Philio Technology Corporation PSM09 User Manual

PSM09
Recessed Door Sensor
The Recessed door sensor PSM09 is Base on Z-Wave
TM
the Z-Wave plus product, it support the security, OTA... Those newest
TM
features of the Z-Wave technology. Z-Wave
communication protocol designed for home automation, specifically to
remotely control applications in residential and light commercial
environments. The technology uses a low-power RF radio embedded or
retrofitted into home electronics devices and systems, such as lighting,
home access control, entertainment systems and household appliances.
Notice: if user use some command,it have to check device is security
bootstrap otherwise some command can not increment.
Add to/Remove from Z-Wave
There are one tamper key in the device,the key is in the front side. Both of
them can add, remove, reset or association from Z-Wave
SmartStart enabled products can be added into a Z-Wave network by
scanning the Zwave QR Code present on the product providing SmartStart
inclusion. No further action is required and the SmartStart productwill be
added automatically within 10 minutes
of minutes On in the network vicinity
TM
technology.It is
TM
is a wireless
TM
Network
TM
network.
Notice: Including a node ID allocated by Z-Wave
"Add" or "Inclusion". Excluding a node ID allocated by Z-Wave
Controller means "Remove" or "Exclusion".
Function Description
1. Have Z-Wave
Pressing tamper key three times within 3 seconds to enter
Add
the inclusion mode.
If the learning code is successful, the LED will flash slowly.
1. Have Z-Wave
Pressing tamper key three times within 3 seconds to enter
the exclusion mode.
Remove
If the removal is successful, the code light will flash for 30
seconds.
Node ID has been excluded.
Notice: Use this procedure only in the event that the primary
controller is lost or otherwise inoperable.
1.
In 3 seconds, press the button 3 times continuously, after 3
successful, then slowly flash for 1 second, press the fourth
button, do not release the button, the LED will light up,
Reset
after about three seconds, the LED will off, and in two
seconds Release the button internally. If the clearing is
successful, the LED will flash slowly. If it fails, the LED will
flash quickly.
1. Have Z-Wave
Pressing tamper key three times within 3 seconds to enter
the association mode.
Association Note: This machine provides a group of groups. Each group
can set 5 Nodes.
Group 1: Used for event return. Example: Reed trigger state
Battery.
• Failed or success in add/remove the node ID can be viewed from Z-
TM
Wave Controller.
Notice 1: Always RESET a Z-Wave
TM
Wave network
1
TM
Controller means
TM
Controller entered inclusion mode.
TM
Controller entered exclusion mode.
TM
Controller entered association mode.
TM
device before trying to add it to a Z-
TM
