- Page 1 Walker W296BT Headphones Operating instructions...
-
Page 2: Specifications
■ Product features ● Excellent low frequency, popular toning and suitable for various music style; ● Plastic ear hooks that are wore in ear to prevent from falling; ● CSR chip, Bluetooth Ver. 4.1 and the connection distance is over 10m; ●... -
Page 3: Package List
100dB Sensitivity (SPL) Nominal impedance ■ Package list Headphones*1 pcs USB charging cable*1 pcs Manual/Warranty card*1 PCS each Silica earplug Large size*1 Silica earplug Middle size*1 Silica earplug Small size*1 pair pair pair... - Page 4 ■ Functions 1. Volume increment/Next song 2. Charging port 3. LED lights 4. Microphone 5. Multi-function key 6. Volume decrement/Last song ■ Charging Before usage, please ensure the headphones are fully charged; during usage, if only the red light can be seen twice every 8 seconds and a prompt beep is heard, this indicates low battery capacity.
- Page 5 Warning: The chargeable batteries that provide power for this product must be disposed properly for recycling. Do not put batteries into fire to preventing explosion. ■ How to use headphones 1. Power on/Off Power on: Press and hold multi-pad for about 2 seconds. Release the key when the blue light is on and a prompt beep can be heard in the headphones.
- Page 6 2. How to wear headphones 2.1 Select the earmuffs with proper size based on your ear size and install them. 2.2 Wear the left and right channel to the corresponding left and right ear as shown in the following figure. Wear the headphones first and then adjust the ear hooks to go around the upper part of your ear to properly fix the headphones.
- Page 7 Now the headphones are in pairing mode. 3.2 Enable the mobile‟s bluetooth and search bluetooth devices. Select „EDIFIER W296BT‟ to pair up and connect. After being connected successfully, the prompt beep sounds and the headphones‟ blue light is flashing quickly.
- Page 8 W296BT” connection in the pairing records of the first mobile. Now the headphones have successfully connected with two mobiles. Note: When two mobiles have different operating system (E.g. One has Android and one iOS). Some cross-system operations may have delay (E.g.
- Page 9 5.1 Basic call operation Function Headphone status Operation Receiving Incoming call ringing Press the multi-function key incoming call Refuse incoming Incoming call ringing Press and hold multi-pad about call 2 seconds Terminate call Talking Press the multi-function key Increase volume Talking Press + key Decrease volume...
- Page 10 2. Make three way call Function Headphone Operation status Hang out the current call There is the Press the multi-function to receive new incoming second call incoming call Receive incoming There Press and hold multi-pad call second about 2 seconds incoming call 6.
- Page 11 multi-function key Note: ● Remote play control (Last/Next/Pause/Restore) functions require your mobile or Bluetooth transmitter to support AVRCP protocol. 7. Clear pairing list Press and hold multi-pad, volume up and volume down key in standby status and wait for 5 seconds to clear all the paired device list of the headphones. (Note: After clearing the pairing records successfully, the headphones shall automatically enter into the pairing status after the headphone is switched on).
- Page 12 ■ Maintenance When usage, please read the following suggestions that may be helpful for you to obey the warranty clauses and extend the service time of the product. ● In order to keep the product dry, please do not place the product at the damp places so as not to affect the product‟s internal circuit.
- Page 13 operates, they may damage the product. ● Do not fall, vibrate strongly, strike the product with hard object to prevent damaging the internal circuit. ● Please do not use drastic chemical products and cleaner to clean the headphones. ● Do not use sharp objects to scratch on the product surface to prevent damaging the outer case and affecting looking.
- Page 14 2. The red light is off during charging. Answer: a. Please ensure the charging device is properly connected with the headphones. b. When the headphones are not used for a long time, the battery will enter the hibernate status. Now it needs to charge about 30 minutes and then the red light shall be on.
- Page 16 Note: The environment-friendly use period depends on the conditions like temperature and moisture under which the product can work properly. CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. A warning that batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.
- Page 17 Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
