- Page 1 GR716-BOARD Development Board 2019 User's Manual The most important thing we build is trust GR716-BOARD Development Board User's Manual GR716-BOARD-UM, 2019, Version 0.1 www.cobham.com/gaisler...
- Page 2 GR716-BOARD Intentionally Blank GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler...
-
Page 3: Table Of Contents
Oscillators and Clock Inputs................17 4.10 Power Supply and Voltage Regulation..............18 4.11 Reset Circuit and Button...................21 4.12 Watchdog......................21 Setting Up and Using the Board...................22 Interfaces and Configuration..................23 List of Connectors.....................23 List of Oscillators, Switches and LED's............25 Change Record.......................30 GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... - Page 4 List of Figures Figure 3-1: GR716-BOARD Development Board................7 Figure 4-1: GR716-BOARD Board Block Diagram................9 Figure .4-2: GR716-BOARD Board Dimensions................10 Figure 4-3: GR716-BOARD mounted on a GR716-CPCI-DEV Carrier board.........11 Figure 4-4: GR716-TEST-MEMORY BOARD.................12 Figure 4-5: GR716-TEST-ADCDAC BOARD..................12 Figure 4-6: GR716 Microcontroller Block Diagram................13 Figure 4-7: GR716 Package.......................13...
-
Page 5: Introduction
Scope of the Document This document provides a User's Manual and Interface document for the “GR716- BOARD” Development and Demonstration board. The work has been performed by Cobham Gaisler AB, Göteborg, Sweden. Reference Documents [RD1] GR716, Data Sheet and User's Manual",Cobham Gaisler, GR716-UM-DS, available from http://www.gaisler.com/index.php/products/components/GR716... -
Page 6: Abbreviations
European Space Research and Technology Center GPIO General Purpose Input / Output Integrated Circuit Input/Output Intellectual Property Low Drop-Out Printed Circuit Board Point of Load System On a Chip Spacewire To Be Confirmed To Be Defined GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 7: Introduction
GR716-BOARD Introduction Overview This document describes the GR716-BOARD Development Board. This equipment is intended to be used as a platform for the demonstration of the Cobham Gaisler GR716 RAD Hard Microcontroller. Furthermore, this board provides developers with a convenient hardware platform for the evaluation and development of software for the GR716 microcontroller. -
Page 8: Handling
This board is intended for commercial use and evaluation in a standard laboratory environment, nominally, 20°C. All devices are standard commercial types, intended for use over the standard commercial operating temperature range (0 to 70ºC). GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 9: Board Design
BOOTSTRAP/ CONFIGURATION CONFIGURATION Figure 4-1: GR716-BOARD Board Block Diagram Note that not all features and interfaces are available at the same time, and the configuration of on-board resistors plus programming of registers is required to access some of the features. -
Page 10: Board Mechanical Configuration
Figure .4-2: GR716-BOARD Board Dimensions The expansion connectors P1 and P2 of the GR716-BOARD are stacking style connectors having a socket on the bottom side and an extended pin on the top side. In a stand-alone configuration the pins on the top side allow easy access for Logic Analyser or Oscilloscope probing for all the functional microcontroller pins. -
Page 11: Figure 4-3: Gr716-Board Mounted On A Gr716-Cpci-Dev Carrier Board
Figure 4-5. This concept also provides a convenient way for User Defined interface boards to be developed and connected to the GR716-BOARD, if other functions or features are to be demonstrated. GR716-BOARD-UM, May 2019, Version 0.1... -
Page 12: Figure 4-4: Gr716-Test-Memory Board
GR716-BOARD Figure 4-4: GR716-TEST-MEMORY BOARD Figure 4-5: GR716-TEST-ADCDAC BOARD GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 13: Gr716 Microcontroller
GR716-BOARD GR716 Microcontroller The Cobham Gaisler GR716 Microcontroller features a fault-tolerant LEON3 SPARC V8 processor, communication interfaces and on-chip ADC, DAC, Power-on-Reset, Oscillator, Brown-out detection, LVDS transceivers, regulators to support for single 3.3V supply, ideally suited for space and other high-rel applications. -
Page 14: Memory
These signals are connected from the GR716 microcontroller to the Expansion connector, P2. 100 Ohm Termination resistors and fail-safe resistors for the LVDS receiver signals are mounted on the board close to the receiver. GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 15: Gpio
No current limiting or overvoltage protection components are included on the GPIO signals of the GR716-BOARD board. The signals are connected directly from the microcontroller to the expansion connector. Care must therefore be taken to ensure that any external circuitry connected does not exceed the allowable voltage limits for the input/output pins. -
Page 16: Debug Support Unit Interfaces
Debug Support Unit Interfaces Program download and debugging to the processor is performed using the GRMON Debug Monitor tool from Cobham Gaisler ([RD4]). The GR716 microcontroller provides a UART based DSU interface for Debug and control of the processor by means of a host terminal, as represented in Figure 4-9. -
Page 17: Oscillators And Clock Inputs
GR716-BOARD Oscillators and Clock Inputs The oscillator and clock scheme for the GR716-BOARD Board is shown in Figure 4-11. Two oscillator inputs are required: CLK for the main system clock, and SPW_CLK for the SpaceWire clock of the microcontroller To allow the GR716 Microcontroller to operate in a stand alone manner a crystal is required on the board which is connected to the Crystal oscillator interface for the GR716. -
Page 18: Power Supply And Voltage Regulation
INA219 Current/Power Monitor circuits with an I2C interface are incorporated on the board. The I2C signals (SDA, SCL) are connected to the Expansion connector P2 to allow the current/voltage to be measured using an I2C master circuit. GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 19: Figure 4-12: Power Regulation Scheme
DCDC I2C measure VDDA_DAC 5V min 12V nom LMZ21701 FILTER 14.5V max 1A max VDDA_REF FILTER GR716 VDDA_LVDS VDD_LDO_IN VDD_IO +1V8 +1V8 VDD_CORE DCDC I2C measure LMZ21701 1A max Figure 4-12: Power Regulation Scheme GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 20: Figure 4-13: Power Supply Configuration Jumpers
GR716-BOARD Figure 4-13: Power Supply Configuration Jumpers GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 21: Reset Circuit And Button
The GR716 microcontroller includes an internal Watchdog timer function which can be used for the purpose of generating a system reset in the event of a software malfunction or crash. Please refer to [RD1]. GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 22: Setting Up And Using The Board
ERROR condition. To perform program download and software debugging on the hardware it is necessary to use the Cobham Gaisler GRMON3 debugging software, installed on a host PC (as represented in Figure 4-9). Please refer to the GRMON3 documentation for the installation of the software on the host PC (Linux or Windows), and for the installation of the associated hardware dongle. -
Page 23: Interfaces And Configuration
Digital Ground Table 3: J1 Screw Terminal Connector for Input Voltages Name Comment +VIN Inner Pin, +5V to +12V, typically 1 A DGND Outer Pin Return Table 4: J2 POWER – External Power Connector GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 24: Table 5: Expansion Connector P1 Pin-Out
GR716-BOARD Table 5: Expansion connector P1 Pin-out Table 6: Expansion connector P2Pin-out GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 25: List Of Oscillators, Switches And Led's
Redundant Memory Available S1-5 DSUTX Copy ASW image S1-6 SPIM_SEL Boot Source 0 S1-7 SPIM-SCK Boot Source 1 S1-8 SPIM-MOSI Remote access/Boot from memory Table 10: Definition of Switch S1 functions (refer to [RD1]) GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 26: Figure 6-1: Pcb Top View
GR716-BOARD Figure 6-1: PCB Top View GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 27: Figure 6-2: Pcb Bottom View
GR716-BOARD Figure 6-2: PCB Bottom View GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 28: Figure 6-3: Pcb Top View (Photo)
GR716-BOARD Figure 6-3: PCB Top View (Photo) GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 29: Figure 7-1: Pcb Bottom View (Photo)
GR716-BOARD Figure 7-1: PCB Bottom View (Photo) GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... -
Page 30: Change Record
GR716-BOARD Change Record Issue Date Section / Page Description 2019-05-02 Draft Issue 2019-05-02 Corrected bootstrap signals and start-up behaviour for default configuration GR716-BOARD-UM, May 2019, Version 0.1 www.cobham.com/gaisler... - Page 31 Cobham; nor does the purchase, lease, or use of a product or service from Cobham convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual rights of Cobham or of third parties.
