pitsco LSRAV Dragster Kit User Manual

Download this manual

LSRAV Dragster

User Guide

The following materials should be in the LSRAV Dragster Kit. If

anything is missing, call Pitsco Customer Service at 800-358-4983 or

e-mail service@pitsco.com.

Teachers: Copy these instructions for the class pack kits.

Materials Included:

• 2 front wheels

• 2 rear wheels

• 2 axles

• 2 screw eyes

• 4 brass washers

• Wooden body blank

• Foam body blank

• Plastic straw

• CO

cartridge

• Grid paper

• 1/4" grid paper

LSRAV Dragster User Guide 58580 V0110

Items Required (not included):

• Pitsco Free Hand Foam Cutter or coping saw

• Latex or tempera paints (for foam prototype)

• Drill (drill press recommended)

• Spray or acrylic paints (for dragster finish)

• Band saw or jigsaw

• Construction paper

• Carbon paper

• Scissors

• Wood rasp

• Sandpaper

• Sanding sealer (optional)

• Decals and stickers (optional)

Need help?

Do you have a question about the LSRAV Dragster Kit and is the answer not in the manual?
