Summary of Contents for EDIFIER W360BT
- Page 1 W360BT Wearable Bluetooth Earbuds, Headphones, Earphones, Earbuds Operating instructions...
- Page 2 Section 1 Product introduction Before using the headphone, please read this manual carefully and keep it safe for future reference. ■ Product features: Modern ergonomic design streamlined for comfort and optimal fit 13mm moving coil ensures outstanding performance notably in mid‐range and low frequencies High quality CSR chip with Bluetooth V4.1 supports up to 10 meters in distance Up to 20 hours of continuous play Wired controller supports voice calls, makes volume adjustment and switches between music Supports CVC voice noise reduction and HSP / HFP / A2DP / AVRCP protocols Voice control wake up signal enabled Able to connect two devices simultaneously Comes with complete accessories kit Specifications Bluetooth version: Bluetooth V4.1 Bluetooth protocol: HSP / HFP / A2DP /AVRCP Effective distance: 10m Working time: 20 hours Standby time: About 500 hours Charging input: DC 5.0V 300mA Charge time: about 2 hrs Battery capacity：300mAh ...
- Page 3 ■ How to wear 1. Put the cable downward, wear the neck hook from the back of neck; 2. Insert the eartips into the ears and adjust them to a comfortable position. Section 3 ■ Operation instructions 1. Charging When the headphone is in use, if blue indicator change to red color, it shows the battery level is in low, and you need to charge. ...
- Page 4 3.2 The distance between your Bluetooth device and the headphones should be kept within 1 m. The closer, the better. 3.3 Enable your mobile’s Bluetooth function and search the headphone. 3.4 Select ‘EDIFIER W360BT’ to pair up. After being connected successfully, the headphones’ blue light is flashing slowly. Tips: ●...
- Page 5 Talking transferred to Talking (mobile phone) Press and hold multi-function key for about 2 headphones seconds Redial last call Connected device Double press multi-function key Voice dial Connected device Press volume increasing/decreasing key the same time Section 5 Tips: 1. When adjust the volume to the maximum or mute, you will hear a prompt. 2.
- Page 6 5. Play music Function Headphone status Operation Increase volume Play music Press volume increasing key Decrease volume Play music Press volume decreasing key Previous track Play music Press and hold volume decreasing Next track Play music Press and hold volume increasing key Pause play Play music Press the multi-function key...
- Page 7 needs to charge about 30 minutes and then the red light shall be on. 3. The headphones hear nothing. Answer: a. Ensure the volume of headphone is in an available level. b. Ensure if the headphones are connected with mobile properly. c.
- Page 8 7 ...
- Page 9 CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. A warning that batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. Correct Disposal of this product.
- Page 10 Manufacturer: Dongguan Edifier Technology Co., Ltd Address: No. 2, Gongye Dong Lu, Dongguan Songshan Lake Hi-tech Industrial Development Zone Trademark: EDIFIER ○ R , Walker ○ R both are the registered trademark of Beijing Edifier Technology Co., Ltd. Counterfeiting is not allowed.
