  • Page 1 Keysight 41901A SMD Type PI-Network Test Fixture Operation and Service Manual...
  • Page 3 Agilent 41901A SMD Type PI-Network Test Fixture Operation and Service Manual Agilent Part No. 41901-90020 Printed in JAPAN July 2001 Fourth Edition...
  • Page 4 Notice Warranty Limitation of Warranty No other warranty is expressed or implied. Agilent Technologies speci cally disclaims the implied warranties of merchantability and tness for a particular purpose. Certi cation...
  • Page 5 Exclusive Remedies The remedies provided herein are the buyer's sole and exclusive remedies. Agilent Technologies shall not be liable for any direct, indirect, special, incidental, or consequential damages, whether based on contract, tort, or any other legal theory. Assistance...
  • Page 6 Manual Printing History : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : :...
  • Page 7 Safety Summary WARNINGS The Agilent Technologies assumes no liability for the customer's failure to comply with these requirements. Do NOT Operate in an Explosive Atmosphere Do NOT Substitute Parts or Modify Instrument Dangerous Procedure Warnings Warnings Warning Dangerous voltages, capable of causing death, are present in this instrument.
  • Page 8 Safety Symbols Warning Caution Note...
  • Page 9 Contents 1. General Information 2. Preparation for Use 3. Operation 4. Service Contents-1...
  • Page 10 Figures Tables Contents-2...

  • Page 11: General Information

    General Information Introduction Speci cations For the 41901A Available Test Device : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Available Measurement Con guration : : : : : : : : : : : : : : : : : : : : : Operating Temperature...
  • Page 12 For the 41901A used with the 87510A Calibration method : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Circuit model of the calibration standards j fL Table 1-1.
  • Page 13 For the 41901A used with the E5100A/B Circuit model of the calibration standards Figure 1-1. Circuit model of the calibration standards Table 1-2. Parameters Standard Value Supplemental Performance Characteristics For the 41901A Maximum Input Level : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Frequency Range : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : :...

  • Page 14: Options Available

    Options Available Applicable DUT size and contact pin position Figure 1-2. Applicable DUT size and contact pin position General Information...
  • Page 15 The dimension of 41901A main block Figure 1-3. The dimension of 41901A main block General Information...
  • Page 17 Preparation for Use Introduction Initial Inspection Preparation for Use...
  • Page 18 Figure 2-1. 41901A SMD Type PI-Network Test Fixture Product Overview Table 2-1. 41901A Contents Reference Agilent Part Designator Number Qty. Description Not shown in the gure. Preparation for Use...
  • Page 19 Figure 2-2. Option 010,020,030,040,050,060 Attachment Kit Product Overview Preparation for Use...
  • Page 20 Table 2-2. Option 010 Attachment Kit Contents Reference Agilent Part Designator Number Qty. Description Not shown in the gure. Preparation for Use...
  • Page 21 Table 2-3. Option 020 Attachment Kit Contents Reference Agilent Part Designator Number Qty. Description Not shown in the gure. Preparation for Use...
  • Page 22 Table 2-4. Option 030 Attachment Kit Contents Reference Agilent Part Designator Number Qty. Description Not shown in the gure. Preparation for Use...
  • Page 23 Table 2-5. Option 040 Attachment Kit Contents Reference Agilent Part Designator Number Qty. Description Not shown in the gure. Preparation for Use...
  • Page 24 Table 2-6. Option 050 Attachment Kit Contents Reference Agilent Part Designator Number Qty. Description Not shown in the gure. Preparation for Use...
  • Page 25 Table 2-7. Option 060 Attachment Kit Contents Reference Agilent Part Designator Number Qty. Description Not shown in the gure. Preparation for Use...
  • Page 26 Figure 2-3. Option 011,021,031,041,051,061 Attachment Kit Product Overview Table 2-8. Option 011 Attachment Kit Contents Reference Agilent Part Designator Number Qty. Description See Table 2-14. Not shown in the gure. Table 2-9. Option 021 Attachment Kit Contents Reference Agilent Part Designator Number Qty.
  • Page 27 Not shown in the gure. Table 2-11. Option 041 Attachment Kit Contents Reference Agilent Part Designator Number Qty. Description See Table 2-14. Not shown in the gure. Table 2-12. Option 051 Attachment Kit Contents Reference Agilent Part Designator Number Qty. Description See Table 2-14.
  • Page 28 Repackaging the 41901A for Shipment FRAGILE 2-12 Preparation for Use...
  • Page 29 Operation Introduction Connecting the 41901A for Use Figure 3-1. Connecting the 41901A to the 87510A, E5100A/B Operation...
  • Page 30 How to connect the Contact Board to the Fixture Figure 3-2. Connecting the Contact Board to the 41901A Caution Operation...
  • Page 31 Assembling the C Adapter Board Figure 3-3. C Adapter Board Circuit Diagram Operation...
  • Page 32 Table 3-1. Example of C Combinations [pF] [pF] [pF] [pF] [pF] Lmin Lmax Operation...
  • Page 33 Figure 3-4. C Location Note Instruction for Cleaning Operation...
  • Page 34 Using the Sample Programs FLCI_EQV CAP_ADJ FLCI_EQV.BAS CAP_ADJ.BAS Table 3-2. Contents of Disk Filename File Type Description FLCI_EQV FLCI_EQV.BAS CAP_ADJ FLCI_EQV CAP_ADJ.BAS FLCI_EQV.BAS PI_DATA FLCI_EQV CAP_ADJ E5100a.DAT FLCI_EQV.BAS CAP_ADJ.BAS Connecting the 41901A to the 87510A, E5100A/B. Executing the Sample Program Note FLCI_EQV FLCI_EQV.BAS...
  • Page 35 RESISTANCE (OHM) Enter Return Enter Return MODIFY ? (Yes=1,No=0,DEFAULT=0) Enter Return Enter Return Enter Return Enter Return PI_DATA E5100a.DAT NNNNNNNNNNNNNN OPEN NNNNNNNNNNNNNN OPEN NNNNNNNNNNNNNNNNN SHORT NNNNNNNNNNNNNNNNN SHORT NNNNNNNNNNNNNN LOAD NNNNNNNNNNNNNN LOAD Operation...
  • Page 36 Figure 3-5. Calibration, C Adapter Board, C Adjustment NNNNNNNNNNNNNNNNNNNNNNNNNNNNN CAL BREAK NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN DONE: 3 TERM CAL COMPUTING CAL COEFFICIENTS Enter Return NNNNNNNNNNNNNNNNNNNNNNNNNN Continue Operation...
  • Page 37 Note VESSEL Ceramic Adjustment Screwdriver No.9000 ( ) 1.8 NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN ADJUSTMENT END NNNNNNNNNNNNNNNNNNNNNNNNNN Continue Table 3-3. Parameters Measured Parameter Unit NNNNNNNNNNNNNNNNNNNNNNNNNN Continue Note CAP_ADJ CAP_ADJ.BAS Operation...
  • Page 39 Service Introduction 41901A Replaceable Parts Service...
  • Page 40 Figure 4-1. Replaceable Parts Service...
  • Page 41 Table 4-1. Replaceable Parts Reference Agilent Part Designator Number Qty. Description Not shown in the gure. Note Service...
