuration of all the parameters is complete, check that the process data is displayed on the DX or the DX2000 Display Example MW100 Display Example (shown in a PC Window) TI 04R01B01-01EN Dec. 12, 2011-00...

  • Page 34: Appendix 1 Modbus Registers

    Appendix 1 Modbus Registers The table below shows the parameters of the YTMX and the corresponding Modbus registers of the YFGW. Three words are used to map one parameter of the YTMX to the corresponding Modbus register of the YFGW. YTMX Parameter YFGW Register Parameter...

  • Page 35: Appendix 2 Explanation Of Terms

    Period set in the wireless field devices. Network Topology There are two network topologies, star and mesh, in field wireless communication systems. Yokogawa recommends the star network topology as it has advantages such as deterministic network actions facili- tating future management and superb scalability.

  • Page 36: Appendix 3 Dx Custom Display Example

    Appendix 3 DX Custom Display Example The custom display function of the DX allows the user to customize the display flexibly by changing the size and layout of the display objects (e.g. trend, digital, and bar graph). Furthermore, the display can be turned into an intuitive overview monitor by placing image files (bitmap) on the display.

  • Page 37: Revision Information

    For Questions and More Information If you have any questions, you can send an E-mail to the following address. E-mail: support-CENTUM@csv.yokogawa.co.jp n If you want have more information about Yokogawa products, you can visit Yokogawa’s homepage at the following web site. Homepage: http://www.yokogawa.com/ n Written by Product Marketing Dept.
