Summary of Contents for OTT PLS
- Page 1 Supplement to operating instructions Pressure Probe OTT PLS...
- Page 2 We reserve the right to make technical changes and improvements without notice.
-
Page 3: Table Of Contents
Table of contents 1 Scope of supply 2 Order numbers 3 Introduction 4 Please note – important information 5 Separating/inserting plug-in connection 6 Information on repair 7 Technical Data... -
Page 4: Scope Of Supply
– 1 operating instructions – 1 supplement to operating instructions – 1 factory acceptance test certificate (FAT) 2 Order numbers OTT PLS OTT PLS pressure probe with 63.037.002.3.0 plug-in type plug-in pressure probe cable Required ordering information – Measuring range: 0 … 4 m;... -
Page 5: Introduction
The function of the pressure compensation capillary is maintained by an axial air permeability in the plug-in connection. The connection must only be carried out in a dry state above the water! The OTT PLS version with SDI-12 interface is not available with a plug-in pressure probe cable. - Page 6 Pressure probe cable Connector (connector sleeve on connector body) Coding lug Protective cap Caution: Protective cap There must not be a gap here when O-ring connected and Coding lug screwed together (as far as possible)! Caution: Avoid the entry of damp and contamination Pressure when disconnected!
-
Page 7: Information On Repair
0 … 10 m ➝ 50 m 0 … 20 m ➝ 50 m 0 … 40 m ➝ 50 m 0 …100 m ➝ 120 m max. submersion duration: unlimited time All other data are identical to the standard OTT PLS version. - Page 8 OTT Hydromet GmbH Ludwigstrasse 16 87437 Kempten · Germany Tel. +49 831 5617- 0 Fax +49 831 5617- 2 09 Document number 63.037.002.B.E 02-0511 info@ott.com · www.ott.com...
