6. Specifications

Item
Number of domains
Number of address
entries
Number of alias tables
Communication
transceiver
Baudrate
Protocol
Communication signal
Transmission distance
Number of
Network variables
Number of connected
nodes
Service pin function
Terminal block
Specification
2
31
8
Free topology transceiver
TP/FT-10 channel type
78kbps
LonTalk
2 wires and shield
Free topology:
Between devices: 400m or less
Total cable length: 500m or less
Bus topology (both terminated):
Total cable length: 1400m or less
Stub length: 3m or less
Input network variables: 7
Output network variables: 12
Configuration properties: 12
64 nodes at maximum / segment
Mechanical switch (SW2)
Detachable terminal block 3-pole
- 24E -
Description
ANSI/EIA/CEA 709.3
ANSI/EIA 709.1
NETA, Shield, NETB
When recommended cable is used:
Level 4/22AWG
However, a host and a router are
counted as one node.
Used for notification of Neuron ID to
the host.
Applicable terminal block
Manufacturer: PHOENIX CONTACT
Type-Form : MSTB 2,5/3-ST-5,08
