P R O G R A M M I N G
ILCS programming is done through the use of menu selections. Any menu can be entered by pressing the ENTER
button, or exited by pressing RESET (or in some cases MENU
headings give an idea of what information can be found, entered, or changed. Within each main menu selection are
several screen "prompts" that walk you through the complete programming process step-by-step.
Below is an example of the main display when the system is idle. The main display is more commonly referred to as
the default display , and appears when the system is not in the programming mode.
ILCS FOAMER
DATE 05/11 TIME 14:32:54
A C C E S S C O D E E N T R Y
The ILCS system has two access codes for protection:
•
The "main" access code allows entry into ALL menus and functions, even when using WinReporter PC software.
•
The "user" access code allows entry into the diagnostics menu only (at the control panel) without the ability of
changing programmed information. When using WinReporter, the user access code allows printing reports only.
Systems are shipped from the factory with both access codes set to zero. Only a person with the "main" access code
can change the "user" access code (changing codes is explained later in this manual). If desired the two access
codes can be the same, however the user will then have access to ALL of the functions of the system, including the
ability of changing programmed information.
ENTER ACCESS CODE
THEN PRESS ENTER
I M P O R T A N T N O T E S
•
Leading zeroes on access codes and user passwords are not required to be entered. For example, a user
password of "010" can be more conveniently typed in as "10", then press ENTER.
•
It is recommended to clear the sum/batch report and batch count, then load factory defaults prior to initial
programming of the system. See MEMORY FUNCTIONS [menu 1] for details.
•
If at any time you get lost in the programming and are not sure what to do, press the RESET button until the
section menu heading appears, then proceed.
Page 8 of 20
or ). Its that simple! Each of the main menu
The default display shows your programmed display name on the
top line. The bottom line will alternate between date/time and the
message ENTER USER PASSWORD.
The "user password" should not be confused with the system's
access code. User passwords allow multiple persons to operate
the system for dispensing chemicals, whereas the access code
allows entry into the menus for programming.
From the default display, you must enter the main access code
(following) to begin programming.
From the default display shown above, press the ENTER button.
The screen at left should appear. If the screen at left does not
appear, wait 2 seconds, press RESET, then press ENTER.
When you see the screen at left, type in the access code and
press ENTER. Remember, for a new system, the access code will
be zero (until you change it later).
You are now in the programming mode. Follow the menus for
each section, starting on the next page.
