K3139 SERIES
RANGE HOODS
Traditional Italian style and a soft-radius design
beautifully merge to create a hand-rolled
masterpiece.

FEATURES

Italian design
Wall mount
Finishes: 430 Stainless Steel #4 Brushed, White, Black
Widths: 30", 36", 42"
Ducted/non-ducted telescopic flue accommodates 8' to 9'
ceilings
6" round duct connector/backdraft damper
Halogen lighting (2 bulbs included. Type GU10, MR16
shielded, 120 volt, 50 watts max.)
Multispeed push-button controls feature an "On" indicator
Quiet, variable-speed centrifugal blower with high-
efficiency motor produces 400 CFM of exhaust
Can be ducted to the outside or non-ducted for indoor
recirculation (purchase recirculation kit separately)
Dishwasher-safe filter features a quick-release latch and
decorative cover plate
Heat Sentry
TM
- automatically turns blower to high speed
when excess cooking heat is detected

OPTIONS

Backsplash available (Contact Broan Technical Support)
Non-ducted recirculation kit (Model NDK3139)
Replacement charcoal filters available (Model FILTEREB40)
Flue extension for 10' ceiling (for ducted applications) (35"
long) (Model FEXTK3139 in Stainless Steel, White, Black)

SPECIFICATIONS

VOLTS
AMPS
CFM
120
3.03
400
REFERENCE
QTY.
SONES
DUCT
6.0
6" round
BEST BY BROAN P.O. BOX 140 HARTFORD, WISCONSIN 53027
REMARKS
SPECIFICATION SHEET
Mount range hood so bottom of hood is
24" minimum above cooking surface.
HVI-2100 CERTIFIED RATINGS comply with new
testing technologies and procedures prescribed by
the Home Ventilating Institute, for off-the-shelf
products, as they are available to consumers. Product
performance is rated at 0.1 in. static pressure, based
on tests conducted in AMCA's state-of-the-art test
laboratory. Sones are a measure of humanly-perceived
loudness, based on laboratory measurements.
Project
Location
Architect
Engineer
Contractor
Submitted by
60H
Date
99043159E
