GR716-BOARD Quick Start Guide
GR716-BOARD-QSG
April 2019, Version 1.0
1
www.cobham.com/gaisler

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GR716-BOARD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for COBHAM GR716-BOARD

Summary of Contents for COBHAM GR716-BOARD

  • Page 1 GR716-BOARD LEON3FT Microcontroller 2019 User's Manual The most important thing we build is trust GR716-BOARD Quick Start Guide GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 2: Table Of Contents

    8.4.5. AHB status register .................... 37 8.4.6. APBUART ......................38 8.4.7. SPI master controller ..................39 8.4.8. I2C master controller ..................39 8.4.9. SpaceWire ......................40 8.4.10. CAN ......................41 8.5. GR716 interfaces ......................43 GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...
  • Page 3 9.1. DSU UART FTDI ......................53 9.2. Memory board ......................53 9.3. Interface boards ......................54 9.4. Resources ........................54 10. Support ..........................55 A. Assembly drawing ........................56 B. Default configuration ......................57 GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 4: Introduction

    GR716 Data sheet and User's Manual [https://www.gaisler.com/doc/gr716/GR716-DS- UM.pdf] RD-4 GRMON User's Manual [https://www.gaisler.com/doc/grmon3.pdf] RD-5 TSIM User's Manual [https://gaisler.com/index.php/products/simulators] RD-10 Bare C Cross-Compilation System [https://www.gaisler.com/index.php/products/operat- ing-systems/bcc] RD-11 BCC User's Manual [https://www.gaisler.com/doc/bcc2.pdf] The referenced documents can be downloaded from https://www.gaisler.com. GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 5: Overview

    • 1 x TDP interface (SpaceWire time distribution protocol) • Socket for user defined Crystal (5 MHz – 25 MHz) • Option for External Clocks • DIP switch for Bootstrap options The board has the dimension of 80 x 100 mm. GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...
  • Page 6 Figure 2.1. GR716-BOARD Table 2.1. Major board items Item Description Section Reset LED 3V3 power supply LED 1V8 power supply LED Power connector for standalone operation Alternative power connector 3.3.1 Socket for external crystal. JP1 - JP9 Power supply source configuration...
  • Page 7 Figure 2.2. GR716 Development Board GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 8: Board Configuration

    • General I/O, SPI flash PROM and Debug-UART are enabled. The complete default configuration can be found in Appendix B and GR716 Development Board User's Manual. If this is your first time using the GR716-BOARD, please use this configuration as a starting point. Default configuration To achieve the default configuration please follow the instructions on each box note like this one.

  • Page 9: Alternative Power

    Bootstrap signals configure the chip at reset and are listed in the section Bootstrap signals of GR716 Data sheet and User's Manual. All of these signals can be controlled on the GR716-BOARD via the SPDT DIP switch S1 position 1 to 8.

  • Page 10: Reset

    Default configuration is to start execute application software from the SPI memory after internal ROM initialization software has executed. The ASW container format is not used by default. Figure 3.2. GR716-BOARD default bootstrap configuration The default configuration of the board uses: •...

  • Page 11: External Reset And Break Switch

    • Boot strap option might cause sub-sections of shared pins to be used for memories or remote access. • GR716-BOARD might be connected to hardware not aware of the GR716 e.g. when user has connected the GR716-BOARD with a GR-CPCI-GR716-DEV board.

  • Page 12: Debug Communication Link

    NOTE: Do NOT connect the USB cable to the host computer until the board is supplied via the the connector J2 or PC/104 style stackable headers. Figure 3.3. Connect to UART debug communication link using the FTDI adapter board For more information on the external FTDI FT423HL chip board, see Section 9.1. GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 13: Software Development Environment

    Bare C Cross-Compiler System is a toolchain to compile bare C or C++ applications di- rectly on top of the processor without the servises provided by an operating system Cobham Gaisler also provides a set of debug tools. The GR716 platform is supported by the following: GRMON Used to run and debug applications on GR716-BOARD hardware.

  • Page 14: Grmon Hardware Debugger

    The previous sections have described which debug-links are available and how to start using them with GRMON. The subsections below assume that GRMON, the host computer and the GR716-BOARD board have been set up so that GRMON can connect to the board.
  • Page 15 GRMON is started with the -u and –cginit 0x00010000 options in order to redirect UART output to the GRMON terminal. $ grmon -u -cginit 0x00010000 -uart /dev/ttyUSB0 GRMON LEON debug monitor v3.0.15 64-bit pro version Copyright (C) 2019 Cobham Gaisler - All rights reserved. For latest updates, go to http://www.gaisler.com/ Comments or bug-reports to support@gaisler.com Device ID:...
  • Page 16 GR716 Analog-to-Digital Conv Cobham Gaisler GR716 Analog-to-Digital Conv Cobham Gaisler GR716 Analog-to-Digital Conv Cobham Gaisler GR716 Analog-to-Digital Conv Cobham Gaisler GR716 Analog-to-Digital Conv Cobham Gaisler GR716 Analog-to-Digital Conv Cobham Gaisler GR716 Analog-to-Digital Conv Cobham Gaisler GR716 Analog-to-Digital Conv Cobham Gaisler...
  • Page 17 AHB Master 0 ahb2ahb2 Cobham Gaisler AHB-to-AHB Bridge AHB Master 1 AHB: 30000000 - 30100000 AHB: 90000000 - A0000000 memscrub0 Cobham Gaisler AHB Memory Scrubber AHB Master 2 AHB: FFF00000 - FFF00100 IRQ: 63 burst length: 8 bytes ahb2ahb3 Cobham Gaisler...
  • Page 18 Cobham Gaisler AHB/APB Bridge AHB: 94000000 - 94100000 ahbtrace0 Cobham Gaisler AMBA Trace Buffer AHB: 9FF20000 - 9FF40000 Trace buffer size: 128 lines irqmp0 Cobham Gaisler Multi-processor Interrupt Ctrl. APB: 80002000 - 80002400 EIRQ: 1 gptimer0...
  • Page 19 Cobham Gaisler AHB Status Register APB: 80306000 - 80306100 IRQ: 63 gradcdac0 Cobham Gaisler ADC / DAC Interface APB: 80308000 - 80308100 IRQ: 16 spi0 Cobham Gaisler SPI Controller APB: 80309000 - 80309100 IRQ: 48 Device is disabled spi1...
  • Page 20 Cobham Gaisler I2C Slave APB: 8040D000 - 8040D100 IRQ: 47 grpwm1 Cobham Gaisler PWM generator APB: 80410000 - 80410100 IRQ: 8 Device is disabled l3stat1 Cobham Gaisler LEON3 Statistics Unit APB: 94001000 - 94001400 Device is disabled gpreg3 Cobham Gaisler...
  • Page 21 System IO register for GPIO 16 to 23 0x00000000 0x8000d00c System IO register for GPIO 24 to 31 0x00000000 0x8000d010 System IO register for GPIO 32 to 39 0x00000000 0x8000d014 System IO register for GPIO 40 to 47 0x00000000 GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...
  • Page 22 General Purpose I/O port 0x8030d000 I/O port data register 0x3f000006 0x8030d004 I/O port output register 0x00000000 0x8030d008 I/O port direction register 0x00000000 0x8030d00c I/O interrupt mask register 0x00000000 0x8030d010 I/O interrupt polarity register 0x00000000 GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...
  • Page 23 Below is information listed for the first UART and the first timer core. Registers for the first AHB- STAT are printed in verbose format. grmon3> info sys uart0 gptimer0 uart0 Cobham Gaisler Generic UART APB: 80300000 - 80300100 IRQ: 24...

  • Page 24: Gr716 License Options

    GR716 boards. The evaluation version is limited in certain regards compared with the GRMON professional product. GRMON can be downloaded from the GRMON3 homepage [RD-4]. The following table summarizes the GRMON license options for GR716. GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 25: Gr716 Specific Considerations

    SRAM is possible but slow. • The on-chip boot ROM can be engaged from GRMON with go 0. • When moving software between boards, note that different APBUART and pins are connected to the FTDI UART channels. GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 26: Tsim Leon Simulator

    Register description Value -------- -------------------- ----- ASR16 LEONFT register file prot. reg 0x00000000 ASR17 Processor config register 0x00000d1e ASR22 Up counter MSB 0x80000000 ASR23 Up counter LSB 0x00000000 tsim> uart0_status Address Register description Value GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...
  • Page 27 IP cores and User modules: mctrl_status Print Memory configurations irqmp_status Print irqmp status gptimer0_status Print GPTIMER0 status gptimer1_status Print GPTIMER1 status bootstrap_status Print bootstrap registers uart0_status Print APBUART0 status uart1_status Print APBUART1 status uart2_status Print APBUART2 status GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...
  • Page 28 "spi1_dbg [<flag>|list|help|clean]" for info gpio0_status print gpio ctrl 0 status information gpio0_dbg activate dbg output, "gpio0_dbg [<flag>|list|help|clean]" for info gpio1_status print gpio ctrl 1 status information gpio1_dbg activate dbg output, "gpio1_dbg [<flag>|list|help|clean]" for info GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 29: Toolchains

    BCC together with the GR716 Development Board. It will be demonstrated how to build an an example program and run it on the GR716-BOARD using GRMON. The BCC toolchain includes the GNU C/C++ cross-compiler 7.2.0, GNU Binutils, Newlib embedded C library, the Bare-C run-time system with LEON support and the GNU debugger (GDB).

  • Page 30: Running And Debugging With Tsim

    Once your application is compiled, start TSIM with the -gr716 option. The following log shows how to load and run an application. tsim-leon3 -gr716 TSIM/LEON3 SPARC simulator, version [...] Copyright (C) 2019, Cobham Gaisler - all rights reserved. For latest updates, go to http://www.gaisler.com/ Comments or bug-reports to support@gaisler.com [...] tsim>...
  • Page 31 Program exited normally. Alternatively you can run TSIM with the -gdb command line option and then attach a GDB session to it. For further information see Chapter 3 of [RD-11]. GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 32: Software Examples

    8. Software examples This chapter will describe a software example collection applicable for GR716 and GR716-BOARD applications. The approach is to provide a starting point for integrating different IO functionality with an application. 8.1. Overview 8.1.1. BCC device driver library BCC ([RD-10]) includes a device driver library which can be used on different LEON systems.

  • Page 33: Configuring With The Cpu

    The below example demonstrates how the function set_pinfunc() can be used to configure a pin for UART operation. It has the same effect as Example 8.2. Example 8.4. #include <stdio.h> #include <pinhelper.h> int main(void) int ret; GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 34: Bcc Device Drivers

    BSP=gr716 8.4.2.3. Run grmon3> load bin/clkgate.elf grmon3> run EXAMPLE BEGIN Init with GR716 static tables clkgate_dev_count() -> 2 clkgate0: addr=80006000, interrupt= 0, device_id=0x02c, version=1 clkgate1: addr=80007000, interrupt= 0, device_id=0x02c, version=1 clkgate0 configuration: enabled=08810060 GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 35: Memory Protection Unit

    SEGMENT 3 start = 00000000 = 00000000 = 00000000 example0: reset()... printstarted: device is STOPPED example0: install example configuration on segment 0... example0: reading back segment 0... start = 80004000 = 800040ff = 00000004 GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 36: Memory Scrubber

    LVDS External Loop 14:13 LVDS production test enable Support Locked transfers in SCRUBBER Force Scrubber on main bus 10:9 prot Interrupt test protection bits Generate interrupt Disable reset signal from MIL core Disable reset request GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 37: Ahb Status Register

    Note that the memscrub device is backwards compatible with the ahbstat device. Thus the AHB status register driver can be used with the memscrub device, with limited functionality. In the transcript below, the device named ahbstat2 is the same as memscrub0. GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 38: Apbuart

    The following prepares to run the example with apbuart3 with UART TX output on GPIO35 and UART RX input on GPIO36. Connect a terminal to apbuart3 and set 115200 BAUD. When using GR716-BOARD, and the serial communication program Minicom, the following can be used: $ minicom -D /dev/ttyUSB2 -b 115200 Clock enable apbuart3.

  • Page 39: Spi Master Controller

    (SPIMCTRL) typically named spim0 and spim1. These four controllers operate independently. GR716-BOARD has SPI flash memory connected to the SPI memory controller spim0. The SPI controllers (spi0 and spi1) are not connected to any SPI slave devices on the GR716-BOARD.

  • Page 40: Spacewire

    The driver is general enough to work with most I2C peripherals such as temperature sensors, ADC, DAC, etc. 8.4.8.1. GR716-BOARD current measurement GR716-BOARD has two current measurement devices with I2C interface. The I2C bus of these devices are not directly connected to the GR716. However, the buses are available on the expansion headers which allows to connect the current measurement by fitting jumpers on the connector.

  • Page 41: Can

    The example assumes that the GR716 CAN external signals are connected to CAN transceivers. They could be connected to the same external CAN bus. When using the GR716-DEV board, the CAN accessory board can be used. 8.4.10.1. Build cd $BCC/src/libdrv/examples/grcan make BSP=gr716 GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...
  • Page 42 MSGDATA[1]: 0x68 0x65 0x6c 0x6c 0x6f hello MSG[2]: STD length: 5, id: 0x5 MSGDATA[2]: 0x77 0x6f 0x72 0x6c 0x64 world grcan0: --- receive end grcan1: --- receive begin --- MSG[1]: STD length: 4, id: 0x6 GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 43: Gr716 Interfaces

    $EXAMPLE/common/adchelper.c, allowing to perform common ADC con- figuration and operations. It is used in the example. 8.5.1.2. Preparation Connect an analog input source to the board connector corresponding to ADC input 0. 8.5.1.3. Build cd $EXAMPLE/adc GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 44: Clock And Pll

    It is recommended to refer to the clock distribution scheme figure in GR716 Data sheet and User's Manual when studying the support library. 8.5.2.2. Preparation Connect the pin EXT_PLL to a clock source. This is part of the GR716-BOARD default configuration. 8.5.2.3. Build cd $EXAMPLE/clock make 8.5.2.4.

  • Page 45: Boot Loader

    8.6. Boot loader The GR716 on-chip ROM contains a boot loader which is engaged on power-on. The boot loader can copy a user application image from non-volatile external memory to on-chip RAM and start executing. GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 46: The Asw Format

    Application Storage Memory without the need for re-generating. This is independent of the -a parameter. 8.6.2.2. BCH generation tool A script named $EXAMPLE/scripts/bchfile.tcl is available for generating BCH check bytes to arbitrary input data. Command line parameter syntax for bchfile.tcl is: bchfile.tcl [-elf] [-a ADDRESS] SOURCE DEST SIZE GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 47: Asw Image In Spi Flash Example

    $ sparc-gaisler-elf-objdump -h hello-board.elf.img.rom-with-bch.elf hello-board.elf.img.rom-with-bch.elf: file format elf32-sparc Sections: Idx Name Size File off Algn 0 .data 00004240 02000000 02000000 00000034 2**0 CONTENTS, ALLOC, LOAD, DATA 1 .bch 00001090 02ffef70 02ffef70 00004274 2**0 CONTENTS, ALLOC, LOAD, DATA GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 48: Io Switch Validation Script And Configuration

    The IO validation and configuration script prints the following sections and information: • IO configuration register constants. The IO configuration constants can be used to update the IO registers in order to set the target configuration. GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 49: Scripts Sections

    # Pin list ##################################################################################### pin[0]: mem_addr(0) pin[1]: mem_addr(1) pin[2]: mem_addr(2) pin[3]: mem_addr(3) pin[4]: mem_addr(4) pin[5]: mem_addr(5) pin[6]: mem_addr(6) pin[7]: mem_addr(7) pin[8]: mem_addr(8) pin[9]: mem_addr(9) pin[10]: mem_addr(10) pin[11]: mem_addr(11) pin[12]: mem_addr(12) pin[13]: mem_addr(13) pin[14]: mem_addr(14) GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 50: Memory Board Configuration

    The GR716 Development Board can be configured to use external SRAM, FLASH and SPI memory. To extend the GR716-BOARD and for correct board configuration, see Section 9.2. External SRAM and FLASH memory shares address and data pins. The script will issue a warning which the user needs to check before programming the IO configuration registers.

  • Page 51: Resources

    8.9. Resources Table 8.1. GR716 software examples resources GR716-AN-0002 External ROM Memory boot option using the GR716 [https://www.gaisler.com/index.php/ products/components/gr716] GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...
  • Page 52 GR716-AN-0003 SPI Memory boot option using the GR716 [https://www.gaisler.com/index.php/prod- ucts/components/gr716] GR716-BP GR716 Quick Start Guide Board Package, gr716-examples-<DATE>.zip [https:// www.gaisler.com/index.php/products/components/gr716] GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 53: Expansion Boards

    9. Expansion boards This section provides an overview of expansion boards which can be attached to the GR716-BOARD expansion connectors. 9.1. DSU UART FTDI The GR716-DSU-USB board can be connected to the GR716-BOARD to: • Debug UART to USB conversion supported by GRMON (Chapter 5).

  • Page 54: Interface Boards

    Best practice is to connected the GR716-TEST-MEMORY board to the GR716-BOARD via the PC/104 style stackable headers on the backside as shown in Figure 9.2. Figure 9.2. GR716 Board with a GR716 Memory board with a GR716 Memory board connected via the PC/104 connector on the backside.

  • Page 55: Support

    10. Support For support contact the Cobham Gaisler support team at support@gaisler.com. When contacting support, please identify yourself in full, including company affiliation and site name and address. Please identify exactly what product that is used, specifying if it is an IP core (with full name of the library distribution archive file), component, software version, compiler version, operating system version, debug tool version, simulator tool version, board version, etc.

  • Page 56: Assembly Drawing

    Appendix A. Assembly drawing Figure A.1. GR716-BOARD top GR716-BOARD-QSG www.cobham.com/gaisler April 2019, Version 1.0...

  • Page 57: Default Configuration

    Select power supply for internal PLL Select power supply for internal LDO Select power supply for internal CORE Select internal reference NOTE: Always leave JP8 open when connecting GR716-BOARD with the GR716- DEV board. External Reference sense JP10 Select system clock source...
  • Page 58 Cobham convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual rights of Cobham or of third parties. All information is provided as is. There is no warranty that it is correct or suitable for any purpose, neither implicit nor explicit.
